CHARACTERISTICS:
The HD67685-IP-A1, HD67685-MSTP-A1, HD67685-MSTP-B2 is a BACnet Slave / J1939 Converter.
It allows the following characteristics:
Up to 2048 BACnet objects (Read + Write);
Triple isolation between BACnet - Power Supply, BACnet – J1939, Power Supply – J1939.
Two-directional information between BACnet bus and J1939 bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67685 software on your PC in order to perform the following:
Define the parameter of BACnet line;
Define the parameter of J1939 line;
Define BACnet objects that contains the data from J1939;
Define BACnet objects that contains the data to to J1939;
Update the device.
