Exmark TURF TRACER HYDRO Operator's Manual page 29

d) Check all idler arms to be sure they pivot freely.
5.1.14 Lubrication
a) Stop engine and remove ignition key.
b) Lubricate fittings with one to two pumps of SAE No. 2
multi-purpose gun grease (see recommended lubricants)
following the lubrication chart.
Refer to the following chart for fitting locations and
lubrication schedule.
LUBRICATION CHART
FITTING INITIAL No. of
SERVICE
LOCATIONS PUMPS PLACES
INTERVAL
1
.
Caster Wheel Bearings 12 2 Daily
2. Caster Pivots
2 2
Daily
3.
Cutter Housing Spindles 10 3
t Weekly
4. Idler Pivots (Mower Deck)
1 2
Weekly
5. Idler Pivot (Pump Drive)
2
i
Weekly
6.
Hydro Control Arm
Support Bushings
2
JU
Weekly
t Under severe cutting conditions, two pumps of grease
twice
weekly
may be more beneficial.
Recommended SAE No. 2 Greases:
Pennzoil #705; Pennzoil #707L; Pennzoil #TTM 302
Mobil Grease CM-P; Mobilith SHC220;
Mobil Grease Special; Mobilith SHC460
(Available at Mobil Stations)
Ronex MP - (Available at Exxon Stations)
Shell Alvania #2 - (Available at Shell Stations)
Super Lube M EP #2 or Super Stay M #2
(Available at Conoco Stations)
5.1.15 Check spark plugs.
Service Interval: 100 hrs.
a) Remove spark plugs, check condition and adjust plug gap
or replace with new plugs. See Engine Owner's Manual.
5.1.16 Remove engine shrouds and clean cooling fins.
Service Interval: See Engine Owner's Manual
a) Stop engine and remove ignition key.
b) Remove cooling shrouds from engine and clean cooling
fins. Also clean dust, dirt and oil from external
surfaces of engine which can cause improper cooling.
-
24
-
