ASD -LWS27-18D18CC-WH Manual

LED OUTDOOR WALL SCONCE
DESIGN - LED OUTDOOR WALL SCONCE has a modern,
▶
multipurpose design and a stylish look with efficient lighting. Durable
housing resistant to rust and impact provides many years of service. The
acrylic lens with a 350° beam angle grants you even light distribution. It
is designed to operate on 120-277V circuits and provides smooth triac
dimming capabilities ranging from 10% to 100%.
COLOR SELECTABLE - You can choose either a 3,000K warm
▶
white, 4,000K cool white or 5,000K daylight color temperature.
INSTALLATION - Quick and easy installation, the fixture can be
▶
installed on standard 2.75" or 3.5" outlet box. The additional mounting
holes provide secure installation options.
APPLICATION - The fixture is rated for Wet Locations, making
▶
it perfect for indoor and outdoor projects such as decks, front doors,
porches, patios, corridors, walkways, or any other common areas.
ADVANTAGES - With a lifespan of 50,000 hours, these fixtures
▶
are made to last decades under normal operation! ASD provides a 5-year
limited warranty along with ETL certification to guarantee top quality
products and safety!
Model Size
ASD-LWS27-18D18CC-WH 18 inch
ASD-LWS27-MV-18D18CC-BK 18 inch
ASD-LWS27A-18D18BK 18 inch
ASD-LWS27C-18D18BK 18 inch
ASD-LWS27-24D24CC-WH 24 inch
ASD-LWS27-MV-24D24CC-BK 24 inch
ASD-LWS27A-24D24BK 24 inch
ASD-LWS27C-24D24BK 24 inch
ASD-LWS27-36D30CC-WH 36 inch
ASD-LWS27-MV-36D30CC-BK 36 inch
ASD-LWS27A-36D30BK 36 inch
ASD-LWS27C-36D30BK 36 inch
ASD-LWS27-48D36CC-WH 48 inch
ASD-LWS27-MV-48D36CC-BK 48 inch
ASD-LWS27A-48D36BK 48 inch
ASD-LWS27C-48D36BK 48 inch
ASD-LWS27-MV-72D40CC-BK 72 inch
ASD-LWS27A-72D40BK 72 inch
ASD-LWS27C-72D40BK 72 inch
ASD LIGHTING CORP
E-mail: orders@asd-lighting.com
Watts Voltage Dimmable
18W 120 V TRIAC 1,364/1,541/1,430 lm
18W 120-277 V TRIAC 1,404/1,636/1,550 lm
18W 120-277 V TRIAC 1,296/1,573/1,507 lm
18W 120-277 V TRIAC 1,099/1,183/1,186 lm
24W 120 V TRIAC 1,875/2,204/2,061 lm
24W 120-277 V TRIAC 1,810/2,134/2,012 lm
24W 120-277 V TRIAC 1,652/2,001/1,933 lm
24W 120-277 V TRIAC 1,380/1,614/1,637 lm
30W 120 V TRIAC 2,226/2,465/2,304 lm
30W 120-277 V TRIAC 2,318/2,642/2,514 lm
30W 120-277 V TRIAC 2,000/2,356/2,327 lm
30W 120-277 V TRIAC 1,584/1,798/1,856 lm
36W 120 V TRIAC 2,598/2,844/2,685 lm
36W 120-277 V TRIAC 2,595/2,933/2,838 lm
36W 120-277 V TRIAC 2,549/2,980/2,965 lm
36W 120-277 V TRIAC 1,769/1,995/2,108 lm
40W 120-277 V TRIAC 3,374/3,541/3,284 lm
40W 120-277 V TRIAC 3,108/3,577/3,620 lm
40W 120-277 V TRIAC 1,936/2,148/2,338 lm
Web site: www.asd-lighting.com
Catalog number
Notes
Type
Finish: White Black
Lumens CCT
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
For most up-to-date spec sheets please refer to asd-lighting.com
English
Finish Dimensions (LxWxH)
White 18" x 5-7/8" x 1-13/16"
Black 18" x 5-7/8" x 1-13/16"
Black 18" x 5-7/8" x 1-13/16"
Black 18" x 5-7/8" x 1-13/16"
White 24" x 5-7/8" x 1-13/16"
Black 24" x 5-7/8" x 1-13/16"
Black 24" x 5-7/8" x 1-13/16"
Black 24" x 5-7/8" x 1-13/16"
White 36" x 5-7/8" x 1-13/16"
Black 36" x 5-7/8" x 1-13/16"
Black 36" x 5-7/8" x 1-13/16"
Black 36" x 5-7/8" x 1-13/16"
White 48-1/16" x 5-7/8" x 1-13/16"
Black 48-1/16" x 5-7/8" x 1-13/16"
Black 48" x 5-7/8" x 1-13/16"
Black 48" x 5-7/8" x 1-13/16"
Black 72" x 5-7/8" x 1-13/16"
Black 72" x 5-7/8" x 1-13/16"
Black 72" x 5-7/8" x 1-13/16"
