- Page 1 IN221200127V01_US 823-039V81 Mobile air conditioner IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY ASSEMBLY INSTRUCTION...
- Page 2 CONTENTS Safety--------------------------------------------------------------------1 Identification of parts--------------------------------------------------10 Control panel Remote-------------------------------------------------11 controller Protection-------------------------------------------------- Maintenance-----------------------------------------------------------16 Trouble shooting ------------------------------------------------------14 Installation Accessories and Select the best location-------------------------19 Installation - 20 Install Exhaust Hose and Adapter--------------------------------- Technical Specification---------------------------------------------- 23...
- Page 3 General information Reading and storing the user manual This user manual belongs to this portable air conditioner (referred to as the “product” below). It contains important information on how to set up and use the product. Before using the product, read the user manual carefully. This particularly applies to the safety instructions.
- Page 4 Caution, risk of fire! Safety Signal symbol/word definitions The following symbols and signal words are used in this user manual. This signal symbol/word designates a hazard WARNING! with a moderate risk, which may result in death or severe injury if not avoided. This signal word warns of possible damage to NOTICE! property.
- Page 5 − Do not splice the power cord. Do not under any circumstances cut or remove the third ground prong from the power cord. − Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. −...
- Page 6 − WARNING – Improper use of the grounding plug can result in a risk of electric shock. Consult a qualified electrician or service agent if the grounding instructions are not completely understood, or if doubt exists as to whether the product is properly grounded.
- Page 7 Safety Awareness VERY IMPORTANT! Please do not install or use your portable air conditioner before you have carefully read this manual. Please keep this instruction manual for an eventual product warranty and for future reference. WARNING! Risk of electric shock! A faulty electrical installation, excessive line voltage, or incorrect operation may result in an electric shock.
- Page 8 − Never move, pull, or carry the product by its power cord. − Keep the product and the power cord away from open flames and hot surfaces. − Lay the power cord so that it does not pose a tripping hazard. −...
- Page 9 − Do not store or use combustible materials such as gasoline or other flammable vapors or liquids in the vicinity of this or any other appliances. − If the product is used in an unventilated area, the area shall be constructed so that should any refrigerant leak, it will not stay stagnate so as to create a fire or explosion hazard.
- Page 10 WARNING! Risk of explosion, leakage or health hazard! Improper handling of the batteries may result in explosion, leakage or personal injury. − WARNING: Do not ingest battery – Chemical burn hazard! Keep batteries away from children. − If the battery compartment does not close securely, stop using the remote control and keep it away from children.
- Page 11 − Under abusive conditions, liquid may be ejected from the battery; avoid contact. Liquid ejected from the battery may cause irritation or burns. − If battery fluid comes into contact with skin, eyes or mucous membrane, wash and rinse the affected area immediately with clean water.
- Page 12 Identification of parts Lower drain port Upper drain port POWER m o m MODE SPEED s S LEEP TIMER SWING The figures in this manual are based on the external view of a standard model. However, the shape may differ from that of the air conditioner you have selected.
- Page 13 Control Panel This section explains how to use this appliance. Indicators High fan speed Low fan speed Middle fan speed Automatic swing Cool Timer off Dehumidify Timer on Automatic Control Panel Operation ● Automatic, cool,fan and dehumidify. 1. Turn on the unit a) Plug in - the unit beeps once.
- Page 14 To Shift the unit between Celsius and Fahrenheit, hold simultaneously when the appliance is on. The corresponding indicator of °C and °F will light up. 4. Adjust Fan Speed Press the to select a desired fan speed, as shown below. 5.
- Page 15 ● Sleep mode 1. The operation is effective when the unit is under mode. 2. Press the button in mode, then the unit will work under sleep mode and the up centrifugal fan will turn to the low speed automatically (the speed icon light remains on the previous setting) .
- Page 16 Remote controller Inserting and replacing the batteries WARNING! Choking hazard! If children or animals swallow the batteries, there is a high health and choking hazard. − Keep the battery out of reach of children. − If you suspect a battery to have been swallowed, seek immediate medical attention.
- Page 17 Protection Operating condition Cooling Dehumidifying Features of protector ● ● Drain water Special reminder: There is condensing water within this unit. The water is partly kept between the condenser and water plate. When the water level rises to the upper level, the float switch and water full indicator (E4) lights on - this is a reminder to drain the water.
- Page 18 1. If the appliance is not being used for long periods, pull out the primary and secondary rubber plug from the port, so the water can drain. 2. Keep the appliance running with the fan for half a day, so the inside can dry and prevent mould.
- Page 19 The following cases may not always be a malfunction, please check suggestions below before asking for service. - The protector trip or fuse has blown. - Wait for three minutes and start again - the protector device may prevent the unit from working.
- Page 20 11A/115V AC...
- Page 21 Installation Installation accessories POWER COOL SPEED DEHUMIDIFY TIMER SWING - Beside a window or door. - There must be at least 60 cm of space between all sides of the unit and the wall. - Fix one end of the air hose to the air outlet, which is on the underside of the appliance.
- Page 22 How to connect the connectors to the Air exhaust duct 1. Extend the air exhaust duct by drawing out the two ends of the duct. 2. Screw the air exhaust duct into its connector. 3. Screw the connector of window into the plastic connector. 4.
- Page 23 Fig. 6...
- Page 25 Technical specifications 823-039V81CW(FDP35-3031ZPV1R3) (Ashare) 12000Btu/h (SACC) 8000Btu/h 400m /h 115V~/60Hz L PA ：54dB(A) ：65dB(A) L44*D33.5*H66.5cm 468X378X870mm 29.0kg CEER 7.22 If you have any questions, please contact our customer care center. Our contact details are below: 001-877-644-9366 customerservice@aosom.com Imported by Aosom LLC 27150 SW Kinsman Rd Wilsonville, OR 97070 USA MADE IN CHINA...
