ASD -LSTL-H01W-D3CC-WH Manual

LED STEP LIGHT
DESIGN - LED STEP LIGHT has a sleek, low-profile design with no visible
▶
hardware, allowing it to seamlessly blend into any setting. Durable waterproof
housing resistant to rust and can be used indoor and outdoor for all weather
conditions. It is designed to operate on 120V circuits.
COLOR SELECTABLE - You can choose either a 3,000K warm white,
▶
4,000K cool white or 5,000K daylight color temperature.
PHOTOCELL - The built-in Dusk to Dawn Photocell will automatically turn
▶
the fixture on/off depending on the time of day.
MOTION SENSOR - The built-in motion sensor will turn off the fixture
▶
automatically when no motion is detected.
PHOTOCELL AND MOTION SENSOR - When motion is detected the
▶
built-in motion sensor turns on the fixture. During the daytime the preinstalled PC
deactivates the motion sensor.
APPLICATION - This fixture is rated for Wet Locations, making it perfect
▶
for indoor and outdoor projects such as stairways, pathways, corridors, walkways,
building perimeters or anywhere else landscape lighting is required.
ADVANTAGES - With a lifespan of 50,000 hours, these fixtures are made
▶
to last decades under normal operation! ASD provides a 5-year limited warranty
along with ETL certification to guarantee top quality products and safety!
Model Watts
ASD-LSTL-H01W-D3CC-WH 3W
ASD-LSTL-H01W-D3CC-WH-4PACK 3W
ASD-LSTL-H01W-D3CC-BZ 3W
ASD-LSTL-H01W-D3CC-BZ-4PACK 3W
ASD-LSTL-H01W-D3CC-BK 3W
ASD-LSTL-H01W-D3CC-BK-4PACK 3W
ASD-LSTL-H01W-N3CC-MS-WH 3W
ASD-LSTL-H01W-N3CC-MS-BZ 3W
ASD-LSTL-H01W-N3CC-MS-BK 3W
ASD-LSTL-H01W-N3CC-PC-WH 3W
ASD-LSTL-H01W-N3CC-PC-BZ 3W
ASD-LSTL-H01W-N3CC-PC-BK 3W
ASD-LSTL-H01W-N3CC-PC-MS-WH 3W
ASD-LSTL-H01W-N3CC-PC-MS-BZ 3W
ASD-LSTL-H01W-N3CC-PC-MS-BK 3W
ASD LIGHTING CORP
E-mail: orders@asd-lighting.com
Voltage Dimmable Lumens
120 V TRIAC 98/103/114 lm 3CCT (3,000/4,000/5,000 K)
120 V TRIAC 98/103/114 lm 3CCT (3,000/4,000/5,000 K)
120 V TRIAC 98/103/114 lm 3CCT (3,000/4,000/5,000 K)
120 V TRIAC 98/103/114 lm 3CCT (3,000/4,000/5,000 K)
120 V TRIAC 98/103/114 lm 3CCT (3,000/4,000/5,000 K)
120 V TRIAC 98/103/114 lm 3CCT (3,000/4,000/5,000 K)
LSTL-MS WITH MOTION SENSOR
120 V - 98/103/114 lm 3CCT (3,000/4,000/5,000 K)
120 V - 98/103/114 lm 3CCT (3,000/4,000/5,000 K)
120 V - 98/103/114 lm 3CCT (3,000/4,000/5,000 K)
LSTL-PC WITH PHOTOCELL
120 V - 98/103/114 lm 3CCT (3,000/4,000/5,000 K)
120 V - 98/103/114 lm 3CCT (3,000/4,000/5,000 K)
120 V - 98/103/114 lm 3CCT (3,000/4,000/5,000 K)
LSTL-PC-MS WITH MOTION SENSOR AND PHOTOCELL
120 V - 98/103/114 lm 3CCT (3,000/4,000/5,000 K)
120 V - 98/103/114 lm 3CCT (3,000/4,000/5,000 K)
120 V - 98/103/114 lm 3CCT (3,000/4,000/5,000 K)
Web site: www.asd-lighting.com
Catalog number
Notes
Type
White
Finish: Bronze
Black
CCT Finish Dimensions (LxWxH)
White 4-3/4" x 1-9/16" x 2-13/16"
White 4-3/4" x 1-9/16" x 2-13/16"
Oil rubbed bronze 4-3/4" x 1-9/16" x 2-13/16"
Oil rubbed bronze 4-3/4" x 1-9/16" x 2-13/16"
Black 4-3/4" x 1-9/16" x 2-13/16"
Black 4-3/4" x 1-9/16" x 2-13/16"
White 4-3/4" x 1-3/4" x 2-13/16"
Oil rubbed bronze 4-3/4" x 1-3/4" x 2-13/16"
Black 4-3/4" x 1-3/4" x 2-13/16"
White 4-3/4" x 1-9/16" x 2-13/16"
Oil rubbed bronze 4-3/4" x 1-9/16" x 2-13/16"
Black 4-3/4" x 1-9/16" x 2-13/16"
White 4-3/4" x 1-3/4" x 2-13/16"
Oil rubbed bronze 4-3/4" x 1-3/4" x 2-13/16"
Black 4-3/4" x 1-3/4" x 2-13/16"
For most up-to-date spec sheets please refer to asd-lighting.com
English
Option
-
-
-
-
-
-
Motion sensor
Motion sensor
Motion sensor
Photocell
Photocell
Photocell
Motion sensor, Photocell
Motion sensor, Photocell
Motion sensor, Photocell
