ASD -OLWS-23-8D12CC-WH Manual

LED OUTDOOR WALL SCONCE
DESIGN - LED OUTDOOR WALL SCONCE has a modern,
▶
multipurpose design and a stylish look with efficient lighting. Durable
housing resistant to rust and impact provides many years of service. The
UV resistant PMMA lens with a 125° beam angle grants you even light
distribution. It is designed to operate on 120V circuits.
PHOTOCELL - The built-in Dusk to Dawn Photocell will
▶
automatically turn the fixture on/off depending on the time of day.
COLOR SELECTABLE - You can choose either a 3,000K warm
▶
white, 4,000K cool white or 5,000K daylight color temperature.
APPLICATION - The fixture is rated for Wet Locations, making
▶
it perfect for indoor and outdoor projects such as decks, front doors,
porches, patios, corridors, walkways, or any other common areas.
ADVANTAGES - With a lifespan of 50,000 hours, these fixtures
▶
are made to last decades under normal operation! ASD provides a 5-year
limited warranty along with ETL certification to guarantee top quality
products and safety!
Model Size
ASD-OLWS-23-8D12CC-WH 8 inch
ASD-OLWS-23-8D12CC-BZ 8 inch
ASD-OLWS-23-8D12CC-BK 8 inch
ASD-OLWS-23-14D20CC-WH 14 inch
ASD-OLWS-23-14D20CC-BZ 14 inch
ASD-OLWS-23-14D20CC-BK 14 inch
ASD-OLWS-23-14N20CC-PC-BZ 14 inch
ASD-OLWS-23-14N20CC-PC-BK 14 inch
ORDERING INFORMATION
Model
ASD-OLWS-23-8D12CC-WH
ASD-OLWS-23-8D12CC-BZ
ASD-OLWS-23-8D12CC-BK
ASD-OLWS-23-14D20CC-WH
ASD-OLWS-23-14D20CC-BZ
ASD-OLWS-23-14D20CC-BK
ASD-OLWS-23-14N20CC-PC-BZ
ASD-OLWS-23-14N20CC-PC-BK
ASD LIGHTING CORP
E-mail: orders@asd-lighting.com
Watts Voitage Dimmable Lumens
12W 120 V TRIAC 805/909/842 lm
12W 120 V TRIAC 805/909/842 lm
12W 120 V TRIAC 805/909/842 lm
20W 120 V TRIAC 1,703/1,909/1,758 lm
20W 120 V TRIAC 1,703/1,909/1,758 lm
20W 120 V TRIAC 1,703/1,909/1,758 lm
OLWS-23-PC WITH PHOTOCELL
20W 120 V - 1,703/1,909/1,758 lm
20W 120 V - 1,703/1,909/1,758 lm
UPC Pcs. per carton
810050737784 4
810050737777 4
810050738842 4
810050737791 4
810050736442 4
810050738859 4
OLWS-23-PC WITH PHOTOCELL
810050736756 4
810128110532 4
Web site: www.asd-lighting.com
Catalog number
Notes
Type
Finish:
CCT Finish
3CCT (3,000/4,000/5,000 K) White
3CCT (3,000/4,000/5,000 K) Oil rubbed bronze
3CCT (3,000/4,000/5,000 K) Black
3CCT (3,000/4,000/5,000 K) White
3CCT (3,000/4,000/5,000 K) Oil rubbed bronze
3CCT (3,000/4,000/5,000 K) Black
3CCT (3,000/4,000/5,000 K) Oil rubbed bronze
3CCT (3,000/4,000/5,000 K) Black
Carton size Carton weight
13.2" x 7.3" x 9.1" 10.6 lbs
13.2" x 7.3" x 9.1" 10.6 lbs
13.2" x 7.3" x 9.1" 10.6 lbs
13.2" x 7.3" x 15" 13.2 lbs
13.2" x 7.3" x 15" 13.2 lbs
13.2" x 7.3" x 15" 13.2 lbs
13.2" x 7.3" x 15.8" 13.6 lbs
13.2" x 7.3" x 15.8" 13.6 lbs
For most up-to-date spec sheets please refer to asd-lighting.com
English
White Bronze Black
Dimensions (LxWxH) Option
6" x 3-1/8" x 8" -
6" x 3-1/8" x 8" -
6" x 3-1/8" x 8" -
6" x 3-1/8" x 14" -
6" x 3-1/8" x 14" -
6" x 3-1/8" x 14" -
6" x 3-1/8" x 14-5/8" Photocell
6" x 3-1/8" x 14-5/8" Photocell
GTIN 14
10810050737781
10810050737774
10810050738849
10810050737798
30810050736443
10810050738856
30810050736757
10810128110539
