- Page 1 O WN E R ’ S MA N U A L...
- Page 2 SRV 700 USER MANUAL Details described or illustrated in this booklet may differ from the vehicle's actual specification as pur- chased, the accessories fitted or the national-market specification. No claims will be asserted as a result of such discrepancies. Dimensions, weights, fuel consumption and performance data are quoted to the customary tolerances. The right to modify designs, equipment and accessories is reserved.
-
Page 4: Table Of Contents
Table of Contents Motorcycle Safety............4 Rearview mirror adjustment ........19 Safe driving rules............4 USB Interface............19 Protective clothing ............5 Instructions for Fuel and Engine Oil ......19 Wearing a safety helmet..........5 Fuel ................19 Precautions for riding on rainy days ......5 Engine oil .............. - Page 5 Engine oil level and oil change......... 27 Storage Guide ...............45 Replacement of engine oil and oil filter ....27 Storage ..............45 Spark plug ..............28 Use of the motorcycle after storage......46 Adjustment of accelerator cable ....... 28 SRV 700 Technical Specifications ........46 Clutch adjustment ............
- Page 6 3. Please read this manual carefully. Careful and patient running-in of a new motorcycle enables the QJmotor Co., Ltd. will be in persistent pursuit of motorcycle to run stably at the excellent perfor- “making consumers more satisfied”. Please under-...
- Page 7 Caution injury or equipment damage. motorcycle to the QJMOTOR Service Center for check. You can ride it only after troubleshooting. Information to help you better use Notice your motorcycle.
- Page 8 • Do not damage the fuse holder when replacing arbitrarily change its registered construction, struc- the fuse. Otherwise, poor contact, damage to ture or characteristics. The QJMOTOR will not bear components or even fire accidents will occur. any quality problems and consequences (including...
-
Page 9: Motorcycle Safety
Motorcycle Safety 7. Be careful at intersections, entrances, and exits of parking lots and on fast lanes. Safe driving rules 8. Refitting the motorcycle or removing the genuine 1. You must inspect the motorcycle before driving parts without permission will not guarantee driv- to avoid accidents and damage to the parts. -
Page 10: Protective Clothing
Precautions for riding on rainy days 12.Do not overload the motorcycle when riding. Overloading can cause failure of parts and com- Pay special attention to the longer braking distance ponents and seriously affect stability, maneuver- due to wet and slippery roads on rainy days. Please ability and performance, possibly resulting in avoid paint, manhole covers, and greasy roads death or serious injuries. - Page 11 Vehicle identification number: Engine number:...
-
Page 12: Part Name
Part Name 1 Left/right rearview mirror 2 Clutch lever 3 Left handlebar switch 4 Instrument panel 5 Ignition switch 6 Front brake reservoir 7 Right handlebar switch 8 Front brake lever 9 Accelerator grip 0 Fuel tank cap... - Page 13 A Rear brake fluid reservoir (inside of guard) B Oil filler C Rear brake pedal D Driver footrest E Passenger footrest F Side stand G Shift lever H Front brake I Driver seat lock hole J Rear brake K Rear wheel ABS wheel speed sensor L Front wheel ABS wheel speed sensor M Passenger armrest (pulling strap) Notice...
-
Page 14: Instrument Panel
If the light is on, the motor- cycle has a fault and needs to be stopped for inspection. Please contact the QJMOTOR Service Center or Maintenance Department to check the motorcycle in time. - Page 15 account and a password (only 5G frequency bands mally on when the mobile phone Bluetooth is suc- are supported) or an iPhone is successfully paired by cessfully paired and connected. After the instrument connecting the instrument panel WIFI, the WIFI indi- panel is connected with the mobile phone Bluetooth, cator light illuminates in blue.
- Page 16 It indicates the fuel capacity stored in the tank. water temperature warning light is on. Please stop When the fuel tank is full, it will display 6 indicating for inspection, or contact the QJMOTOR Service marks. If the indicating mark approaches mark E, Center to check the motorcycle.
-
Page 17: Instrument Panel Adjusting Button
See“Instrument Panel adjusting but- It displays the alarm message content. Please stop ton” for details. for checking or contact the local QJMOTOR Service I Gear position indicator Center to check the motorcycle. It indicates the current gear position of the motor-... -
Page 18: Operation Of Parts
Operation of parts Under the state of the relative mileage (TRIP A and TRIP B), press and hold “SELECT” to clear the sub- Keys total relative mileage. Under the state of the total Two folding keys or three keys mileage (TOTAL), press and hold “SELECT” to (including one folding key or two switch the mileage and the unit display of the motor- mechanical keys) are optional for... -
Page 19: Ignition Switch
Ignition switch Left handlebar 1 Clutch lever “ ” mark - When the key is turned to the “ ” mark When starting the engine or position, the power is off, and the engine cannot be shifting gears, hold the clutch started, but the key can be removed;... -
Page 20: Clutch Lever Adjuster
tivate the turn signal, move the turn signal light ment may be made by choosing one of four posi- switch to the center or press the switch downward tions. To adjust, move the clutch lever forwards hor- again. izontally, and then rotate the ring nut adjuster for alignment with the arrow (A) to get the desired posi- Warning tion. -
Page 21: Refueling
QJMOTOR Service Center for inspections. pull and open the fuel tank cap together with the key. 4 Accelerator grip... -
Page 22: Shift Lever
For canister as soon as possible at the QJMOTOR Ser- engaging the neutral position, depress or move vice Center, because excessive gasoline entering... -
Page 23: Rear Brake Pedal
Caution Notice When the transmission is placed at the neutral Do not support the vehicle on an inclined slope. Oth- position, the neutral indicator light on the instru- erwise, the vehicle may roll over. Please check the ment panel will come on. Now, still slowly release position of the side stand before parking the vehicle. -
Page 24: Rollover Automatic Shutdown
QJMOTOR will affect mobile phones and other components. the warranty of the vehicle). Please go to the QJMO-... -
Page 25: Running-In
QJMOTOR only provides special engine ning-in. As long as the recommended maximum oil to QJMOTOR Service Center. The engine oil vis- speed limit is not exceeded, each gear position can cosity should be determined according to the tem- be engaged to accelerate the engine, but the maxi- perature in the riding area. -
Page 26: Inspections Before Driving
• Appropriate tread depth • No cracks or damages After the initial running-in to 1000 km, please con- tact the QJMOTOR Service Center to replace the Filled with sufficient fuel for the planned Fuel oil level oil filter, change the oil, clean the filter screen, etc. -
Page 27: Riding A Motorcycle
Warning Inspection item Key points of inspection The exhaust contains harmful substances such as • Proper clearance of the accelerator cable Accelerator carbon monoxide. Inhalation of these hazardous • To ensure smooth acceleration and deceleration substances can cause serious injuries or even death. Do not start the engine in a poorly ventilated or •... -
Page 28: Use Of Transmission
The transmission can ensure that the engine may run The braking system is an important safety compo- smoothly within the normal operating range. The nent. Please contact the local QJMOTOR Service driver should select the most appropriate gear posi- Center for repair or replacement of the braking tion for the general conditions. -
Page 29: Inspection And Maintenance
Inspection and maintenance The following table shows the scheduled maintenance time limit for the mileage (km) traveled. At the end of each time limit, inspection, check, lubrication and prescribed maintenance must be carried out in accordance with the specified methods. The steering gear system, center and side stands as well as wheel system are key components and should be carefully repaired by specialized personnel. - Page 30 Interval Maintenance Odometer reading (Note 2) Content mileage Remarks 1000 km 6000km 12000km 18000km 24000km 30000km Maintenance item Oil screen Cooling system Drive chain Note 3 Every 1000 km: I, L, A Drive belt Note 3 I, A I, A I, A Brake pad wear Brake system...
- Page 31 Interval Maintenance Odometer reading (Note 2) Content mileage Remarks 1000 km 6000km 12000km 18000km 24000km 30000km Maintenance item Wheel/wheel rim Note 3 Steering gear Instructions: I: Inspection, cleaning, adjustment, lubrication or replacement C: Cleaning R: Replacement A: Adjustment L: Lubrication * represent that it must be overhauled by the distribution department: You should bring your own qualified tools and motor- cycle inspection data, and the part shall be overhauled by those holding the mechanical certificate.
-
Page 32: Engine Oil Level And Oil Change
Engine oil level and oil change 1. When draining the oil, put the oil basin below the oil Check the engine oil level drain position and remove before starting the engine. the drain bolt 1. After When checking the oil level, completely draining the keep the motorcycle upright oil from the tank, reinstall... -
Page 33: Spark Plug
Spark plug Notice For the initial 1000 km and every Please do not remove the O-ring seal of the oil fil- 6000 km traveled, use a small ter, as this will cause incorrect installation of the O- metal brush or spark plug cleaner to ring seal, which will result in oil leakage or engine remove carbon... -
Page 34: Clutch Adjustment
• Adjust the nut 4 so that the throttle grip can ate range. If adjustment is required, please contact rotate flexibly. a professional repair shop or the QJMOTOR Ser- vice Center. • Tighten the lock nut 3. -
Page 35: Throttle Body
Throttle body chain and sprocket. Under harsh use, maintenance must be carried out frequently. The idling speed of the motorcycle will be reduced Drive chain adjustment: due to the pollution of the throttle body. Clean the Inspect chain slack and wheel throttle body every 5000 km traveled. - Page 36 Adjust the chain as follows: Wrong example Correct example 1. Support the motorcycle on its side stand. 2. Loosen the rear axle nut 1. 3. Loosen the left and right lock nuts 2. 6. Tighten the left and right lock nuts. Re-tighten 4.
-
Page 37: Drive Belt
During routine inspection, check the chain for: as wounds and cracks on the belt, and clean up the silt, gravel and other impurities in the belt teeth or on • loose pins its surface in time. • damaged roller Alignment is required for installing the belt. The par- •... - Page 38 ley. Then tighten the rear wheel lock nut. 4. Rotate the adjusting nut 3 to adjust the rear 7. Re-confirm the belt frequency. Rotate the rear wheel to the belt mount- tire 1/4 turn (90°) successively and the rear ing position (minimum wheel at least 2 turns.
-
Page 39: Brakes
1. The free stroke at the end may be different. If the belt needs to be replaced, of the front brake lever please contact the local QJMOTOR Service Cen- should is 10 to 20 mm. ter. Please do not use other brands of belts to avoid dangerous accidents. - Page 40 Friction plate and the fluid level will decrease. The front brake fluid reservoir is installed above the right handlebar, Front Rear and the rear fluid reservoir is installed in the middle of the right side of the motorcycle (in the guard). Ensure that the brake fluid level is between the MIN and MAX marks.
-
Page 41: Tire
for leakage. Tire 3. Check whether there is a suitable stroke of the Correct tire pressure will ensure the brake lever and that of the brake foot lever, and highest stability, ride comfort, and tire whether they are always reliably connected. durability. -
Page 42: Installation And Removal Of Driver Seat
of the seat into the corresponding limit slot, align the Warning lock hook with the lock hole, and then press down Improper tire inflation will cause abnormal tread on the rear of the seat. wear and therefore threaten safety. Insufficient tire Air filter maintenance inflation may cause tire slippage or disengage- Maintain the air filter regularly, and more frequently... -
Page 43: Coolant
QJMOTOR Service Center. Caution If a motorcycle is driven in a more humid or dusty environment than usual or according to other driving conditions, it is necessary to shorten the filter ele- ment replacement interval. -
Page 44: Catalytic Converter
The muffler of this motorcycle model is equipped ervoir cap plug 5, and add coolant to the MAX with a catalytic converter to meet the needs of envi- mark. Please go to the QJMOTOR Service Center ronmental emission. to add special coolant. -
Page 45: Carbon Canister
If you need to place, causing coolant over- replace them, please remember to use genuine flowing and resulting in motor- parts or contact the QJMOTOR Service Center for cycle fault or personal injury. replacement. The old disposable clamp Clamp cannot be reused. -
Page 46: Lubrication Of Parts
Lubrication of parts Battery Proper lubrication is essential to maintain every part The battery 1 is located of the motorcycle in normal running, prolong its ser- under the driver seat. The vice life and ensure safe driving. Lubricate your battery equipped with this motorcycle after riding it for a long mile or if the motorcycle is a valve-con- motorcycle is wet due to rain or washing. - Page 47 For inspecting the battery, proceed as follows: 2. The red battery terminal is the positive terminal, and the black one is the negative terminal. Turn • Turn off the power supply switch of the motorcycle. off the ignition switch for wiring. Connect the •...
-
Page 48: Fuse Replacement
When replacing the battery, please pay attention to Warning the following: The electrolyte is a toxic substance. Beware of When replacing the battery, confirm the motorcycle children playing with them. Please place the bat- model and verify whether it is consistent with the tery safely to prevent children from touching it. -
Page 49: Headlight Beam Adjustment
Notice a short circuit or the circuit is overloaded. Please When adjusting the beam level, the driver should contact the QJMOTOR Service Center for repairs in sit on the seat of the motorcycle, keeping the front time. and rear tires seated on the ground, and ensure Warning that the motorcycle is vertical. -
Page 50: Abs Maintenance Instructions
If the ABS system is abnormal, please contact the Notice QJMOTOR Service Center. When replacing the bulb, the headlight bulb must Storage Guide be kept clean and dust-free; otherwise, the service life of the bulb may be shortened. Wipe off the Storage grease or dust with a clean cloth. -
Page 51: Use Of The Motorcycle After Storage
8750 rpm 68.2 6250 rpm 1580mm...
