Rocstor Y10A325-B1 User Manual

User Manual
HDMI to DisplayPort Female (8K) Adapter
with USB-A 5V Power supply
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
Introduction
Rocstor introduces the HDMI to DisplayPort Adapter, featuring USB-A 5V Power Supply,
enabling signal transmission from HDMI sources (such as DVI, tablets, PCs, etc.) to
DisplayPort display devices (like TVs, monitors, projectors, etc.) using a DisplayPort
M/M Cable. This product adheres to DP1.4 speci cation, supporting resolutions up to
8K@30Hz or 4K@120Hz.
Package Contents
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the packaging:
• Main Unit x1
• User Manual
Y10A325-B1
®
Features
Upstream:
HDMI X1
• Supports 8/10/12bit color Depth
• Supports HDCP1.4/2.2/2.3
• Supports HDR
• Supports Status and Control Data
Channel (SCDC)
• Supports Resolution up to 8K@30Hz
for 4:4:4 format
Downstream:
DisplayPort Female X1
• Supports DP1.4 speci cation,
resolution up to 8K@30Hz or or
4K@120Hz
• Supports Four Lanes with 1.62Gbps
(RBR), 2.7Gbps (HBR), 5.4Gbps (HBR2),
or 8.1Gbps(HBR3) Data Rate per lane
• Supports HDCP1.3/2.2/2.3
• Supports 8/10/12 bit color depth,
supports output pixel format
RGB/YCbCr4:4:4/YCbCr4:2:2
• Supports Hot-Plug Detect
• Supports HDR
Speci cation
Input / Output Connector
Input
Output
Mechanical
Weight Operating Temperature
Size
Warranty
Limited Warranty
Environmental
Operating Temperature Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Power Supply
Regulatory Approvals
Certi cations
Accessory Adapter
User Manual
USB-A Male X1
• Connect to 5V power and supply
power for the product
• The connected power should be no
less than 5V/500mA
• Supports FW updates to this product
through this port
HDMI Male x1
USB-A 5V Power Port x1
DisplayPort Female x1
0°C to 45°C (32°F to 113°F) 3.2lbs (92g)
2.8x2.3x0.6in (72x60x16mm)
3 Years
0°C to 45°C (32°F to 113°F)
10% to 85% RH (no condensation)
-10°C to 70°C (14°F to 158°F)
5% to 90 % RH (no condensation)
USB-A (External 5V/500mA Power)
FCC, CE
English Version
