ASD -LWS27C-18D18BK Manual

LED OUTDOOR WALL SCONCE
DESIGN - LED OUTDOOR WALL SCONCE has a modern,
▶
multipurpose design and a stylish look with efficient lighting. Durable
housing resistant to rust and impact provides many years of service. The
acrylic lens with a 350° beam angle grants you even light distribution. It
is designed to operate on 120-277V circuits and provides smooth triac
dimming capabilities ranging from 10% to 100%.
COLOR SELECTABLE - You can choose either a 3,000K warm
▶
white, 4,000K cool white or 5,000K daylight color temperature.
INSTALLATION - Quick and easy installation, the fixture can be
▶
installed on standard 2.75" or 3.5" outlet box. The additional mounting
holes provide secure installation options.
APPLICATION - The fixture is rated for Wet Locations, making
▶
it perfect for indoor and outdoor projects such as decks, front doors,
porches, patios, corridors, walkways, or any other common areas.
ADVANTAGES - With a lifespan of 50,000 hours, these fixtures
▶
are made to last decades under normal operation! ASD provides a 5-year
limited warranty along with ETL certification to guarantee top quality
products and safety!
Model Size
ASD-LWS27C-18D18BK 18 inch
ASD-LWS27C-24D24BK 24 inch
ASD-LWS27C-36D30BK 36 inch
ASD-LWS27C-48D36BK 48 inch
ASD-LWS27C-72D40BK 72 inch
PRODUCT SPECIFICATIONS:
Construction & Materials
Housing Steel
Lens Acrylic
Finish Black
ASD-LWS27C-18D18BK
ASD-LWS27C-24D24BK
Weight ASD-LWS27C-36D30BK
ASD-LWS27C-48D36BK
ASD-LWS27C-72D40BK
Environmental system
Work environment Suitable for Wet Locations
Operating temperature -40℉ to 113℉ (-40℃ to 45℃)
L-70 Life > 50,000 hrs
Optical system
ASD-LWS27C-18D18BK
ASD-LWS27C-24D24BK
Luminous flux ASD-LWS27C-36D30BK
ASD-LWS27C-48D36BK
ASD-LWS27C-72D40BK
Color temperature 3CCT switch (3,000/4,000/5,000 K), 3,000 K by default
CRI > 80
Dimming range
10-100%
ASD LIGHTING CORP
E-mail: orders@asd-lighting.com
Watts Voltage Dimmable
18W 120-277 V TRIAC 1,099/1,183/1,186 lm
24W 120-277 V TRIAC 1,380/1,614/1,637 lm
30W 120-277 V TRIAC 1,584/1,798/1,856 lm
36W 120-277 V TRIAC 1,769/1,995/2,108 lm
40W 120-277 V TRIAC 1,936/2,148/2,338 lm
Dimming compatible controls
Brand
5.1 lbs (2.3 kg) Models
6.9 lbs (3.1 kg)
10.1 lbs (4.6 kg)
13.7 lbs (6.2 kg) Regular and voluntary certifications
21.6 lbs (9.8 kg) 5-year limited warranty
1,099/1,183/1,186 lm
1,380/1,614/1,637 lm
1,584/1,798/1,856 lm
1,769/1,995/2,108 lm
1,936/2,148/2,338 lm
Web site: www.asd-lighting.com
Catalog number
Notes
Type
Lumens CCT
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
3CCT (3,000/4,000/5,000 K)
Lutron
MACL-153MLH-WH
STCL-153PH-WH
PD-6WCL-WH-R
DVCL-153PR
P-PKG1W
cETLus certified 4001256
PACKAGE CONTENTS:
Description Q-ty
LED Outdoor Wall Sconce 1
Mounting plate (A) 1
Mounting screw (B) 2
Self-tapping screw (C) 2
Fixture screw (D) 4
Wire nut (E) 3
Waterproof gasket (F) 4
Anchor (G) 2
Box 1
For most up-to-date spec sheets please refer to asd-lighting.com
English
Finish Dimensions (LxWxH)
Black 18" x 5-7/8" x 1-13/16"
Black 24" x 5-7/8" x 1-13/16"
Black 36" x 5-7/8" x 1-13/16"
Black 48" x 5-7/8" x 1-13/16"
Black 72" x 5-7/8" x 1-13/16"
Leviton
R02-DW6HD-2RW
R00-RNL06-0TW
R68-06674-P0T
DSL06
A B D
E
C F
G
