ASD LWS27 Series Manual

LED OUTDOOR WALL SCONCE
LWS27 series
DESIGN - LED OUTDOOR WALL SCONCE has a modern,
▶
multipurpose design and a stylish look with efficient lighting.
Durable housing resistant to rust and impact provides many years
of service. The acrylic lens with a 350° beam angle grants you even
light distribution. It is designed to operate on 120-277V circuits
and provides smooth triac dimming capabilities ranging from 10%
to 100%.
COLOR SELECTABLE - You can choose either a 3,000K warm
▶
white, 4,000K cool white or 5,000K daylight color temperature.
INSTALLATION - Quick and easy installation, the fixture can
▶
be installed on standard 2.75" or 3.5" outlet box. The additional
mounting holes provide secure installation options.
APPLICATION - The fixture is rated for Wet Locations, making
▶
it perfect for indoor and outdoor projects such as decks, front doors,
porches, patios, corridors, walkways, or any other common areas.
ADVANTAGES - With a lifespan of 50,000 hours, these fixtures
▶
are made to last decades under normal operation! ASD provides
a 5-year limited warranty along with ETL certification to guarantee
top quality products and safety!
PRODUCT PRESENTATION:
Model Size
ASD-LWS27-18D18CC-WH 18 inch
ASD-LWS27-MV-18D18CC-BK 18 inch
ASD-LWS27A-18D18BK 18 inch
ASD-LWS27-24D24CC-WH 24 inch
ASD-LWS27-MV-24D24CC-BK 24 inch
ASD-LWS27A-24D24BK 24 inch
ASD-LWS27-36D30CC-WH 36 inch
ASD-LWS27-MV-36D30CC-BK 36 inch
ASD-LWS27A-36D30BK 36 inch
ASD-LWS27-48D36CC-WH 48 inch
ASD-LWS27-MV-48D36CC-BK 48 inch
ASD-LWS27A-48D36BK 48 inch
ASD-LWS27-MV-72D40CC-BK 72 inch
ASD-LWS27A-72D40BK 72 inch
ASD LIGHTING CORP
E-mail: orders@asd-lighting.com
Power Voltage Dimming Lumens
18W 120 V TRIAC up to 1,541 lm
18W 120-277 V TRIAC up to 1,636 lm
18W 120-277 V TRIAC up to 1,573 lm
24W 120 V TRIAC up to 2,204 lm
24W 120-277 V TRIAC up to 2,134 lm
24W 120-277 V TRIAC up to 2,001 lm
30W 120 V TRIAC up to 2,465 lm
30W 120-277 V TRIAC up to 2,642 lm
30W 120-277 V TRIAC up to 2,356 lm
36W 120 V TRIAC up to 2,844 lm
36W 120-277 V TRIAC up to 2,933 lm
36W 120-277 V TRIAC up to 2,980 lm
40W 120-277 V TRIAC up to 3,541 lm
40W 120-277 V TRIAC up to 3,620 lm
Web site: www.asd-lighting.com
Finish: White Black
CCT Finish
3CCT (3,000/4,000/5,000 K) White
3CCT (3,000/4,000/5,000 K) Black
3CCT (3,000/4,000/5,000 K) Black
3CCT (3,000/4,000/5,000 K) White
3CCT (3,000/4,000/5,000 K) Black
3CCT (3,000/4,000/5,000 K) Black 24" x 5-7/8" x 1-13/16"
3CCT (3,000/4,000/5,000 K) White 36" x 5-7/8" x 1-13/16"
3CCT (3,000/4,000/5,000 K) Black 36" x 5-7/8" x 1-13/16"
3CCT (3,000/4,000/5,000 K) Black 36" x 5-7/8" x 1-13/16"
3CCT (3,000/4,000/5,000 K) White 48-1/16" x 5-7/8" x 1-13/16"
3CCT (3,000/4,000/5,000 K) Black 48-1/16" x 5-7/8" x 1-13/16"
3CCT (3,000/4,000/5,000 K) Black 48" x 5-7/8" x 1-13/16"
3CCT (3,000/4,000/5,000 K) Black 72" x 5-7/8" x 1-13/16"
3CCT (3,000/4,000/5,000 K) Black 72" x 5-7/8" x 1-13/16"
For most up-to-date spec sheets please refer to asd-lighting.com
English
Dimensions Certification
18" x 5-7/8" x 1-13/16" ETL (4001256)
18" x 5-7/8" x 1-13/16" ETL (4001256)
18" x 5-7/8" x 1-13/16" ETL (4001256)
24" x 5-7/8" x 1-13/16" ETL (4001256)
24" x 5-7/8" x 1-13/16" ETL (4001256)
ETL (4001256)
ETL (4001256)
ETL (4001256)
ETL (4001256)
ETL (4001256)
ETL (4001256)
ETL (4001256)
ETL (4001256)
ETL (4001256)
