Rocstor Y10A339-B1 User Manual

User Manual
Premium USB-C to 2.5 Gb Ethernet with
USB-C 100W Power Delivery PD 3.0 Adapter
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Keep this manual for future reference.
Introduction
Rocstor introduces the Type-C 2-in-1 Hub, featuring both a 2.5G Ethernet port and a
Type-C PD charging port. This versatile solution o ers an ideal way to expand the
connectivity options of Type-C or Thunderbolt hosts, whether it's a PC, laptop, or
mobile phone—perfect for devices with a solitary Type-C port. With cutting-edge IC
technology, our hub delivers lightning-fast 2.5G Ethernet support, ensuring an
e cient internet experience. Additionally, the Type-C female port supports PD 3.0 with
up to 100W PD Charging, allowing for swift device charging. Compatible with
Macbooks, Google's latest Chromebook Pixel, and various USB-C supported hosts, PCs,
and computers, our hub promises seamless integration and superior performance for
all your connectivity needs.
Package Contents
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the packaging:
• Main Unit x1
• User Manual
Y10A339-B1
®
Features
Upstream:
Type-C Male X1 Host Computer
• Supports USB-C plug and play, hot swap
• Supports 2.5G Ethernet
• Supports to work with Macbook/Chromebook Pixel and other USB-C supported PCs
• No extra driver software is required, and auto driver installation
• Supports twisted pair crossover detection and auto-correction
Downstream:
Type-C PD Charging X1
• Support PD3.0 with max 100W
PD charging
• Support fast role swap of PD3.0, the
connected device will not get
disconnected while plugging out
PD Adapter
Speci cation
Input/Output Connector
Input
Output
Physical
Weight
Size
Environmental
Operating Temperature Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Power Requirement
USB-C Female Port
Warranty
Limited Warranty
Regulatory Approvals
Certi cations
Accessory
User Manual
RJ45 X1
• Supports Gigabit Ethernet
10M/100M/1000M/2.5G
• Supports Wake-On-LAN
• Supports full duplex ow control
• Light indicates the state, no light when
no Internet connected, orange light
turns on when network connection is
established, green light ashes when
transmitting data.
USB-C Male x1
2.5G Ethernet x1
USB-C PD3.0 Charging x1
0.8lbs (24g)
2.9x0.8x0.5in (74x21.5x15mm)
0°C to 40°C (32°F to 104°F)
10% to 85% RH (no condensation)
-10°C to 70°C (14°F to 158°F)
5% to 90 % RH (no condensation)
UP to 100W(20V 5A)
2 Years
FCC, CE
English Version
