Loose Parts

Use the chart below to verify that all parts have been shipped. Part numbers not shown are available on the dealer
extranet.
Dealer Pack
Part #
323-6
3290-357
98–5975
104-8300
3230-1
1-806003
3272-5
1-808280
322-9
3296-29
3220-16
1-303335
1-303287
103-2106
1-603511
Literature Pack
Part #
—
—

Uncrating the Unit

1. Leaving the unit on the pallet, place the upper handle
assembly and the LP tank bracket at the rear of the
machine.
2. Remove the bolt bag from under the mower deck
belt shield.
3. Refer to the parts manual to help you identify and
locate the parts and their proper position.
© 2011—Exmark Mfg. Co., Inc.
P.O. Box 808
Beatrice, NE 68310
Description
Screw, HH 3/8-16 x 1 inch
Nut, Whizlock 3/8-16 inch
Washer, Spring Disc
Nut-Nyloc 5/16-18 Flg
Bolt-Carriage 5/16-18 x 3/4
Hairpin, Cotter
Pin, Cotter 3/32 x 1/2 inch
Pin, Clevis
Screw, HH 5/16-18 x 1 3/4 inch
Nut, Nyloc 5/16-18 inch
Nut, Jam 3/8-24 inch LH
Tie, Cable
Tie, Cable
Key, Exmark Logo
Key, Standard
Description
Manual, Operator's
Manual, Engine Operator's
TURF TRACER
Qty.
4

Installing the handle assembly.

4
4
4
Installing the LPG tank bracket.
4
1
1
1
2
2
2
2
4
Fill out the online warranty registration
1
form and place keys into literature
1
pack.
Qty.
1
Read before operating the machine.
1
Read before operating the machine.
Installing the Handle Assembly
1. Position the lower end of the handle assembly on
the outside of the upper rear section of the fuel tank
and handle support.
2. Install four 3/8-16 x 1 inch bolts, four spring disk
washers from the outside in. Secure using four
3/8-16 whizlock nuts on the inside of each handle
support and tighten until the spring disk washers are
flat (Figure 1).
Note: Be sure the cone of the spring disk washer is
against the head of the bolt.
S-SERIES LP
®
Setup Instructions
For Serial Nos. 312,000,000 & Higher
Use
Use
Part No. 4501-050 Rev. A
Printed in the USA
All Rights Reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TURF TRACER LP S Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Exmark TURF TRACER LP S Series

Summary of Contents for Exmark TURF TRACER LP S Series

  • Page 1 (Figure 1). Note: Be sure the cone of the spring disk washer is against the head of the bolt. © 2011—Exmark Mfg. Co., Inc. Part No. 4501-050 Rev. A P.O. Box 808 Printed in the USA...
  • Page 2 Figure 1 1. Front of the unit 3. Upper handle Figure 2 2. Upper handle mounting 1. Tank slot 3. LPG tank 2. Mounting tab Install the LPG Tank Bracket 4. Latch the bracket and make sure the tank is securely fastened to the mower.
  • Page 3 Figure 3 1. Throttle control lever 3. Clamp 2. Throttle cable — Located on bottom side of clamp. Install the PTO Engagement Linkage Figure 4 1. Loosen the jam nut and remove the turnbuckle from 1. Lower PTO engagement linkage the lower linkage (Figure 4).
  • Page 4 2. Insert the end of the linkage opposite the yoke into the end of the speed control lever located underneath the handle console from the right hand side and fasten with a hairpin from the bolt bag. 3. Connect the lower end of the speed control linkage to the speed control crank located at the top rear of the fuel tank support.
  • Page 5 Servicing the Battery neutral lock latches (Figure 7). If the tire rotates in either direction, the length of the drive lever link will need to be adjusted. WARNING 3. Adjust the linkage length by loosening the jam nuts CALIFORNIA at both ends of the linkage and rotating the linkage Proposition 65 Warning in the ball joints.
  • Page 6 Servicing the Engine The engine is shipped with oil; check oil level and if Greasing the Unit necessary fill to the appropriate level. Exmark 4-Cycle Note: The unit is not greased at the factory. Premium Engine Oil is recommended. Refer to the Engine Owner’s Manual for an acceptable alternative.
  • Page 7 2. Check hydraulic reservoir and if necessary fill the reservoir to the appropriate level with Exmark Premium Hydro oil. 3. Replace hydraulic reservoir cap and tighten until snug. Do Not overtighten. Note: The baffle is labeled “HOT” and “COLD”. The oil level varies with the temperature of the oil.
