Field of use
 The KINETEC® Traction frame allows the traction or suspension of one part of the body.
Indications / Contraindications
 Only the physician must determine the protocol adapted to the patient.
Warnings and safety instructions
 Before using Traction Frame, it is essential to have a thorough understanding of this manual. This manual contains instructions for general use and
guarantees improved safety.
 Any serious incident that has occurred in relation to the device should be reported to the manufacturer and the competent authority of the
Member State in which the user and/or patient is established.
 During assembly:
- The KINETEC system must not be used with traction frame components from another company.
®
- The headboard and footboard should always be in place (risk of neck entrapment), only remove the footboard panel to perform lower limb
traction, only remove the headboard panel to perform cervical traction.
 During use:
- Before any use, please make sure that the weight of the patient and of the accessories are compatible with the security load of the bed.
- Check before each use and each week the fixing of the jaws, the general state of the accessories.
- The physician must define the protocol and ensure that it is correctly implemented.
- The weights must be positioned outside of the line of the frame ensuring that they do not pose a risk to any person interfacing with the frame.
- Do not position weights above the patient.
- All bed functions should be blocked when using the traction frame to avoid incompatible use with the patient's pathology and/or assembly
performed.
 During movements / manipulations of the bed equipped with a traction frame:
- Use only the head and foot panels, do not use the tubes of the traction frame.
- Make sure no one is in contact with the elements of the bed and frame. This is to prevent entrapment and pinching with all the moving parts of the
bed and frame.
- Make sure that no components are outside of bed frame (weights, bars, accessories).
- Make sure that no outer components can knock against the frame. (Light strip, lighting, TV, indication panels...).
- Do not move the bed with the frame and the patient, but in an emergency situation take care of the obstacles which can provoke weight
vibrations (doorways, elevator entrances, floors in poor condition, change in floor level ...).
- When you move the bed with the frame and the patient please make sure that the frame is in a low position except when contraindicated and
in this case take care of for example the elevator entrance.
 Remove the traction frame when it is not used.
 Improper use may cause injury to the patient or equipment damage.
Assembly
 The KINETEC frame should be installed when the bed is in a low position and without patient.
®
 Ensure you only use the correct upright bar this will be marked with the «T64 Linet Latera» label. They mustn't be used with another bed.
 Please respect the positioning of the main elements of the frame, as shown on the figure 1.
 When mounting the porch bars, using the screws supplied with the frame in order to secure all (see photo a).
 During assembly of the B210 octagonal bar make sure that both double clamps are on the top of porches (see picture b). The plain bar on the top of
the porch.
 To use the bed extension, the 2 double "DMEP" jaws must be loosened to allow the octagonal bar "B210" to slide, then retighten them after locking the
bed extension.
 When you install the head porch, the grounding continuity is assured by the cable fixed to the head porch "PRTT64" and the bed grounding socket
(see picture c). Attention with positioning the cable of grounding continuity well in order to prevent that it is not detached during the moving of the
bed with the frame. Make sure that the measure of this socket is inferior or equal to 0.1 ohms.
 In order to respect the grounding continuity, you should realise a maximum of 5 connections.
Cleaning
 Clean the traction frame between each patient.
 Use a DISINFECTANT (PROPANOL/ISOPROPANOL or ALDEHYDE-based solution). Spray the disinfectant on the SURFACES (plastic and metal
components). We advise to pay particular attention to the articulations and on holding back zones like the screws and bolts.
 In order to ensure optimal hygiene, you are advised to clean the pads and the frame for each new patient. All the consumables enable hazard-free
disposal. You should also clean the yellow protections "SP01" to each patient.
 Recommendations to obtain a maximum hygiene of the pads.
Disinfecting of the pads: Washing at 30°C with use of a disaffection solution during the rinsing cycle. Example of product which can be used: Solution
"Baclinge" at 0.125% or "Souplanios" at 0,125% from ANIOS Laboratory. A complete list of distributors in your country is available on request.
Elimination and recycling
 Packaging: the packaging must be separated from plastic components and paper/cardboard and placed in the specific recycling locations.
 Device: it contains metal, aluminium, plastics, and cables. When the device is no longer operational, dismantle it and separate the parts into groups
of materials and deliver them to authorised recycling units or return the device to KINETEC SAS for destruction. Or contact the local authorities to
determine the suitable method to dispose of the parts and accessories that are potentially hazardous to the environment.
Warranty
The KINETEC warranty is strictly limited to the replacement free of charge or repair in the plant of the component or components found to be defective.
®
Kinetec SAS guarantees its Traction frames systems for 2 years against all defects of manufacture from the date of purchase by the consumer.
Kinetec SAS is the only organisation able to assess the application of the warranty to its systems.
The warranty will be considered null and void if the device has been used abnormally or under conditions of use other than those indicated in the user's
manual.
The warranty will also be considered null and void in the event of deterioration or an accident due to negligence, inappropriate surveillance, or
inappropriate maintenance, or due to transformation of the equipment or an attempt to repair the equipment.
