Rocstor Y10A303-B1 User Manual

Type-C to Triple DisplayPort Adapter with DP1.4 Alt mode
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
Introduction
Rocstor introduces the Type-C to Triple DisplayPort Adapter, designed to expand the
host's Type-C port into three DisplayPort ports, o ering ultra-high-de nition display
capabilities. With support for DP1.4 Alt mode and a maximum bandwidth of 32.4Gbps,
this product enables the output of a single max 8K DP1.4 video or dual max 4K/60Hz
videos, or even triple videos (max 4K/60Hz + 2x4K/30Hz) simultaneously under MST
mode. Compatible with all DP Alt mode supported Type-C/Thunderbolt PCs, this
adapter delivers seamless performance and enhanced display options.
Package Contents
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the packaging:
• Main Unit x1
• User Manual
System Requirements
Working on Windows System
• Support to output dual 4K/60Hz with di erent pictures under MST mode
• Support to output triple videos(max 4K/60Hz+2x4k/30Hz) with di erent pictures
under MST mode
Working on Mac OS System
• Support to output max triple max 4K/60Hz under SST mode (output the same
picture)
Note: To achieve the above resolution, the host should support DP1.4 Alt mode, when
working on DP1.2 host, the corresponding resolution will be decreased due to
bandwidth limitation. The above resolution combination is for theoretical reference,
the actual output resolution depends on the connected host and displays
User Manual
Y10A303-B1
®
Features
Upstream:
USB Type-C Male (Connect to a host computer)
Downstream:
DisplayPort X3
• Supports Type-C input, 3 DisplayPort
outputs
• Supports DP1.4 Alt mode
• Supports DSC
• Supports 6/8/10 bit color depth output
• Supports output pixel format
RGB4:4:4/YCbCr4:4:4/YCbCr4:2:2/YCbCr4:2:0
• Supports HDCP2.2&1.4
• Supports HDR which ensures every
moment of a video is displayed at its
ideal values for depth, detail,
brightness, contrast and wider color
gamuts—on a scene-by-scene or even
a frame-by-frame basis
• Supports DP1.4 with max 4K/60Hz for
one video output
Speci cation
Input / Output Connector
Input
Output
DisplayPort
Resolution
HDR
HDCP Version
Environmental
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Power Requirement
Power Source
Standby Power Consumption
Mechanical
Size (L-W-H)
Weight (Net)
Warranty
Limited Warranty
Regulatory Approvals
Certi cations
Accessory Adapter
User Manual
USB-C Male x1
DisplayPort Female x3
Max one 4K/60Hz or dual 4K/60Hz
Support
HDCP2.2&1.4
0°C to 45°C (32°F to 113°F)
10% to 85% RH (no condensation)
-10°C to 70°C (14°F to 158°F)
5% to 90 % RH (no condensation)
Bus Power
≤1W
9.9x1.4x0.45in (252x36x11.5mm)
1.86lbs (51g)
1 Year
FCC, CE
English Version
