Rocstor Y10A320-S1 User Manual

User Manual
Type-C to HDMI/USB-A 10GX2/Type-C 10G data/SD/TF/
PD Charging with DP1.4 Alt mode
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
Introduction
Rocstor introduces the Type-C 7-in-1 hub with HDMI, 2 USB-A ports, Type-C data,
SD/TF card slots, and a Type-C PD charging port—a versatile solution for expanding
the port options of Type-C or Thunderbolt hosts (PC/Laptop/Mobile phone, etc.),
particularly suited for devices with a single Type-C port. This hub facilitates HDMI video
output at a maximum resolution of 4k/60Hz while concurrently transferring USB 3.1
Gen2 data at a maximum speed of 10Gbps. With 2 USB-A ports and a Type-C data port,
you can connect up to 3 USB devices simultaneously. The SD/Micro SD card slots
accommodate the simultaneous insertion of 2 cards, enabling data transmission or
reading/writing information on the host. Additionally, the Type-C female port supports
PD 3.0 with a maximum power delivery of 100W PD Charging. Compatible with all DP
Alt mode supported Type-C hosts, this hub ensures seamless compatibility and
enhanced functionality.
Package Contents
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in it:
• Main Unit x1
• User Manual
Y10A320-S1
®
Features
Upstream:
USB Type-C Male (Connect to a host computer)
• Supports DP1.4 Alt mode,downward compatible with DP1.2 Alt mode
• Supports USB3.0/2.0 data transmission (transfer speed: Max 10Gbps)
• Supports transmission of DP Alt Mode video up to 4K/60Hz Simultaneously
Note: To get max bandwidth, the host should support DP1.4 Alt mode & DSC
Downstream:
HDMI X1
• Supports HDMI max 4K/60Hz
• Supports 8/10/12 bit color depth output
• Supports output pixel format
RGB/YCbCr4:4:4/YCbCr4:2:2/YCbCr4:2:0
• Supports dynamic HDR10+
• Supports HDCP2.3 & HDCP1.4
Note: The actual resolution supported is
determined by the host and the display.
Type-C Data 10G X1
(Close to HDMI)
• Max 10Gbps data transmission
• Supports max 1.5A downstream charging
• Supports short-circuit, over-current,
over-voltage protection
USB-A X2
• Max 10Gbps data transmission per port
• Supports max 7.5W(5V/1.5A)
downstream charging the port close to
Type-C male port, another port supports
max 900mA downstream charging.
• 2 USB-A port share max 7.5W(5V/1.5A)
,the 2USB-A and the Type-C data port
share max 12W(5V/2.4A)
• Supports short-circuit, over-current,
over-voltage protection
Speci cation
Input / Output Connector
Input
Output
Mechanical
Weight Operating Temperature
Size
Warranty
Limited Warranty
Environmental
Operating Temperature Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Regulatory Approvals
Certi cations
Accessory Adapter
User Manual
SD/Micro SD 3.0 X1
• Supports SD3.0 data transmission up
to 104MBps
• Allow 2 card slots to work simultaneously
• TF card slot with self-ejecting
mechanism by pressing
Type-C Female X1
(for PD Charging & Data)
• Supports max 100W PD charging
• Supports PD3.0 Fast Role Swap, the
connected device will not get
disconnected while plugging out
PD Adapter
• 15W is dedicated to the functioning of
this product, the rest power (max 85W)
will be passed to charge for the host
Type-C Male x1
HDMI Female x1
USB-A 10G x2
Type-C 10G data x1
SD/Micro SD 3.0 x1
Type-C PD Charging x1
3.4lbs - (99g) 0°C to 45°C (32°F to 113°F)
4.5x1.9x0.5in - (115x50x14mm)
3 Years
0°C to 45°C (32°F to 113°F)
10% to 85% RH (no condensation)
-10°C to 70°C (14°F to 158°F)
5% to 90 % RH (no condensation)
FCC, CE
English Version
