Care & Maintenance - Echelon STRIDE-8s Instruction Manual

C A R E & M A INTEN A NCE
CARE & MAINTENANCE
Daily
1. Power off the treadmill and clean any high-use areas, like
the handlebars and console, with a non-acidic cleaner (NO
ammonia, chlorine, or alcohol) on a soft cloth. Do not spray
cleaning solution directly on the treadmill as that could ruin
any electrical components.
2. Inspect the power cord for damage. If damaged, replace
immediately by contacting Customer Service (833-937-2453).
Note: When the treadmill is not in use, unplug and store the
power cord in a secure, dry area and away from children.
3. The safety key and power cord should be removed after each
use so the treadmill is not accidentally powered on when not
in use.
4. Inspect for any noises that could indicate potential issues.
If a troubling noise is indicated please contact Customer
Service (833-937-2453).
Weekly
1. Clean the running belt, console, uprights, and motor cover
with non-acidic cleaners and a soft cloth. Cleaners should be
applied to the cloth and never sprayed onto the equipment
directly.
2. Inspect all the assembled and pre-assembled hardware
and tighten or re-secure as-needed. This includes but is not
limited to the following:
a. Handlebars & Uprights
b. Tablet
c. Running Belt
3. Dust and vacuum the treadmill and the surrounding area. To
clean underneath the treadmill, turn off the power, fold, and
roll the treadmill to an alternate location. Return the treadmill
to its original location after cleaning.
4. Ensure your app and equipment firmware are up-to-date with
the latest versions.
5. Check the belt for any looseness, this will cause the treadmill
to receive improper info when calculating metrics if it is not
properly tightened. When tightening make sure to adjust
both sides of the rear roller evenly with the provided Allen
Wrench, turning clockwise to tighten.
NOTE: Contact customer service (833-937-2453) if your running deck is damaged or if you are experiencing any issues.
16
ECHELON FITNE S S | S TRIDE- 8 S
Weekly | 2-a
Monthly
Check the alignment on the treadmill running belt by
ensuring it is centered and glides smoothly over the
running deck. Utilize the instructions located in your
user manual for "re-centering" the belt to troubleshoot
and fix. Refer to page 14 for belt adjustment instructions.
1. Start the treadmill at a low speed and test for any
slippage of the belt to ensure the motor is applying
the proper torque.
2. Stop using the treadmill and contact Customer
Service (833-937-2453) if you hear rubbing noises
or if the belt is off-center and can't be recentered
using the instructions..
3. Lubricate the running deck every 1-2 months
depending on usage or 500 miles/km
(whichever comes first) per the provided steps.
TROUBLESHOOTING
Troubleshooting
Ensure RS232 cable is fully inserted and secured to the tablet.
DC IN Port
1. Ensure safety key is fully inserted.
RS232
2. Ensure the AC power cord that runs
from the wall outlet to the front of the
treadmill motor cover is plugged in on both sides.
3. If screen does not turn on, make sure the
DC power plug that comes from the tablet is
properly plugged into the DC IN port.
4. Retry pairing. If treadmill will not pair, please
contact Customer Service (833-937-2453)
for further assistance.
Incline Calibration
From time to time it is necessary to perform an incline
calibration, on the treadmill if for any reason the incline
motor automatically sets itself to a certain level or
refuses to reset to the zero position.
Safety Magnet (Removed)
The treadmill stops automatically when the safety magnet
is pulled from the slot.
a. Running belt comes to a complete stop.
b. Incline level remains in current position and will not
automatically return to level 0.
c. Any class that is currently in-progress will pause with an
on-screen prompt until the safety magnet is re-inserted
into the slot.
d. "SAFETY KEY IS PULLED. Insert the safety magnet to
resume your workout."
INS TRUC TION M A NUA L
To do this follow these instructions:
• Make sure you are off the treadmill.
• Remove the safety key from the inserted position.
• Hold the start/stop button for 10 seconds. The treadmill will
reprogram the incline motor to its default setting.
• Once the treadmill has gone through the incline and decline
process, re-insert the safety key and resume using.
Safety Magnet (Inserted)
The treadmill will not automatically start when the safety magnet
is inserted.
a. The on-screen prompt will update and allow the current class
to resume: "SAFETY KEY IS PLUGGED IN. Pressing resume
will start treadmill and class playback."
17
