Rocstor Y10A331-S1 User Manual

User Manual
USB-C to Hi-Res AUX 3.5mm Audio
with 100W Power Delivery (PD) Adapter
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
Introduction
Introducing a Type-C Hi-Res audio adapter featuring PD&QC charging capabilities. This
adapter facilitates seamless connectivity between Type-C enabled PCs, laptops, or
smartphones and your 3.5mm audio peripherals such as headphones, headsets,
speakers, or microphones. Enjoy immersive music playback or record with ease while
keeping your device charged. The USB-C female port not only charges the host device
but also powers the adapter simultaneously.
• This product is compatible with Type-C hosts supporting USB digital audio
transmission but not with those supporting only analog audio mode.
• Phone call functionality is not supported on Samsung S8, Note 9, or Blackberry
Keyone devices.
• When connecting to a Type-C mobile phone without PD function, audio and charging
functions are mutually exclusive, with charging taking precedence.
• On Type-C mobile phones without data role swap support, audio may temporarily
halt upon plugging in the power adapter.
• On Type-C mobile phones or laptops lacking Fast Role Swap support, audio may
brie y pause and resume automatically upon power adapter disconnection.
Package Contents
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the packaging:
• Main Unit x1
• User Manual
Y10A331-S1
®
Features
Upstream:
USB-C Male X1 (connect Type-C device)
• Stereo Digital-to-Analog Converter with 93dB SNR for audio output
• Supports digital Hi-Res Audio(High Resolution Audio)
• DAC supports 44.1/48/96KHz Sample Rate, 16/24-bit
• ADC input supports 48KHz Sample Rate, 16bit
• Compatible with CTIA & OMTP
Downstream:
USB-C Female X1
• Supports PD3.0&QC2.0
• Supports PD Charging with power up to
100W (20V/5A)
• Supports QC2.0 Charging with power up
to 18W
Speci cation
Connector
Connector
Channel
SNR
Sampling frequency
Warranty
Limited Warranty
Environmental
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Power Consumption
Standby Power Consumption
Operating Power Consumption
Certi cations
Power Requirement
Power Source
Accessory Adapter
User Manual
3.5mm Female X1
• Audio Jack Detection with Auto-Switch
Type-C Male x1
Headphone/Mic Connector x1
Type-c Female x1
Dual-channel 2.0
93dB
96KHz
2 Years
0°C to 45°C (32°F to 113°F)
10% to 85% RH (no condensation)
-10°C to 70°C (14°F to 158°F)
5% to 90 % RH (no condensation)
<5V/10mA
<5V/85mA
FCC,CE
USB Bus Power or PD/QC power adapter
(PD Up to 100 W, QC Up to 18 W)
English Version
