- Page 1 User's manual (Translation of original language) N420928A - Rev.04 - 07/2024 AirLeaf EEB749 - EFB749 - EGB749 EEA649 - EEB649 - EFA649 - EFB649 ECA644 - ECA647 - EWF644 - EWF647 E4T643 - E2T543 - B3V137...
- Page 2 By following the suggestions contained in this manual, the product you have purchased will operate without problems giving you optimum room temperatures with minimum energy costs. INNOVA S.r.l. Conformity Refer to the Installation Manual of the paired unit.
-
Page 3: Table Of Contents
TABlE oF ConTEnTs TABLE OF CONTENTS Coding p. 7 1.1 Coding accessories . - Page 4 TABlE oF ConTEnTs Smart Touch remote controls EEA649 - EEB649 - EFA649 - EFB649 p. 15 4.1 Interface ..........p. 15 Description .
- Page 5 TABlE oF ConTEnTs Keys functions ........p. 22 6.1.3 6.2 Main functions .
- Page 6 TABlE oF ConTEnTs 10 Maintenance p. 30 10.1 Preliminary warnings .
-
Page 7: Coding P
EFB749II WiFi module, App Innova Butler. Cable connection. Colour white LED electronic control panel with touch interface, wall-mounted complete with thermostat and room temperature and relative humidity probe. Cable connection. - Page 8 CoDInG Accessory description Combinable products Code Control panels SMART TOUCH wall mounted control panel with thermostat and room tempera- ture and relative humidity probe with integrated WiFi module, InnovAPP. Colour EFA649II (2) black SMART TOUCH wall mounted control panel with thermostat and room tempera- ture and relative humidity probe with integrated WiFi module, InnovAPP.
-
Page 9: General Information P
GEnERAl InFoRMATIon GENERAL INFORMATION 21 About the manual I nthefigures This manual was written to provide all the explanations for the correct management of the appliance. 1 The numbers indicate the individual components. This instruction manual forms an integral part of the A The capital letters indicate component assemblies. -
Page 10: General Warnings
GEnERAl InFoRMATIon Coding Control panels It addresses all recipients. It addresses all recipients. It contains the list of products and/or accessories referred It contains section by control mode and information on the to in the manual. use of the main functions. General information Maintenance and Troubleshooting It addresses all recipients. -
Page 11: M7 Series Controls Eeb749 - Efb749 - Egb749 P
M7 SERIES cOnTROlS EEB749 - EFB749 - EGB749 M 7SERIESCONTROLSEEB749-EFB749-EGB749 31 Interface • internal memory with data saving even in case of 311 Description shut-down or power outage M7 series lED electronic control panels with touch inter- face for wall installation allow: After 20 seconds after the last action the panel bright- •... -
Page 12: Main Functions
M7 SERIES cOnTROlS EEB749 - EFB749 - EGB749 32 Main functions Please refer to chapter "Alarm display on wall control 321 General start-up panel" p. 14 for the list of errors shown on the display. Before the activation: Make sure that the remote control is connected to the 325 Cooling only mode mains. -
Page 13: Set The Key Lock
M7 SERIES cOnTROlS EEB749 - EFB749 - EGB749 All settings are inhibited by the user. 3210 Set the key lock Repeat the sequence to unlock the control. Toset-upthekeylocking ► press both keys for 3 seconds The text appearing on the display. 33 Basic menu 333 S etprobeoffsetRH To access the basic menu ►... -
Page 14: Wi-Fi Reset
M7 SERIES cOnTROlS EEB749 - EFB749 - EGB749 The volume changes after confirm the modification. Activate Wi-FI ToactivateWi-Fi Wi-FI reset ► select up ► press to change settings ToresettheWi-Ficredentialsandreturnthedevice ► use the icons in sequence toitsoriginalconfiguration Appear no. ► select uu ► press ► press to change settings St appears to enable Wi-Fi pairing. ►... -
Page 15: Smart Touch Remote Controls Eea649 - Eeb649 - Efa649 - Efb649 P
SMART TOucH REMOTE cOnTROlS EEA649 - EEB649 - EFA649 - EFB649 S MARTTOUCHREMOTECONTROLSEEA649-EEB649-EFA649- EFB649 41 Interface • internal memory with data saving even in case of 411 Description shut-down or power outage smart Touch wall control panels with thermostat and room temperature and relative humidity probe are electronic The control can control up to a maximum of 30 units. thermostats with the possibility of control over several ap- The room temperature probe ensures an antifreeze pliances with electronic remote control. -
Page 16: Main Functions
SMART TOucH REMOTE cOnTROlS EEA649 - EEB649 - EFA649 - EFB649 413 Keys functions Keys area Up key Down key This can be used to select the operating mode (Cooling or Heating) Enables Automatic function Consente di attivare la funzione notturno con limitazione della velocità di ventilazione e variazione automatica della temperatura Enables Maximum ventilation speed function This can be used to switch the unit on or off Enables the silent function with ventilation speed limitation to a low... -
Page 17: Night Function
SMART TOucH REMOTE cOnTROlS EEA649 - EEB649 - EFA649 - EFB649 4212 R oomtemperatureprobeoffset 427 Night function adjustment To select the Night function ► press the Toadjusttheroomtemperatureprobeoffset key for about 2 seconds The symbol on indicate the Night function en- ► from display off, press the key for about 5 sec- able. onds Access to the variation menu of the AIR probe offset The ventilation speed is limited at a very low value. -
Page 18: Warnings
SMART TOucH REMOTE cOnTROlS EEA649 - EEB649 - EFA649 - EFB649 43 Warnings 431 Long period shut-down For seasonal shutdowns or for long periods: ► disable the device ► set the main system switch to Off The antifreeze function is not on. 432 Visualization of alarms on display Displayedalarms ► Room temperature probe disconnect- ed or faulty None of the modes can be activated. -
Page 19: On-Board Control Eca644 - Eca647 - Ewf644 - Ewf647 P
On-BOARd cOnTROl EcA644 - EcA647 - EWF644 - EWF647 O N-BOARDCONTROLECA644-ECA647-EWF644-EWF647 51 Interface Through the water temperature probe (10 kΩ) positioned The controls can only be installed on the versions Air- leaf sl, Airleaf sls, Airleaf Rs. in the compartment on the unit's coil, the functions can be regulated: • minimum temperature in heating mode (30 °C) 511 Description •... -
Page 20: Main Functions
On-BOARd cOnTROl EcA644 - EcA647 - EWF644 - EWF647 52 Main functions out of range values from 5 °C and 40 °C are allowed, 521 General start-up except in automatic mode. These value should be set Before the activation: only for short periods of time. Make sure that the remote control is connected to the mains. -
Page 21: Brightness Reduction
On-BOARd cOnTROl EcA644 - EcA647 - EWF644 - EWF647 Repeat the sequence to unlock the control. Use this adjustment carefully. This adjustment must be carried out only after having found actual deviations from the room temperature us- 5210 Brightness reduction ing a reliable tool. Toreducethedisplaybrightness Adjust the measured value in a range of - 9/+ 12 K, with ►... -
Page 22: On-Board Control E4T643 P
On-BOARd cOnTROl E4T643 O N-BOARDCONTROLE4T643 61 Interface Through the water temperature probe (10 kΩ) positioned The control can only be installed on the view versions Airleaf sl, Airleaf sls, Airleaf Rs. in the compartment on the unit's coil, the functions can be regulated: • minimum temperature in heating mode (30 °C) 611 Description •... -
Page 23: Main Functions
On-BOARd cOnTROl E4T643 62 Main functions out of range values from 5 °C and 40 °C are allowed, 621 General start-up except in automatic mode. These value should be set Before the activation: only for short periods of time. Make sure that the remote control is connected to the mains. -
Page 24: Brightness Reduction
On-BOARd cOnTROl E4T643 6212 R oomtemperatureprobeoffset 6210 Brightness reduction adjustment Toreducethedisplaybrightness ► with thee display off, press the Toadjusttheroomtemperatureprobeoffset key for 5 sec- onds ► from display off, press the key for about 5 sec- The text appearing on the display. onds ► press the Access to the variation menu of the AIR probe offset key to decrease the value ►... -
Page 25: On-Unit Control E2T543 P
On-unIT cOnTROl E2T543 O N-UNITCONTROLE2T543 71 Interface The control can only be installed on the view versions • internal memory with data saving even in case of Airleaf sl, Airleaf sls, Airleaf Rs. shut-down or power outage Through the water temperature probe (10 kΩ) positioned in the compartment on the unit's coil, the functions can be 711 Description regulated: The electronic control on the unit with 4 fixed speeds and... -
Page 26: Main Functions
On-unIT cOnTROl E2T543 72 Main functions 721 General start-up 725 Setting the ventilation speed Before the activation: To select the fan speed control ► press the key Make sure that the remote control is connected to the mains. The symbol on indicates the Silent function en- able In case of a master switch on the power supply line, switch on the system by inserting the switch. - Page 27 On-unIT cOnTROl E2T543 ► E2 and flashing of lEds Motor alarm (e.g., jamming due to foreign matter or rotation sensor failure) (automatic reset alarm) ► E3 and flashing of lEds Failure water temperature detection probe located in the main battery ► Flashing of lED Water temperature alarm, wa- ter demand not met (<30 °C in heating). Tempo- rary stop of ventilation until the appropriate value is reached ►...
-
Page 28: Speed Selector B3V137 P
SPEEd SElEcTOR B3V137 S PEEDSELECTORB3V137 81 Interface It is fitted with: The control can only be installed on the view versions Airleaf sl, Airleaf sls, Airleaf Rs. • internal memory with data saving even in case of shut-down or power outage After 20 seconds after the last action the panel bright- 811 Description ness is reduced, only the room temperature is seen on The on-board speed selector allows:... -
Page 29: Main Functions
SPEEd SElEcTOR B3V137 82 Main functions 821 General start-up 823 Setting the ventilation speed Before the activation: To select the fan speed control ► press the key Make sure that the remote control is connected to the mains and to a room thermostat with a single 230 V ac The symbol on indicates that the Super Silent contact. -
Page 30: Preliminary Warnings
MAInTEnAnCE MAINTENANCE Routine maintenance is essential to keep the device always efficient, safe and reliable over time. 101 Preliminary warnings Warnings: Before each cleaning and maintenance intervention: ► disconnect the device from the power mains by turn- • Do not lean or sit on the fancoil to avoid damaging ing the system master switch to "oFF"... - Page 31 MAInTEnAnCE Filter extraction Versionwithfinnedintakegrill Air intake grill with fins Filter For removing the filter in versions with a finned in- take grill: ► lift the fin grill slightly ► rotate the fin grill until it comes completely out of the housing ► remove the grid ► remove the filter...
- Page 32 MAInTEnAnCE Version with mobile intake panel Mobile intake panel Filter Toremovingthefilterinversionswithmobileintake panel: ► press the plastic tabs at the lower ends of the mobile panel ► lift the mobile panel slightly ► rotate until the complete exit from the housing ►...
- Page 33 MAInTEnAnCE C leaningthefilters Vacuum cleaner Filter Tocleanthefilter: ► aspirate dust ► use a vacuum cleaner Water flow Filter Ifthequantityofdustisconsiderable: ► wash the filter under running water (max. 40 °c) ► allow to dry in the shade Exposure to the sun or washing water temperatures above 40 °c can shrink the filters. It is forbidden to use detergents or solvents to clean the filter.
- Page 34 MAInTEnAnCE Filter installation Versionwithfinnedintakegrill Filter Filter housing Toreassemblethefilter: ► bring the filter closer to the unit ► insert the filter into its housing ► bring the finned grill closer ► insert the grill into the appropriate slots ► rotating the grill ► hooking the grill check that the filter is fitted correctly. It is forbidden to use the unit without a filter.
-
Page 35: Suggestions For Energy Saving
MAInTEnAnCE Version with mobile intake panel Filter Filter housing Mobile panel Toreassemblethefilter: The appliance is equipped with a safety switch that pre- ► bring the filter closer to the unit vents fan operation in the absence or with a poorly po- ► insert the filter into its housing sitioned moving panel. ►... -
Page 36: Preliminary Warnings
TRoUBlEsHooTInG TROUBLESHOOTING 111 Preliminary warnings ► disconnect the device from power supply immediate- Should you encounter any of the anomalies below: • the ventilation does not start even if the water circuit is filled with hot or cold water ► close the water taps ► contact immediately an authorized technical support •... -
Page 37: Technical Information P
TECHnICAl InFoRMATIon TECHNICAL INFORMATION 121 Operating limits Operating limits u.d.m. Heating Cooling Minimum room relative humidity Maximum room relative humidity Minimum room air temperature °C Maximum room air temperature °C... - Page 38 noTE...
- Page 39 noTE...
- Page 40 InnoVA s.r.l. Via I Maggio 8 - 38089 storo (Tn) - ITAlY tel. +39.0465.670104 – fax +39.0465.674965 info@innovaenergie.com...
