- Page 1 Operating and installation instructions REMKO SKM series Local room air conditioner SKM 240, SKM 340 0170-2019-06 Edition 3, en_GB Read the instructions prior to performing any task!
- Page 2 Read these operating instructions carefully before commis- sioning / using this device! These instructions are an integral part of the system and must R410A always be kept near or on the device. Subject to modifications; No liability accepted for errors or mis- Refrigerant prints! Translation of the original...
-
Page 3: Table Of Contents
Table of contents Safety and usage instructions......................4 1.1 General safety notes........................4 1.2 Identification of notes........................4 1.3 Personnel qualifications........................4 1.4 Dangers of failure to observe the safety notes................4 1.5 Safety-conscious working....................... 4 1.6 Safety notes for the operator......................5 1.7 Safety notes for installation, maintenance and inspection.............. -
Page 4: Safety And Usage Instructions
REMKO SKM series Safety and usage instructions CAUTION! This combination of symbol and signal word 1.1 General safety notes warns of a potentially hazardous situation, which if not avoided may cause injury or mate- Carefully read the operating manual before com- rial and environmental damage. -
Page 5: Safety Notes For The Operator
"certificate of warranty" to with all applicable regional regulations. REMKO GmbH & Co. KG at the time when the Local regulations and laws such as Water units are purchased and commissioned. -
Page 6: Transport And Packaging
REMKO SKM series 1.11 Transport and packaging The devices are supplied in a sturdy shipping con- tainer. Please check the equipment immediately upon delivery and note any damage or missing parts on the delivery and inform the shipper and your contractual partner. For later complaints can not be guaranteed. -
Page 7: Technical Data
Technical data 2.1 Unit data Series SKM 240 SKM 340 Operating mode Local compact air conditioning unit for cooling 2.40 3.40 Nominal cooling output Energy efficiency ratio - cooling Energy efficiency rating EER Energy consumption, hourly kWh/60 min 0.92 1.30 Application area (room volume), approx. -
Page 8: Design And Function
REMKO SKM series Design and function 3.1 Unit description The local air conditioning unit is particularly well suited to flexible use. The local room air conditioner comprises a floor- standing unit for the indoor area and an exhaust air hose to conduct the heat away. The indoor unit... -
Page 9: Operation
Operation The system can be operated by means of the control panel on the unit or via the standard infrared remote controller. The functional operation of the keys is identical, however, the designation may vary. The batteries must be correctly inserted before the infrared remote control is used. Fig. - Page 10 REMKO SKM series Selection of the operating mode "Mode" Switch the unit on with the "On/off" key Cooling Press the "Mode select" key until the yellow LED illuminates. The unit provides room cooling. It filters and dehumidifies the air thereby creating a comfort- Select the setting for the fan with the "Fan...
-
Page 11: Assembly And Installation
Assembly and installation Help save on energy consumption in stand-by Assembly and unit installation instructions mode! If the device, system or component is not in use, we recommend disconnecting the power The unit is positioned at the desired location with supply. - Page 12 REMKO SKM series Check whether the stopper in the condensate Conduct the warm exhaust air away drain is present and correctly installed. There is a risk of uncontrolled condensate leakage after NOTICE! commissioning. The exhaust air hose should always be laid...
- Page 13 Via a wall pass-through The hose supplied is firmly attached to a wall pass- through. A suitable wall pass-through is available as an accessory (Fig. 12). Fig. 12: Wall pass-though NOTICE! In some circumstances routing the exhaust air Fig. 10: Exhaust air with open window via a firmly attached exhaust air hose, e.g.
- Page 14 REMKO SKM series Installation scheme for wall pass-though (accessory) Fig. 13: Installation example 1: External grill 2: Telescopic tube 3: Non-return flap 4: Sealing cover Installation instructions Create a core hole in the exterior wall (max. wall thickness 480 mm) with a diameter of at least 135 mm.
-
Page 15: Electrical Wiring
Electrical wiring Electrical drawings Fig. 14: Electrical drawings Mains power circuit board Condenser fan Control panel control board Colour coding: Power plug Brown Microswitch (reservoir) Blue Temperature sensor, recirculation Evaporator fan White Compressor We reserve the right to modify the dimensions and design as part of the ongoing technical development process... -
Page 16: Commissioning
REMKO SKM series Commissioning Before every commissioning the air inlet and outlet openings should be checked for foreign bodies and the air inlet filter must be checked for dirt. Blocked or soiled grids and filters must be cleaned immedi- ately, see "Care and maintenance" chapter. -
Page 17: Troubleshooting And Customer Service
Troubleshooting and customer service The unit has been manufactured using state-of-the-art production methods and has been tested several times to ensure that it works properly. If malfunctions should occur, please check the unit as detailed in the list below. Please inform your dealer if the unit is still not working correctly after all the function checks have been performed. - Page 18 REMKO SKM series Fault description Cause Remedy The unit does not cool prop- LED cooling indicator The "Cool" LED indicator must illuminate erly Windows, doors, blinds Close and curtains Exhaust air hose Must be properly attached. It must not be kinked, sloping downwards or laid in bends that are too tight.
-
Page 19: Care And Maintenance
Care and maintenance Filter cleaning The unit is equipped with an air filter. This can be Regular care and observation of some basic points withdrawn from the rear of the unit. The filter must will ensure trouble-free operation and a long be cleaned at regular intervals. -
Page 20: Shutdown
Permanent shutdown The entire system should only be dismantled by a specialist firm familiar with all environmental aspects involved. REMKO GmbH & Co. KG or your sales partner will be pleased to provide details of refrigerant specialists in your area. -
Page 21: Exploded View And Spare Parts Lists
Exploded view and spare parts lists 11.1 Exploded view of the unit SKM 240 Fig. 18: Exploded view drawing SKM 240 We reserve the right to modify the dimensions and design as part of the ongoing technical development process. -
Page 22: Spare Parts List Skm 240
Spare parts list SKM 240 Please contact REMKO GmbH & Co. KG directly to order spare parts. All the spare part numbers for your unit can be found in the download area at www.remko.de. IMPORTANT! To ensure the correct delivery of spare parts, please always the device type with the corresponding serial... - Page 23 Designation SKM 240 Control board Display board Control panel Display board plastic fastener Control board housing Control board retaining plate Control board cover Condensate tank sealing stopper union nut Condensate container sealing stopper Temperature sensor, recirculation Condensate sealing cap Exhaust air hose air outlet protection grid Protection grid fastening frame Housing front cover Air outlet grid...
- Page 24 REMKO SKM series Designation SKM 240 Spare parts not illustrated On request by pro- Probe, ambient air viding the serial number Accessories Wall pass-though 1613115...
-
Page 25: Exploded View Of The Unit Skm 340
11.3 Exploded view of the unit SKM 340 Fig. 19: Exploded view drawing SKM 340 We reserve the right to modify the dimensions and design as part of the ongoing technical development process. -
Page 26: Spare Parts List Skm 340
Spare parts list SKM 340 Please contact REMKO GmbH & Co. KG directly to order spare parts. All the spare part numbers for your unit can be found in the download area at www.remko.de. IMPORTANT! To ensure the correct delivery of spare parts, please always the device type with the corresponding serial... - Page 27 Designation SKM 340 Evaporator fan roller housing, bottom part Fan roller Fan roller ball bearing Fan motor, evaporator Evaporator fan roller housing, top part Evaporator Display board housing Display board plastic fastener Control panel Display board plastic cover Side section, housing, left Side section, housing, right Housing front Housing front cover...
- Page 28 REMKO SKM series Designation SKM 340 Window nozzle Infrared remote control Designation SKM 340 Spare parts not illustrated On request by pro- Probe, ambient air viding the serial number Accessories Wall pass-though 1613115...
-
Page 29: Index
Index Dehumidifying mode ....10 Operating mode "Mode" ....10 Assembly . - Page 30 REMKO SKM series...
