Users can query 4 types of reports: daily, monthly, annual, and power outage reports. The meter can
save up to 90 daily reports, 36 monthly reports, 3 annual reports and 20 power outage reports.

Parameters setting

11.2
In the main interface state (Figure 8), press
interface (Figure 10). The user enters the corresponding password by entering different levels of
passwords. The menu sets the parameters related to the use of the flowmeter.
Special tips: Please operate carefully when setting, so as to avoid the failure of the flowmeter due to the
parameter setting!

Level 1 password menu

11.3
Users enter the menu through level 1 password "19818" and can set the parameters in the menu. The
specific parameter information and data type are shown in Table 10.
Items Functions
Communication
1
address
Communication
2
rate
Day Report
Month Report
Year Report
Power Report
Figure 16 Report query interface
+ ("shift" + "enter") to enter the password input
Pass Word Input
00000
Figure 17 Password input interface
Table 10
Setting/Instructions
COM Address
001 k
COM Baud Rate
9600 N
14
Parameter Range
Range:0~255
Rate:1200,2400,4800,9600,14400
Check: no check, odd parity Check, even
parity check
