PR ODUC T USE

PRODUCT USE

Membership
Activation
Required
to Unlock
the Echelon
Stride-8s
Treadmill
Experience
Connecting to the Echelon Fit
®
App
1. Ensure your treadmill and tablet (screen) are both
powered on.
a.
The power cord should be plugged into the wall and the
base of the treadmill.
b.
The screen should be plugged into the treadmill via the DC
cable coming from the tablet mount base as well as the
USB or UART port on applicable Echelon equipment.
c.
You may need to power on the screen by pushing the red
power button located on the back right side.
Console Display
12
ECHELON FITNE S S |
S TRIDE- 8 S
Activate Echelon Premier Membership
to connect to classes.
You should have received an activation email after purchasing this
product.
a.
Follow the link from the activation email.
b.
Choose "Sign Up Now" and follow the prompts to complete
your membership enrollment.
2. Echelon Fit® App.
a.
Use the email and password used to create your
membership account.
b.
Select user (there may only be one option).
3. Select a class.
a.
We recommend a "Welcome Run", but any class will work.
b.
Press play.
Hand Pulse
Incline
One Key
/Vol
Start / Stop
Tracking
Ball
Fast Toggle Key
Incline / Vol
1.
One-Key Start/Stop Button:
Start/Pause/Stop, the LED lights will auto change color: "Stop" red light steady on; "Start" green light steady on;
"Counts down 3-2-1" green light flashes; "Pause" red and green lights flash alternatively; "Magnet safety key pulled out" red light flashes. To get
started, power on treadmill and login to Echelon Fit® App. Select your desired class (we recommend a "Welcome" class), and click 'Play'; after the
class ends, the Stride-8s will automatically stop.
To "Start"/"Pause"/"Stop" the treadmill, use the following touch structure: "Start"/"Stop" press (1) time, the treadmill will begin when the green
light is steadily on. "Pause" press (2) times, the treadmill will pause with red and green flashing alternately. "Stop" press the "One-Key" a second
time and the treadmill will stop with a steady red light. Pressing the "One-Key" a third time from either "Pause" or "Stop" status, and the treadmill
will start.
2.
Fan Key:
When the treadmill is powered on, press (1) time for Level 1; Press (2) times for Level 2; Press (3) times for fan to stop.
3.
Left Tracking Ball - Incline/Sound Volume:
The LED blue light indicates that tracking ball is in "Incline" status. Move the ball forward to
increase the incline. Move the ball backwards to decrease the incline. To switch to "Sound Volume", press the "Fast Toggle Key" from incline (blue
light) to sound/volume. LED green light will indicate it's in the "Sound Volume" status. Move the ball forward to increase the volume, move the ball
backwards to decrease the volume.
4.
Right Tracking Ball - Speed:
The LED blue light indicates that the incremental speed will be increased by 0.1 MPH each time. Move the tracking
ball forward to increase speed and backwards to decrease speed. Press the "Fast Toggle Key" on the right by the tracking ball to change the
incremental speed amount. When the LED green light is on, the speed will be increased by 1 MPH each time. Move the tracking ball forwards to
increase speed and backwards to decrease speed.
5.
Magnet Safety Key:
Pull the "Safety Key" out to immediately stop the Stride-8s Treadmill. A flashing LED red light will indicate this has been
pulled out. When the "Safety Key" is inserted back in, the LED red light will stay steady. Press the "One-Key" "Start" or "Stop" to restart the treadmill.
On the screen a "Resume Workout" button will appear, which you may also press to restart the treadmill. When using the treadmill attach the clip
end of the lanyard to the most rigid piece of fabric on your person. This will ensure your safety if you ever fall while using the treadmill.
6.
Hand Pulse Sensors:
While using the Stride-8s, place both hands on the "Hand Pulse" bars on the handlebars. The heart rate will be displayed
on the screen. Note: This is not specific medical data and is only for workout references. Should you feel dizzy, fatigued, etc. IMMEDIATELY stop
the treadmill and seek a medical personnel.
INS TRUC TION M A NUA L
Fan Key
Wireless Charging
Hand Pulse
Speed
Tracking Ball
Magnetic
Safety Key
Fast Toggle Key
Speed: .01/1 mph
increment
13
