Summary of Contents for QJMOTOR SRV 250 2024
- Page 2 SRV 250 V USER MANUAL Details described or illustrated in this booklet may differ from the vehicle's actual specification as pur- chased, the accessories fitted or the national-market specification. No claims will be asserted as a result of such discrepancies. Dimensions, weights, fuel consumption and performance data are quoted to the customary tolerances.
-
Page 4: Table Of Contents
Contents Safety Precautions for Motorcycles.........4 Cushion Loading and unloading ......17 Safe riding rules............4 Instructions for the use of fuel and oil......18 Protective apparel............4 Fuel ................18 Wear safety helmet.............5 Engine oil ..............18 Precautions for riding on rainy days ......5 Running-in .............. - Page 5 Engine idle speed adjustment ........28 Storage and Guidelines..........40 Driving chain ............28 Storage Guidelines ...........40 Adjustment of the drive chain: ........28 End of storage for use ..........41 Cleaning and Lubrication of driving chain ....29 Specifications and Technical parameters .....42 Driving belt ...............
- Page 6 Preface Important Information Thank you for choosing QJMOTOR brand motorcy- 1. Rider and passenger cle. We use advanced technology at home and The motorcycle is designed to be used by only one abroad to produce this type of motorcycle, Will pro- rider and one passenger.
- Page 7 If there is reverse connec- QJMOTOR Motorcycle will not bear all quality prob- tion, pay attention to check whether the fuse is lems and consequences (including loss of warranty) intact.
- Page 8 After you buy a motorcycle, please equip it with a motorcycle helmet that meets the national standard. Warning The motorcycle must be equipped with a fuse that meets the requirements before it can run safely. It is not allowed to adopt other specifications other than the requirements, and it is not allowed to con- nect directly or replace it with other conductive objects;...
-
Page 9: Safety Precautions For Motorcycles
Safety Precautions for Motorcycles 7. At intersections, car park entrances and exits and fast lanes, special attention should be paid Safe riding rules to driving carefully. 1. The vehicle must be inspected before driving in 8. Random motorcycle modification or disassembly order to avoid accidents and damage to the of the original parts, which will not ensure the parts. -
Page 10: Wear Safety Helmet
Frame numbers and engine numbers are used to Please record the number for reference. register motorcycles. When ordering accessories or entrusting special services, this number can enable Frame VIN number: QJMOTOR dealer maintenance department to pro- vide you with better service. Engine number:... -
Page 11: Parts Location
Parts Location 1 Rearview mirror 6 Front brake fluid reservoir 2 Clutch lever 7 Right handle switch 3 Left handle switch 8 Front brake handle 4 Instrument 9 Throttle control grip 5 Ignition switch 0 Fuel tank... - Page 12 SRV 250 (chain drive) SRV 250 V (belt drive) model Status model Status A Rear brake pedal B Rider's pedal C The passenger pedal D Oil filling port E Rear brake fluid reservoir F USB interface G Cushion lock hole H Shift pedal I Side stand J Front brake...
-
Page 13: Instrument
QJMOTOR motorcycle distribution department or maintenance center to check the vehicle in time. 5 Engine oil indicator When the engine is not started after the power sup- ply is turned on, the oil indicator light is always on;... - Page 14 perature exceeds 115 °C), the water temperature The speedometer indicates the current speed of the alarm light will be lit and alerted. vehicle. The optional unit is kilometer / hour (km/h) 9 Neutral indicator or mile / hour (mph), as described in the following When the gear position is changed to the neutral “instrument adjustment button”.
-
Page 15: Instrument Panel (If Equipped)
Instrument panel (IF EQUIPPED) In the relative mileage (TRIP A, TRIP B) state, press "SELECT" for a long time to clear the relative mile- age; in the total mileage (ODO) state, press "SELECT" for a long time, odometer and speedom- eter male mile unit switch Press the "ENTER"... - Page 16 Please contact the B Odometer QJMOTOR Service Center to inspect the motorcy- Depending on your needs, you can choose TRIP cle in time. (TRIP A or TRIP B) or TOTAL on the odometer.
-
Page 17: Operation Guide
D Fuel indicator Power lock It indicates the fuel level in the fuel tank. When the Warning fuel tank is full, the fuel level is displayed with 6 indi- cating marks. When the fuel is low and the fuel level Don't hang O-shaped rings or other things on the is displayed with 1 indicating mark, the last indicating key, because they may hinder rotation. -
Page 18: Left Handle
car, you should use a low light to avoid affecting the “ ” position, the faucet lock protrudes out the lock other side's line of sight. core, locks the faucet, the key can be taken out. 4 steering signal light switch Notice Press the steering signal switch. -
Page 19: Right Handle
Right handle handle in your own direction, while turning in the opposite direction slows down. 1 starting / Flameout switch 5 front brake handle Switch to “ ” position, the Hold the brake handle of the right handle slowly whole vehicle circuit is turned when braking. -
Page 20: Shift Pedal
clockwise, together with the key to open the fuel Warning tank cover. After adding oil, when you want to close Fireworks are strictly prohibited when refueling. the fuel tank cover, please direct the pin to the fuel tank cover, and then press down, you can close the fuel tank cover until the key is removed when you If the gasoline spills into the carbon tank and other hear the lock sound, and close the fuel tank cover... -
Page 21: Rear Brake Pedal
foot tip of the neutral and hanging into the low speed The side stand has the function of automatic flame- gear; each time the tip of the foot picks up the shift out: when the side stand is standing in the vehicle pole, it moves into the next high grade;... -
Page 22: Rear Shock Absorber Adjustment
Rear shock absorber adjustment Adjustment of rearview mirror The rear shock absorber is Rotating the rearview mirror mainly composed of shock frame 1 and the mirror rod 2 absorber spring and spring pre- can adjust the rearview mirror loading, which can be adjusted angle. -
Page 23: Instructions For The Use Of Fuel And Oil
Instructions for the use of fuel and oil cycle special oil. The oil viscosity should be deter- mined according to the temperature in the driving Fuel area, and the appropriate oil viscosity can be Please use unlead gasoline. Gasoline If the engine selected with reference to the diagram. -
Page 24: Avoid Running At A Low Speed On A Continuous Basis
Avoid running at a low speed on a continuous Routine first maintenance inspection basis The maintenance of 1000km is the most important maintenance work of motorcycle. all adjustments When the engine continues to run at a low speed should be done well, all fasteners should be tight- (light load), it will cause excessive wear and tear of ened, and the dirty oil should be replaced. -
Page 25: Pre-Riding Inspection
Pre-riding inspection Content Check points Before driving a motorcycle, be sure to check the Horn and brake Normal function switch following. The importance of these examinations must not be ignored. Finish all the inspection items Engine oil The oil level is correct before driving. -
Page 26: Starting
Starting Press the right handle to start the switch. “ ” when Put away the stand, hold the clutch grip, stop for a the throttle is closed, press the piezoelectric starting few seconds, step down the gearshift lever and switch to start the engine. hang it up. -
Page 27: Brake
Brake Motorcycles should be parked on solid, flat ground. Don't park in a place where traffic is blocked. Use of brakes and parking To completely close the throttle, release the throttle Turn the ignition switch to “ ” position to turn off control grip, and evenly use the front and rear the engine. - Page 28 Period Maintenance Odometer readings (note 2) mileage Content NOTES. 1000Km 6000Km 12000Km 18000Km 24000Km 30000Km Item Fuel path Fuel filter Throttle operation Air filter Note 1 Spark plugs Valve clearance Per 10000km: I Engine oil Oil filter Oil filter Cooling system Drive chain Note 3 Per 1000km: I, L, A...
- Page 29 Period Maintenance Odometer readings (note 2) mileage Content NOTES. 1000Km 6000Km 12000Km 18000Km 24000Km 30000Km Item Clutch device stand Shock absorption sys- Nuts, bolts, fasteners Note 3 Wheel / ring Note 3 Steering gear *Must be carried out by the distribution department or maintenance service center: the owner shall provide his own quali- fied tools and vehicle inspection information, and shall be overhauled by the holder of the mechanical worker's certificate, if repaired by himself Reference should also be made to the manual.
-
Page 30: Oil Level And Oil Exchange Of Engine
Oil level and oil exchange of engine The engine oil capacity is about 1.5L, 1.1L (no oil fil- ter is replaced) or 1.3L (oil filter is replaced at the Check the engine oil level same time). before starting the engine. When checking the oil level, let the car stand upright on a flat ground and observe through... -
Page 31: Spark Plug
• Use a new oil filter of the same model and Spark plug apply a layer of lubricating oil to the O-ring At the beginning of the riding 1000km, (figure 4 position). and each time 3000km is driven, the carbon deposit attached to the spark Notice plug is removed with a small metal wire brush or spark plug cleaner, and... -
Page 32: Clutch Adjustment
2. Measure its free travel in the Clutch adjustment throttle control grip flange. The The free stroke of the clutch standard free stroke should be shall be 10-20mm before the 10°-15 °. clutch begins to loosen and the The car is equipped with two-wire structure throttle position of the end of the clutch cable, throttle cable Ⓐ... -
Page 33: Engine Idle Speed Adjustment
Engine idle speed adjustment Warning The stepping motor in the motorcycle automatically These suggestions are the maximum adjustment adjusts the idle speed to the appropriate range. If time interval, in fact, the adjustment chain should you need to adjust, please contact Reseller mainte- be checked before each driving. -
Page 34: Cleaning And Lubrication Of Driving Chain
same level. After the base mark on both sides Cleaning and Lubrication of driving chain aligns and adjusts the relaxation of the chain to Use dry cloth and motorcycle chain cleaning agent 10-20mm, the rear shaft nut should be re-fixed to clean the chain. -
Page 35: Brake
Friction plate Warning The main point of checking the friction plate is to Do not adjust the drive belt on your own, incorrect see if the friction plate in the front brake clamp 1 operation may make the belt kink or flip, easy to and the rear brake clamp 2 is worn to the bottom lead to belt fracture. -
Page 36: Braking System
out. The front fluid reservoir is installed above the Braking system right handle of the vehicle, and if the liquid level is The braking systems that should be checked on a below the lower limit calibration line of the liquid cup daily basis are as follows: or the lower limit mark of the liquid cup liquid level •... -
Page 37: Tires
Tires Warning Correct wheel tire pressure will provide maximum It is a dangerous thing to drive a motorcycle under stability, driving comfort, and tire durability. Check the condition of excessive tire wear, which is not the tire pressure and adjust it as necessary. conducive to ground adhesion and driving. -
Page 38: Coolant
• remove the fixing screw 1 from the edge cover of Caution the empty filter, remove the edge cover of the If the motorcycle is driving in a more humid or empty filter, and you can see the paper filter core dusty environment than usual, or according to other driving conditions, it is necessary to shorten •... -
Page 39: Catalytic Converter
When the coolant becomes muddy or to the mainte- Warning nance cycle, please entrust the dealer maintenance In some cases, the substance contained in the department to replace the coolant in time. coolant is flammable, and when ignited, an invisi- The coolant expansion kettle is located in the front ble flame will be produced. -
Page 40: Carbon Canister
age your engine performance. If you need to replace Radiator pipe clip loading and unloading it, please remember to use pure parts or entrust When the radiator clamp is dealer maintenance department to replace it. removed, a special clamp 1 is needed to reinstall the clamp Notice 2, otherwise the clamp will not... -
Page 41: Parts Lubrication
Please follow the right diagram to connect the con- Oil Type nection method of the inlet and return pipes. (M: Motorcycle Description lubricating oil Parts lubrication G: Grease) Proper lubrication is 1 Rear brake pedal shaft very important to main- Side stand joint and tain the normal opera- spring hook... -
Page 42: Battery
Battery starts, the battery voltage shows that the charging system is normal between the 13.5V-15V. The battery is located under the cushion. The bat- • Vehicle leakage current detection: turn off the tery equipped with this car is valve-controlled wet whole vehicle power supply, positive or negative load free battery, it is strictly forbidden to pry open series multimeter (current file), the current is less... - Page 43 When installing the battery, please proceed in the Warning opposite order, first to the positive extreme (+), and The battery will produce flammable gas when it is then to the negative extreme (-). used and charged, so do not approach open fire or Notice spark when charging.
-
Page 44: Replacement Of Fuse
Replacement of fuse Headlamp beam adjustment The fuse is located under the The headlamp beam can be driver's cushion and next to the adjusted up and down in the battery. vertical direction. The main fuse 1 is set on the Loosen the left and right two starting relay and the fuse box headlamp fixing screws 1, light... -
Page 45: Abs Usage And Maintenance Instructions
with the same rated power. If the light source with If you find that the ABS indicator is flashing all the different rated watts is used, it may cause the over- time, indicating that the ABS is not working, check load of the circuit system and the premature dam- that the ABS plug-in is in place and that the ABS age of the light source. -
Page 46: End Of Storage For Use
3. As much as possible to empty the fuel tank, fuel 5. Remove the battery and store it separately in a place free from freezing and direct sunlight. injection unit oil. 6. Clean and dry motorcycles. Wax all painted sur- Notice faces. -
Page 47: Specifications And Technical Parameters
7000rpm...
