Separated converter dimensions
The separated type is generally used in on-site
maintenance and debugging reading inconvenient
occasions, but also used in more severe applications,
such as high-temperature fluids and vibration sources.
On most occasions, the integrated and separated
types can both meet the requirements.
is ≥500mm, the separated type is recommended for
easy maintenance; when the meter is installed below
the ground, the separated type, IP68 protection level
structure must be selected; when the meter is
unavoidably installed at the pump outlet, please
choose a separated structure meter

6 Specifications

Diameter
Measurement accuracy
Electrode type
Structure type
Rated pressure
Electrode material
Lining material
Measured pipe
flange/body flange
converter housing
Power supply
Flange type: DN6~DN1600, ≥DN20 with built-in grounding electrode
Sanitary type: DN6~DN50
Threaded type: DN6~DN50
Clamping type: DN10~DN300
0.2%，0.5%
Standard fixed electrode, antifouling electrode
DN6~DN20: a pair of measuring electrodes, no grounding electrodes
DN25~DN500: a pair of measuring electrodes and a pair of grounding electrodes
≥DN600: 2 pairs of measuring electrodes and a pair of grounding electrodes
Integrated type, separated type (cable length of separated type≤100m)
GB: PN2.5, PN6, PN16, PN25, PN40, PN63, PN100, PN160, PN250
ANSI: CLASS 150, CLASS 300, CLASS 600, CLASS 900
DIN: PN10, PN16, PN25, PN40, PN63
JIS: 5K,10K,16K,20K,30K,40K,63K
Others: customizable
316L, Ti, HB/HC, Ta, WC, Pt
Neoprene (CR), Natural Rubber (NR), Polyurethane Rubber (PU)
Polytetrafluoroethylene (PTFE), F46, PFA
Stainless steel
Carbon steel (standard), stainless steel (optional)
Aluminum die-casting
100 V AC~240V AC
12V DC,24V DC
Battery supply (LCD display, RS485 output, wireless output, frequency/pulse output, and the
frequency/pulse output is used only for calibration or calibration purposes.)
Solar power with storage battery
44
71
Figure 4 Separated converter dimensions
Table4
5
3× 7
102
34
70
164
