5 Outline Structure

IIntegrated flange connection dimensions
A: duct length of flowmeter; H: flowmeter height; N: bolt holes quantity; L: bolt hole diameter; K: center
circle diameter of bolt hole; D: flange outside diameter.
Integrated flowmeter dimensions
Rated Pressure
DN
(MPa)
6
10
15
20
25
4.0
32
40
50
65
80
100
1.6
125
150
200
250
300
350
400
450
1.0
500
600
700
800
900
1000
1200
1400 0.6
1600
Figure 2 Integrated Outline Dimension
Table 2 Integrated flowmeter dimensions
Outline Dimension(mm)
A
150 304
150 304
150 304
150 304
150 312
150 330
150 340
200 338
200 358
200 374
250 402
250 425
300 458
350 522
400 574
500 624
500 678
600 742
600 794
600 862
600 950
700 1058
800 1166
900 1272
1000 1376
1200 1578
1400 1840
1600 2078
3
Flange Connection Dimension(mm)
H D
Φ90
Φ90
Φ95
Φ105
Φ115
Φ140
Φ150
Φ165
Φ185
Φ200
Φ220
Φ250
Φ285
Φ340
Φ395
Φ445
Φ500
Φ656
Φ615
Φ670
Φ780
Φ895
Φ1010
Φ1110
Φ1220
Φ1405
Φ1630
Φ1830
K n×L
Φ60 4×Φ14
Φ60 4×Φ14
Φ65 4×Φ14
Φ75 4×Φ14
Φ85 4×Φ14
Φ100 4×Φ18
Φ110 4×Φ18
Φ125 4×Φ18
Φ145 8×Φ18
Φ160 8×Φ18
Φ180 8×Φ18
Φ210 8×Φ18
Φ240 8×Φ23
Φ295 8×Φ23
Φ350 12×Φ23
Φ400 12×Φ23
Φ460 16×Φ23
Φ515 16×Φ25
Φ565 20×Φ25
Φ620 20×Φ25
Φ725 20×Φ25
Φ840 24×Φ30
Φ950 24×Φ34
Φ1050 28×Φ34
Φ1160 28×Φ34
Φ1340 32×Φ34
Φ1560 36×Φ36
Φ1760 40×Φ36
