KINETEC CEM™
Manuel d'utilisation
User manual
Bedienungsanleitung
Avant toute utilisation lire ce document.
Kinetec se réserve le droit de toutes modifications techniques.
Before use, please read this document.
Kinetec reserves the right to effect technical modifications.
Vor Benutzung unbedingt dieses Dokument lesen.
Kinetec behält sich das Recht vor, jegliche technische Änderung
durchzuführen.
FR
EN
DE
467896366 – 12/2014
Série 1-2
Notice Originale
Advertisement
Table of Contents
Related Manuals for Kinetec KINETEC CEM
Summary of Contents for Kinetec KINETEC CEM
- Page 1 KINETEC CEM™ Avant toute utilisation lire ce document. Manuel d'utilisation Kinetec se réserve le droit de toutes modifications techniques. Before use, please read this document. User manual Kinetec reserves the right to effect technical modifications. Vor Benutzung unbedingt dieses Dokument lesen.
-
Page 2: Table Of Contents
Compliance: ...................................... 3 Unpacking and packing ..................................4 Installing the device ..................................4 Basic assembly ....................................5 Assembling the components of the KINETEC CEM™ ........................5 Transporting the device ..................................6 Description ......................................6 USING THE HAND CONTROL.................................... 8 Electrical connection: safety first ..............................8 Starting the unit .................................... -
Page 3: Description
DESCRIPTION 1. Definition The device KINETEC CEM™ is a PASSIVE mobilisation device allowing Extension/Flexion movements of the ELBOW from -10° to 135° with fixed prono-supination, in all abduction planes of the shoulder. It is available as a complete device with chair or as an add-on module that can be used on Series 2 or higher KINETEC CENTURA™... -
Page 4: Warning And Safety Instructions
See the table on page 22. 6. Compliance: The device KINETEC CEM™ meets the requirements of the Medical Directive No. 93/42/EEC. It bears the EC mark. The device KINETEC CEM™ complies with the standards in force: IEC 601601-1-2 concerning the electromagnetic compatibility of medical devices and IEC 60601-1 concerning electrical safety. -
Page 5: Unpacking And Packing
• Box B – the other accessories, except for the arm rest - Place the machine in its box. Box 2: - Put the accessories specific to the KINETEC CEM™ in this box. Box A 8. Installing the device The device KINETEC CEM™ machine is designed to be used in hospitals, clinics, doctors' offices or in private homes (rental). -
Page 6: Basic Assembly
Take care that fingers do not get pinched during handling operations or when the chair is unfolded. Never carry the device by the chair when it is in its working position. 10. Assembling the components of the KINETEC CEM™ Kit Install the elbow motor support (3) Install the elbow motor (2) Install the forearm splint (6). -
Page 7: Transporting The Device
Place your foot as indicated to tilt the unit. You can adjust the height of the handle with the knobs (9). 12. Description The device KINETEC CEM™ consists of the following components: 1 – Chair 2 – Base 3 –... - Page 8 DESCRIPTION Description Composition of the KINETEC CEM™ Module: 1 • Hand control 2 • Extension – Flexion motor 3 • Elbow motor support 4 • Elbow protection 5 • Arm splint 6 • Forearm splint 7 • Forearm length setting lock 8 •...
-
Page 9: Using The Hand Control
ELBOW MODULE 30 STOP 15 70 Your device KINETEC CEM™ is ready to be used with the parameters from the previous session (except Timer and Warm Up mode) Warning Always check the motion parameters displayed on the hand control before starting the session. -
Page 10: Changing The Display Language
Note: the hand control locking is preserved when you switch the unit ON/OFF. 5. START/STOP/REVERSE function As with all KINETEC systems, the device KINETEC CEM™ is equipped with a START/STOP/REVERSE ® function. Press this key of the hand control and the movement stops. -
Page 11: Session Time
1 to 5 (from 50° to 145° per minute) • Force 1 to 6 • Extension pause 0 to 900 seconds (15 minutes) • Flexion pause 0 to 900 seconds (15 minutes) • Timer No timer (00H00) to 24H00 KINETEC CEM™ 10/22... -
Page 12: To Set The Parameters For A Single Movement
ELBOW MODULE The unit is ready to start with the or wait more than 3 seconds. The display new parameters. STOP shows the selected mode Comments: • The values in the display column are given as an example. KINETEC CEM™ 11/22... -
Page 13: Program Mode: To Enter A Program
KINETEC To exit program mode, switch the unit OFF To use the modified program see and switch back ON. page 14. ELBOW MODULE 0.6 Comments: • The values in the display column are given as an example. KINETEC CEM™ 12/22... - Page 14 USING THE HAND CONTROL PROGRAM MODE: To enter a program Comments: PROGRAM NR11 • When a program has been deleted, the display shows EMPTY Program table: KINETEC CEM™ 13/22...
-
Page 15: Using Programs
USING THE HAND CONTROL 12. Using Programs The device KINETEC CEM™ allows you to store up to 16 programs (numbered 1 to 16), including the type of movement, ROM, speed, load, pauses and timer. The original parameter values of the program are empty. These values can be modified and saved at any time (see ‘To enter a program’, page 12) -
Page 16: To Use The Warm Up Key
20 RUN Warm Up rules. The device KINETEC CEM™ starts at 70% of the full ROM, increasing 5% of the range each full cycle until the pre-set ROM is reached. Note: - The parameters should only be modified while the unit is stopped. -
Page 17: To Define The Patient Tolerance • At The Start Of A Session
This function shows the running time (in minutes) of the session (motor functioning). • It is directly accessible by the key , the display shows TIME 02h25 This counter is reset each time the unit is switched ON. KINETEC CEM™ 16/22... -
Page 18: Using The Kinetec Patient Pad Kit
USING THE KINETEC PATIENT PAD KIT The device KINETEC CEM™ is delivered with 3 straps: • 1 - Arm strap (A) • 2 - Forearm straps (B) • 1 - Elbow protection (C) All these straps are used the same way (see pictures). -
Page 19: Setting Up The Patient
The knob (8) allows you to adjust the prono- supination position. Install the arm support (5). • Starting the movement: - Set the movement parameters (see page 11). Then press - or select a program (see page 14). KINETEC CEM™ 18/22... -
Page 20: Product Information
1. Maintenance After 2,000 hours of operation, or once a year, the device KINETEC CEM™ requires lubrication and maintenance operations (lubrication of the joints and pointer stops). The need for maintenance is indicated by display of the message SERVICE TIME Mx when the system is switched on. -
Page 21: Technical Specifications
® Kinetec SAS guarantees its continuous passive motion systems for 2 years against all defects of manufacture from the date of purchase by the consumer. Kinetec SAS is the only organization able to assess the application of the warranty to its systems. -
Page 22: Guidance And Manufacturer's Declaration
KINETEC CEM™ immunity. WARNING: the device KINETEC CEM™ should not be used next to other appliances. If the device KINETEC CEM™ must be used next to other appliances, it should be under constant supervision to check that it is working normally in the given configuration. - Page 23 Guidance and manufacturer’s declaration - Electromagnetic immunity The device KINETEC CEM™ is intended for use in the electromagnetic environment specified below. The customer or the user of the device KINETEC CEM™ should ensure that it is used in such an environment.
- Page 24 Kinetec SAS Zone Industrielle de Tournes Rue Maurice Périn F-08090 Tournes France +33 (0)3 24 29 85 05 +33 (0)3 24 33 51 05 contact@kinetec.fr www.kinetec.fr...
