Summary of Contents for Risco GT480

  • Page 1 Installation Instructions...
  • Page 3: Table Of Contents

    Contents Introduction ......1 Display Status Blanking ....1 Pre Setting Error Check .
  • Page 4: Introduction

    Introduction The GT480 control panel is supplied as a blank fronted end station complete with LCD RKP. Up to 3 additional keypads may be fitted if required. Two types of keypad are available, the 480 Profile RKP that offers two additional zones from the RKP (fixed as E/E + Chime & Access) or the eurosec CP8L RKP with no RKP Zones.
  • Page 5: Battery Fuse

    IMPOR ANT! IMPOR ANT! Input: AC230V +/-10% ~50Hz 125mA Max. 35W Max For Indoor Use Only Nominal Temp Range: 0° - 50° Centigrade This equipment is intended only for use as a Security Alarm Control Panel. Adequate ventilation away from heat and humidity must be provided. The unit must be fixed securely to a non-flammable surface using suitable fixings.
  • Page 6: Installation

    Control Panel & RKP Location Consideration needs to be given to the location of the Control Panel & LCD RKP with regards The surface that the unit(s) are to be fixed to should be firm, vibration free, damp free and fire resistant.
  • Page 7: Wiring

    General Detector Wiring We would strongly suggest that you adopt a colour scheme for the detector wiring of your system. This will enable you to quickly determine the source of any problems that may occur. The security industry does not have recommended colour schemes because of the nature of the wiring, one suggested scheme is given below.
  • Page 8: Wiring Passive Infra-Red Detectors

    Fig. 2 Wiring Single Contact Fig. 3 Wiring Double Contact (on the same zone) Wiring Passive Infra-Red Detectors It is essential when using Passive Infra-Red Detectors that you refer to the manufacturers instruction as to the positioning and settings of the detector. This section is intended as a guide to the wiring of the detectors.
  • Page 9: General Bell Box Wiring

    General Bell Box Wiring As with the detector wiring we would suggest that you adopt a standard for your Bell Box wiring, the colour scheme below is provided as a suggestion only. Hold Off Supply +....Red Hold Off Supply - ....Black Trigger........
  • Page 10 Fig.6E Fig.6F CQR Integra HS Texecom Azura Control bellbox connections bellbox connections panel terminals Control Common panel terminals (Select AT Return) SAB TMP SAB TMP AT Return Bell Hold - Bell Hold - Supply -VE Bell - Bell - Siren Trigger -VE Bell + Bell + Supply +VE...
  • Page 11: Wiring Notes

    Wiring Notes Fig. 7 Control Panel Connections The 680 Ohm resistor (provided) must be fitted across 12v & D1 at the last RKP in line. Maximum current draw from the panel MUST Remove 2K2 NOT EXCEED 1Amp*. (See Page 23 for further if using Keypad zones.
  • Page 12: Programming

    Terminology Various terms are used throughout this manual that may be unique to the GT480 control panel. This section gives brief details of this terminology. Zones Alert 12Hr Internal Speaker only. A zone programmed as 12Hr is active when the system is set.
  • Page 13: Engineer Programming Mode

    Engineer Programming Mode Several options are available via the Engineer code (1234 factory default). These are Setting and Unsetting of the system. Engineer/User Options System Test Delete Zone(s) Chime On/Off Program Code Set Time/Date View Log Program Engineer Options Details of items a and b are given in the User manual. Please refer to it when programming these modes.
  • Page 14 Press No ( ). The display will show:- Do You Want to . . You are now in Engineer mode. Test ? Press No ( ). The display will show:- Do You Want to. . Delete Zone ? Press No ( ). The display will show:- Do You Want to.
  • Page 15 Select a number corresponding to the zone you wish Zone 1 Type to program. The display will show, for example:- E / E Press No ( ) until the required zone type is displayed. Note: Please see page 9 for zone terminology. Press Yes.
  • Page 16: Programming Exit / Entry Times

    Press No ( ). The display will show:- Program ..Entry / Exit Press 0 twice to escape out of Engineer Mode. Programming Exit / Entry Times Two entry times are available (Entry Time 1 & Entry Time 2). On entry to the premises via the entry door, the Entry Time 1 will start.
  • Page 17 Press No ( )until the required setting is displayed. Then press Yes ( ). The display will show:- Quick-Set Note: The Quick-Set is no longer applicable on the GT480 Control Panel Entry 1 Time Press Yes ( ). The display will show:- (Default 30 seconds) .
  • Page 18: Programming Bell & Panic

    Programming Bell & Panic Program ..With the display showing:- Press Yes ( Bell & Panic ? The display will show:- Ring Time Default Bell Time is 10 Minutes. To change, press No ( ) followed by the required time. Note: Bell ring time is programmable to a maximum of 15 minutes The minimum time allowed is 1 minute.
  • Page 19: Programming Pgm1 Output

    Press No ( ) until the required Bell Mode is displayed. Tamper Ring Then press Yes ( ). The display will show:- Press No ( ) to set the Bell Tamper Ring Mode On or Off. Then press Yes ( ).
  • Page 20: Programming Reset & Keypad

    Press 0 to escape back one level. Then press No ( ) to go Program ..to the next Header. The display will show:- Reset & Keypad ? Press 0 three times to escape out of Engineer Mode. Programming Reset &...
  • Page 21: Engineer Reset (After An Alarm)

    Engineer Reset (After an Alarm) If the Reset Mode(s) has been programmed for Engineer follow the steps below to reset the system. The user must first unset the system. Details in User manual. With the display showing:- ! ! ! ! CHECK ! ! ! ! ! Enter the Engineer code followed by Yes ( Exit Now ! .
  • Page 22: Resetting To Factory Defaults

    Resetting to Factory Defaults If required the unit may be reset to factory defaults. It should be noted that if the engineer code begins with a 9 it will not be defaulted. Remove all power from the system. Wait 10 seconds. Re-Apply power to the system.
  • Page 23: Troubleshooting

    Fault Action Control Panel will not power up from the Check / replace fuse in fused spur or mains mains supply. connection block. Also check all connections for trapped insulation. Display shows zone fault and panel will Remove zone wires from the problem zone at not set after the exit time has expired.
  • Page 24 Fault Action Tamper is not tripped when a detector Check to see if all tampers are wired in series. cover is removed. If detector tampers have been wired in parallel they will all have to be removed before the tamper would trigger. Check for short circuits that may occur through staples piercing cables.
  • Page 25: Specifications

    Specifications Power Input: 230v a.c +/- 10% @50Hz No. of Zones: GT480 = 8 LCD Max Loop Resistance: 2K Ohms Loop Delay Time: 300 milliseconds Fuses: Mains Fuse: 200mA slow blow F2 Misc Fuse: 250mA quick blow F1 System Fuse:...
  • Page 26: System Details

    *Power Supply Rating It should be noted that the eurösec GT480 has 1 Amp available for the full system. However, for the purpose of compliance to EN and PD6662 standard, the capacities of the power supply have to be specified differently.
  • Page 27: Changing The Engineer Code

    Changing the Engineer code The engineer code may only be changed by use of the current engineer code. If the engineer code starts with a 9 the code will be ‘locked in’ defaulting the panel will have no effect on the engineer code. To program the engineer code proceed as follows:- In order to access Engineer Mode the User MUST start to set the system, then the Engineer must enter the Engineer code TWICE.
  • Page 28 Tel: 0161 655 5500 Fax: 0161 655 5501 Internet: www.riscogroup.co.uk Technical Support: 0161 655 5600 Technical Support Fax: 0161 655 5610 Technical Support e-mail: technical@riscogroup.co.uk Risco Group UK Ltd reserve the right to amend the software and features without prior notice Supplied By:- 5IN480IM B PR5832 Rev1.1...
