ASD -LWS26S-13D12BK Manual

LED OUTDOOR WALL SCONCE
DESIGN - LED OUTDOOR WALL SCONCE WITH PHOTOCELL AND
▶
RGWB (for indicated models) has a modern, multipurpose design and
a stylish look with efficient lighting. The clear seeded glass shade with
a 180° beam angle filled with air bubbles emits a luxurious glow. It is
designed to operate on 120V or 120-277V (for indicated models) circuits
and provides smooth triac dimming capabilities ranging from 10% to
100%.
COLOR SELECTABLE - You can choose either a 3,000K warm
▶
white, 4,000K cool white or 5,000K daylight color temperature.
RGBW - Indicated fixtures has RGBW design with manual selection
▶
switch on the bottom of the fixture. You can easily select Red, Green, Blue,
Warm White and Daylight White.
PHOTOCELL - The built-in Dusk to Dawn Photocell for indicated
▶
models will automatically turn the fixture on/off depending on the time of
day.
APPLICATION - The fixture is rated for Wet Locations, making
▶
it perfect for indoor and outdoor projects such as decks, front doors,
porches, patios, corridors, walkways, or any other common areas.
ADVANTAGES - With a lifespan of 50,000 hours, these fixtures
▶
are made to last decades under normal operation! ASD provides a 5-year
limited warranty along with ETL certification to guarantee top quality
products and safety!
Model
ASD-LWS26S-13D12BK
ASD-LWS26S-13D12CC-BK
ASD-LWS26S-13D12CC-BK-2PACK
ASD-LWS26S-18D12WH
ASD-LWS26S-18D12CC-WH-2PACK
ASD-LWS26S-18D12BK
ASD-LWS26S-18D12CC-BK
ASD-LWS26S-18D12CC-BK-2PACK
ASD-LWS26S-MV-24D20CC-BK
ASD-LWS26-13N9AC-RGBW-BK
ASD-LWS26-18N9AC-RGBW-BK
ASD-LWS26S-13N12BK-PC
ASD-LWS26S-13N12CC-PC-BK
ASD-LWS26S-13N12CC-PC-BK-2PACK
ASD-LWS26S-18N12BK-PC
ASD-LWS26S-18N12CC-PC-BK-2PACK
For detailed luminous flux information please refer to Annex 1, page 2.
ASD LIGHTING CORP
E-mail: orders@asd-lighting.com
Size Watts Voltage Dimmable
13 inch 11.5W 120 V TRIAC
13 inch 11.5W 120 V TRIAC
13 inch 11.5W 120 V TRIAC
18 inch 11.5W 120 V TRIAC
18 inch 11.5W 120 V TRIAC
18 inch 11.5W 120 V TRIAC
18 inch 11.5W 120 V TRIAC
18 inch 11.5W 120 V TRIAC
24 inch 20W 120-277 V TRIAC
13 inch 8.5W 120-277 V -
18 inch 8.5W 120-277 V -
LWS26S-PC WITH PHOTOCELL
13 inch 11.5W 120 V -
13 inch 11.5W 120 V -
13 inch 11.5W 120 V -
18 inch 11.5W 120 V -
18 inch 11.5W 120 V -
Web site: www.asd-lighting.com
Catalog number
Notes
Type
Lumens CCT
LWS26S
up to 566 lm 3CCT (3,000/4,000/5,000 K)
up to 566 lm 3CCT (3,000/4,000/5,000 K)
up to 566 lm 3CCT (3,000/4,000/5,000 K)
up to 495 lm 3CCT (3,000/4,000/5,000 K)
up to 495 lm 3CCT (3,000/4,000/5,000 K)
up to 495 lm 3CCT (3,000/4,000/5,000 K)
up to 495 lm 3CCT (3,000/4,000/5,000 K)
up to 495 lm 3CCT (3,000/4,000/5,000 K)
up to 581 lm 3CCT (3,000/4,000/5,000 K)
LWS26-RGBW
up to 243 lm Red-Green-Blue-3,000K-5,000 K
up to 190 lm Red-Green-Blue-3,000K-5,000 K
up to 566 lm 3CCT (3,000/4,000/5,000 K)
up to 566 lm 3CCT (3,000/4,000/5,000 K)
up to 566 lm 3CCT (3,000/4,000/5,000 K)
up to 495 lm 3CCT (3,000/4,000/5,000 K)
up to 495 lm 3CCT (3,000/4,000/5,000 K)
For most up-to-date spec sheets please refer to asd-lighting.com
English
White
Finish:
Black
Finish Dimensions (LxWxH)
Black 4-3/4" x 2-1/2" x 13-3/4"
Black 4-3/4" x 2-1/2" x 13-3/4"
Black 4-3/4" x 2-1/2" x 13-3/4"
White 4-3/4" x 2-1/2" x 17-15/16"
White 4-3/4" x 2-1/2" x 17-15/16"
Black 4-3/4" x 2-1/2" x 17-15/16"
Black 4-3/4" x 2-1/2" x 17-15/16"
Black 4-3/4" x 2-1/2" x 17-15/16"
Black 4-3/4" x 2-15/16" x 24"
Black 4-3/4" x 2-7/8" x 13-3/4"
Black 4-3/4" x 2-7/8" x 17-15/16"
Black 4-3/4" x 2-1/2" x 13-3/4"
Black 4-3/4" x 2-1/2" x 13-3/4"
Black 4-3/4" x 2-1/2" x 13-3/4"
Black 4-3/4" x 2-1/2" x 17-15/16"
Black 4-3/4" x 2-1/2" x 17-15/16"
