• Definition__________________________________________________________ 2
• Description ________________________________________________________ 3
• Safety ____________________________________________________________ 4
• Electrical connection __________________________________________________ 4
- Select your language ________________________________________________ 5
- Locking the hand control setting ________________________________________ 5
- START/STOP/REVERSE function _________________________________________ 5
- Quick Start_______________________________________________________ 6
- Possible values for each parameter ______________________________________ 6
- How to modify programs PROGRAM MODE? _________________________________ 8-9
- Using Programs ___________________________________________________ 10
- Reading the values of a program ________________________________________ 10
- Setting up the forearm support _________________________________________ 12
- Setting up the driving mechanism ________________________________________ 12
- Adjusting the length finger ____________________________________________ 13
- Pronation / Supination _______________________________________________ 14
- Extension / Flexion of the wrist__________________________________________ 14
- Ulnar deviation ____________________________________________________ 15
- Thumb opposition __________________________________________________ 16
- Complete fist _____________________________________________________ 16
- Intrinsic + _______________________________________________________ 17
- Intrinsic - ________________________________________________________ 17
- Selective mobilization of the DIP joint _____________________________________ 18
- Maintenance______________________________________________________ 18
- Cleaning ________________________________________________________ 18
- Technical specifications ______________________________________________ 18
- Troubleshooting ___________________________________________________ 19
- Symbols used _____________________________________________________ 19
- Warranty ________________________________________________________ 19
- Maintenance sheet _________________________________________________ 20
• The physician defines the protocol and ensures that it is correctly implemented (adjustments, session time and frequency of use).
• We recommend that you lock the hand control when you give it to the patient.
• For optimum safety, always give the hand control to the patient before starting the system.
• Explosion hazard: KINETEC Maestra is not designed for use in the presence of flammable anaesthetics.
• Check that the electrical socket is in good condition and is suitable for the splint power supply cord. The latter complies with current
standards and has a grounding socket. The plug may be connected to any standard socket. The socket must however have a grounded
pin. To connect the power supply, only use the original cable supplied with the machine. Check that the cables remain free around the
device so that they do not get damaged.
Manuel N°467896276 - Update 16/07/09
Summary
Page
SAFETY RECOMMENDATIONS
GB
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Maestra and is the answer not in the manual?

Questions and answers

Related Manuals for Kinetec Maestra

Summary of Contents for Kinetec Maestra

  • Page 1: Table Of Contents

    • For optimum safety, always give the hand control to the patient before starting the system. • Explosion hazard: KINETEC Maestra is not designed for use in the presence of flammable anaesthetics. • Check that the electrical socket is in good condition and is suitable for the splint power supply cord. The latter complies with current standards and has a grounding socket.

  • Page 2: Definition

    Definition The KINETEC Maestra is used for passive mobilization of the hand and wrist and permits a wide range of possible joint movements for: The forearm The wrist The thumb The long fingers • Indications • Flexor and extensor tenolysis.

  • Page 3: Description

    Description The KINETEC Maestra is a portable machine, single unit device that can be used on a table. It consists of the following components: 1 • Casing encloses the motor and the power PCB. 2 • Forearm support. 3 • Transport handle.

  • Page 4: Safety

    KINETEC Maestra is not designed for use in the presence of flammable anaesthetics. In case of electromagnetic interference with other devices move the device. KINETEC Maestra is in compliance with standards in force (IEC 601.1.2), electromagnetic compatibility standard for medical devices.

  • Page 5: Use Of The Hand Control

    We recommend that you lock the hand control when you give it to the patient. Comment: The hand control is unlocked when you switch the unit ON/OFF. START/STOP/REVERSE function As with all KINETEC systems, KINETEC Maestra is equipped with a START/STOP/REVERSE function. When the unit is running, the display reads RUN Press the key of the hand control.

  • Page 6: Quick Start

    Set up the patient and proceed as below: Beginning Keys to press Display Remarks Switch the unit ON KINETEC Maestra V01.0 Check if the hand control is not blocked (See page 5). Please wait Prona/supination STOP The display shows the new movement selected...

  • Page 7: How To Adjust The Basic Parameters Of The Movement

    Use of the hand control How to adjust the basic parameters of the movement? Beginning Keys to press Display Remarks To stop the unit Prona/supination Check if the hand control is not blocked STOP (See page 5). To choose the movement The display shows the new movement selected Prona/supination and the default settings of the upper and lower...

  • Page 8: How To Modify Programs Program Mode

    Display Remarks To switch off the unit Press the two keys at the same time and switch the unit KINETEC Welcome text during 3 seconds. maestra V01.0 Program Then The program number blinks. EMPTY Program To change the program if necessary The new program number blinks.
  • Page 9 Use of the hand control Comments: Program • When a program has been deleted, the display shows EMPTY Program table:...

  • Page 10: Using Programs

    Use of the hand control Using Programs The KINETEC Maestra allows you to store up to 16 programs, including the type of movement, ROM, speed, load, pauses and timer. The original parameter values of the program are empty. These values can be modified and recorded at any time (see ‘How to enter a program’ page 10).

  • Page 11: How To Define The Upper And Lower Movement Limits

    The MANUAL MODE is a way to set within the tolerance of a patient at the beginning of a session. Set up the patient and proceed as below: Beginning Keys to press Display Remarks KINETEC maestra V01.0 Check if the hand control is not blocked Switch the unit on (See page 5). Please wait Prona/supination STOP...

  • Page 12: Start Up

    Start up Setting up the forearm support The forearm support should be attached on the RIGHT hand for the Left hand on the LEFT for the RIGHT hand. For Pronation-supination of the wrist, the support should be attached to the base directly IN FRONT of the motor axis. The support is set on a telescopic rod (1) which has two notched joints (2 and 3).

  • Page 13: Adjusting The Length Finger

    Start up Adjusting the length finger To better fit individual hand lengths and polar radii depending on the fingers or thumb to be mobilized the guide will be oriented as follows by unscrewing the nut (8) and lifting the guide (7), in position (A) or in position (B).. Guide in position A Guide in position B...

  • Page 14: Possible Movements

    Possible movements Pronation / Supination The KINETEC Maestra provides a motion from 90° of pronation to 90° of supination • Choice of the Pronation / Supination movement: - Press and adjust your parameters (see page 9). - Or select a program (see page 13).

  • Page 15: Extension / Flexion Of The Wrist And The Mp Joints Of The Fingers

    Possible movements Extension / Flexion of the wrist and the MP joints of the fingers The KINETEC Maestra provides a motion from -50° to 140°. • Choice of the 2 movement of the wrist: - Press 2 times and adjust your parameters (see page 9).

  • Page 16: Thumb Opposition

    Possible movements Thumb opposition The KINETEC Maestra provides a motion from 0° to 180°. • Choice of the thumb opposition movement: - Press and adjust your parameters (see page 9). - Or select a program (see page 13). Complete fist The KINETEC Maestra provides a motion from -30°...

  • Page 17: Intrinsic

    Possible movements Intrinsic + The KINETEC Maestra provides a motion from 0° from 90°. • Choice of the intrinsic + movement: - Press 1 time and adjust your parameters (see page 9). - Or select a program (see page 13).

  • Page 18: Selective Mobilization Of The Dip Joint

    The need for maintenance is indicated by display of the message SERV. MOTOR when the system is switched on. Despite that warning, you can continue to use your KINETEC Maestra by pressing START, but you should contact your nearest KINETEC technician to have the maintenance operations conducted as soon as possible.

  • Page 19: Troubleshooting

    Warranty The KINETEC warranty is strictly limited to the replacement free of charge or repair in the plant of the component or components found to be defective. KINETEC guarantees its joint passive mobilization systems for 1 year against all defects of manufacture from the date of purchase by the consumer.
