Summary of Contents for QJMOTOR SRF135
- Page 2 PREFACE Welcome to the world of motorcycling! As the owner, you are benefiting from the vast experience and newest technology regarding the design and manufacture of high-quality products, which have earned us a reputation for dependability. Please take the time to read this manual thoroughly, so as to enjoy all advantages of your vehicle. The Owner’s Manual does not only instruct you in how to operate, inspect and maintain your vehicle, but also how to safeguard yourself and others from trouble and injury.
- Page 3 IMPORTANT NOTES 1. Rider and Passenger The motorcycle is designed to be used by only one rider and one passenger. 2. Road conditions for riding This motorcycle is suitable for riding on-road. 3. Please read this operation and maintenance manual carefully. Following the break-in instructions in this manual will keep your motorcycle running stably and allow the engine to reach its full performance.
- Page 4 SPECIAL NOTICE Warning: this motorcycle is equipped with a main fuse that must meet the standard requirements to run safely. DO NOT use fuses of incorrect specifications or other conductive objects; otherwise it will lead to damage to parts, fire, and/or a serious accident. Fuse location: under the rider's seat A blown fuse is usually caused by an electrical system short.
- Page 5 QJMOTOR Motorcycle will not bear all quality problems and consequences (including loss of warranty) caused by users' unauthorized modification or installation of unauthorized parts. The user is requested to comply with the regulations of the traffic management department on the use of vehicles.
-
Page 6: Table Of Contents
Table of Contents PREFACE Riding up a slope …...….…………………………………… 10 IMPORTANT NOTES SPECIAL NOTICE Braking and parking ………………………………………… 11 Inspection and Maintenance ............12 Safety Precautions for Operation ………………….…………… 1 Maintenance Schedule ............. 12 Safe riding rules …………….……………………….……… 1 Oil level and oil change …………………………………… 14 Protective clothing ……………………………………………... -
Page 7: Safety Precautions For Operation
Safety Precautions for Motorcycle Operation riding safety operational performance Safe riding rules motorcycle, especially the overloading of the electrical systems can easily cause danger. 1. The vehicle must be checked before riding to avoid Protective clothing accidents and damage to parts. 2. -
Page 8: Motorcycle Serial Number
Motorcycle serial number Parts locations The frame number and engine number are used when registering the motorcycle. This number enables the dealer to provide you with better service when ordering accessories or commissioning special services. Please record the number for future reference. -
Page 9: Instruments
Note: This picture is for reference only, and the actual Instruments vehicle you purchased may vary. ○ Left turn signal indicator When the turn signal is turned to the left, the left turn signal indicator will flash accordingly. ○ Right turn signal indicator When the turn signal is turned to the right, the right turn signal indicator will flash accordingly. -
Page 10: Operation Guide
○ off, the vehicle is running normally. If the indicator light is 10 Speedometer on, the vehicle has a fault and needs to be stopped for Indicates the current vehicle speed. ○ inspection. Please contact the dealership or maintenance Fuel gauge center to check the vehicle in time. -
Page 11: Ignition Switch
Ignition switch Left handlebar & switch ① Clutch lever When starting engine or shifting gears, operate the clutch lever to drive rear wheel. ② Horn button Press the horn button " ON " mark... The key is turned to the " ON " mark position, and the horn will sound. -
Page 12: Right Handlebar Switch
Gradually pull in the brake lever on the right handlebar Warning: to brake the front wheel. When changing lanes or turning, turn on the turn signal in advance and confirm that no vehicles are passing ④ Throttle grip The throttle grip is used to control the engine speed. behind. -
Page 13: Shifter Lever
Warning: Always check the patency of the water outlet of the fuel tank Fuel tank should not exceed 90% of the volume, as shown in cap to ensure smooth drainage and prevent external water from the specified position of the upper limit of fueling, and do not splash entering the fuel tank cavity. -
Page 14: Brake Pedal
Brake pedal which can be adjusted according to various factors such as the driver's This model is wishes, bearing conditions and road equipped with conditions. combined braking There are two adjustment nuts at one system, and the front end of the shock absorber spring. Use the and rear wheels of rear shock absorber adjuster and sleeve the motorcycle can... -
Page 15: Break-In
Break-in 2) Flexible rotation The first 600 mile riding period, the engine should 3) No axial movement and looseness neither be operated excessively, nor should the speed of any 1) The lever and brake pedal have gear position exceed 80% of its maximum speed; do not allow the correct free play the throttle to be fully opened. -
Page 16: Riding A Motorcycle
quickly to the closed position Caution: Do not rev the engine when not riding, or it will 1) Cable clearance is appropriate Clutch overheat and may damage internal engine components. 2) Smooth operation Setting off 1) Correct adjustment Drive chain Pull in the clutch lever, pause for a moment, and press 2) Proper lubrication the shift lever down for first gear. -
Page 17: Braking And Parking
When going downhill, shift the engine to a lower gear to facilitate braking. Be careful not to rev the engine too high. Braking and parking To fully close the throttle, release the throttle control grip to auto-return. Apply front and rear braking simultaneously and evenly. -
Page 18: Inspection And Maintenance
Inspection and Maintenance The table below shows the time limit for regular maintenance in kilometers driven. At the end of each time period, inspection, inspection, lubrication and prescribed maintenance must be carried out in accordance with the methods described. Steering systems, struts and wheel systems are critical components that require careful repair by skilled personnel. - Page 19 Period Maintenance Odometer reading (Note 2) Content mileage 600mi 2500mi 4400mi 6200mi 8700mi Note Maintenance item Every 600mi : I, L , A Drive chain Note 3 Brake pad wear Braking system I , A I , A I , A I , A I , A Brake switch...
-
Page 20: Oil Level And Oil Change
Oil level and oil change ● 3. Install the filter screen, spring, oil filter cover and oil drain plug. Oil level 4. Fill the engine with oil that meets the specification until the oil amount reaches the upper limit mark. When measuring the oil level, stand the vehicle upright on flat ground. -
Page 21: Throttle Body
condition of the engine. The porcelain insulator around the Open the cover at the bottom of the throttle body, spray center electrode of the spark plug should be a medium to contact cleaner on the inside of the throttle body, and use a light tan (the ideal color for normal vehicle riding). -
Page 22: Drive Chain
● Drive chain (1) Use a rear stand to support the motorcycle. (2) Loosen the rear axle nut ①. The service life of the drive (3) Loosen the lock nut ②. chain depends proper (4) Turn the adjusting bolt lubrication and adjustment. ③... -
Page 23: Brakes
The free play at the end of the front brake lever should be If the chain has the above problems, then the sprocket will most likely be damaged. 10-20mm. Check the sprockets for the following: The free play of the brake pedal should be: 20-30mm Brake pads (1) Degree of worn gear teeth Inspect brake pads frequently to... -
Page 24: Tires
we strongly advise you to entrust the work to your Replenishing brake fluid should be considered a necessity for dealer. They have complete tools and skilled technology, regular maintenance. and can do the work in the safest and most economical way. Caution: This car uses DOT4 brake fluid. -
Page 25: Fuel Injector And Fuel Circuit
Riding a motorcycle with excessive tire wear is a performance. If you need to replace it, please remember to use dangerous thing that is bad for ground adhesion and genuine parts or entrust a dealer to replace it. Note: riding. The catalytic converter is a high temperature area, ●... -
Page 26: Battery
□ Ｙ Motorcycle Lubricant □ Ｚ Grease After the battery is installed, the positive and negative ①Rear brake pedal shaft□ Ｚ ②Speedometer flexible shaft★□ Ｚ terminals of the battery should be located towards the right ③Speedometer gears and gear shaft bearings★□ Ｚ side of the vehicle. - Page 27 the electrolyte container forcefully, breaking the sealing speed riding, frequent braking, or installing additional film of the liquid injection port of the electrolyte electrical components will increase the accelerated discharge container, and let the electrolyte fill the battery. At this of the battery, increase the load on the battery, cause power time, check the three injection tubes on the left and loss and shorten the service life.
-
Page 28: Headlight Beam Adjustment
To replace the battery, please note the following: Headlight The adjusting screw ① is When replacing the battery, confirm the model of the motorcycle and check whether it is the same as the original located on the back of the headlight, battery model. -
Page 29: Air Filter Maintenance
● Air filter maintenance upper inspection hole, making sure the piston is at the top dead center position. The air filter should be maintained regularly, especially if riding in a dusty or sandy areas. 3. Insert a feeler gauge ⑤ between the adjusting screw ⑥ and (1) Remove the seat first. -
Page 30: Storage Guidelines
Storage Guidelines from freezing and direct sunlight. 6. Wash and dry the motorcycle. Wax all painted surfaces. If you plan to not use your motorcycle for an extended 7. Inflate the tires to the recommended tire pressure. Place period, certain maintenance measures should be performed to the motorcycle on a stand so that both tires are off the ground. -
Page 31: Specifications And Technical Parameters
Specifications and Technical Parameters SRF135 Length …………………………………………………………….1770mm Width ……………………………………………………………….760mm Height …………………………………………………………….1025mm Wheelbase ………………………………………………………1215mm Curb weight ………………………………………………………271lbs. Engine Type ……………………………..…154FMI-7A Single Cylinder, 4V Bore×Stroke ……………………………………………54.0× 58.8mm Displacement ………………………………………………………135ml Maximum power ………………………………11.66hp /9000r/min Maximum torque …………………………… 7.376 ft lbs. /7000r/min Ignition method ……………..…ECU electronic control ignition Tire specification Front tire specification ……………………………………120/70-12... - Page 32 YOUR WARRANTY RIGHTS AND OBLIGATIONS engine computer, if it is equipped. Also included The California Air Resources Board, the U.S. may be hoses ,belts, connectors and other Environmental Protection Agency, and Hua Mei emission-related assemblies. Motor USA LLC. (hereinafter “Hua Mei”) are Where a warrantable condition exists, Hua Mei pleased to explain the emission system warranty will repair your motorcycle at no cost to you,...
-
Page 33: Owner's Warranty Responsibilities
OWNER’S WARRANTY RESPONSIBILITIES If you have any questions regarding your As the vehicle owner, you are responsible for the warranty rights and responsibilities, you should performance of the required maintenance listed contact Hua Mei Motor USA LLC, 270 TRACE in your owner’s manual. Hua Mei recommends COLONY PARK STE B, Ridgeland, MS 39157,TEL: that you retain all receipts covering maintenance (866) 222-1558 or (for California registered... - Page 34 workmanship which cause such vehicle to fail to station is not reasonably available to the owner. conform with applicable regulations of the United In an emergency, repairs may be performed at States Environmental Protection Agency or the any available service establishment, or by the California Air Resources Board for the periods owner, using any replacement part.
- Page 35 In the state of California only, emission-related In the state of California only, any warranted part warranted parts are specifically defined by the which is scheduled for replacement as required state’s Emission Warranty Parts List. These maintenance in the owner’s manual is warranted warranted parts are: carburetor and internal for 12,000 km or for 5 years, whichever first parts;...
- Page 36 caused by the use of an add-on or modified part Inspections, replacement of parts and other is not covered by this warranty. services and adjustments required for required maintenance. In the state of California only, Hua Mei will Any vehicle equipped with an odometer or warrant the damages to other vehicle hour meter on which the odometer mileage or components proximately caused by a failure...
- Page 37 or exemplary arising in connection with the sale Mei Limited Emission Control System Warranty. or use of or inability to use the vehicle for any purpose. Some states do not allow the exclusion IV. LEGAL RIGHTS. or limitation of any incidental or consequential This warranty gives you specific legal rights, and damages, so the above limitations may not apply you may also have other rights which vary from...
-
Page 38: Reporting Safety Defects
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National High way Traffic Safety Administration (NHTSA) in addition to notifying QJMOTOR. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. -
Page 39: California Proposition 65 Warning
California Proposition 65 Warning Operating, servicing and maintaining a passenger vehicle or off-highway motor vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle in a well-ventilated area and wear gloves or wash your hands frequently when servicing your vehicle. - Page 40 Part Number: 02401V040002...
