SSV Works MAVR-PHZ4VTD Manual page 11

L. Plug in the amplifiers turn-on bullet connectors to the turn-on delay
module output wire. See page 6 for reference.
N. Remove the panel behind the passenger seat.
P. Split the B-H2936 rear speaker harness to the passenger and driver
side along the rear firewall. Zip tie the cables to the factory harness
and avoid hot or moving parts.
L
M. Plug in the amplifier's front speaker output to the B-H1385 "Y"
harness and the rear speaker outputs to the B-H1913, 4-pin audio
extension harness.
M1. Plug in the amplifier's subwoofer output to the B-H2702, 2-pin
subwoofer extension cable.
N
O. Plug in the B-H2936 (rear speaker harness) to the B-H1913 (4-pin
audio extension harness, 8 ft.).
P
Q. Run the driver and passenger side speaker harness through the
plastic panel by the B-pillar.
M
M1
O
Q
11
