R13 ATEX Z2 Receiver
Technical description
R13 ATEX Z2 hardware description
©
Danfoss | July 2024
7
6
5
8
Multi-band antenna
3.
4.
Power supply
Internal EEPROM
5.
6.
Signaling LEDs
7.
TR800-CE MCX radio
Wiring communication
8.
R13 ATEX Z2 receiver only allows Altern Current (AC) power supply and a maximum of 13 relays.
