Rocstor Y10A306-B1 User Manual

Type-C to HDMI/USB-A/Type-C Female(PD&Data)
with DP1.4 Alt mode
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
Introduction
Rocstor introduces the Type-C 3-in-1 hub, featuring HDMI, USB-A, and a Type-C female
port, o ering an ideal solution for extending the port capabilities of Type-C/Thunder-
bolt 3 hosts (PC/Laptop/Mobile phone, etc.), particularly useful for those with a single
Type-C port. Equipped with the latest DP1.4 Alt mode supported IC, this hub enables
HDMI video output at a maximum resolution of 4k/60Hz while simultaneously
transferring USB 3.1 data at up to 5Gbps. Additionally, the Type-C female port supports
PD 3.0 with a maximum power delivery of 100W when connected to a PD Adapter and
facilitates data transmission at a maximum speed of 5Gbps when connected to a
Type-C device. Compatible with all DP Alt mode supported Type-C hosts, this hub
ensures seamless compatibility and enhanced functionality.
Package Contents
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the packaging:
• Main Unit x1
• User Manual
User Manual
Y10A306-B1
®
Features
Upstream:
USB Type-C Male (Connect to a host computer)
• Supports DP1.4 Alt mode, downward compatible with DP1.2 Alt mode
Note: To get max bandwidth, the host should support DP1.4 Alt mode with DSC format
Downstream:
HDMI
• Supports HDMI max 4K/60Hz， 4 ： 4 ： 4,
8bit with 18Gbps Bandwidth
• Supports 6/8/10/12 bit color depth
output
• Supports output pixel format
RGB4:4:4/YCbCr4:4:4/YCbCr4:2:2
• Supports HDCP 2.2&HDCP1.4
• Supports HDR
Note: When connecting a DP1.4 Alt mode
supported host, the max resolution of
HDMI is 4k/60Hz; When connecting a
DP1.2 Alt mode supported host, the max
resolution of HDMI is 4k/30Hz due to
bandwidth limitation
Speci cation
Input / Output Connector
Input
Output
Warranty
Limited Warranty
Environmental
Operating Temperature Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Electronic Parameter
Input Voltage
Power Consumption
Power Supply
USB-C PD Charging Port
Regulatory Approvals
Certi cations
Accessory Adapter
User Manual
USB-A 3.0 X1
• Support max 7.5W(5V@1.5A)
downstream charging
• Max 5Gbps bandwidth
Type-C Female X1
(for PD Charging & Data)
When connecting a PD Adapter:
• Support PD Charging 100W (20V/5A)
• Support Fast Role Swap of PD 3.0, the
connected device will not get
disconnected while plugging in and out
PD Adapter
• 7.5W is dedicated to the functioning of
this product, the rest power (max 92.5W)
will be passed to charge for the host
When connecting a Type-C device:
• Max 5Gbps data transfer
• Max 7.5w(5V/1.5A) downstream charging
• Share max 7.5W downstream charging
with USB-A port
USB-C Male x1
HDMI Female x1
USB-A Female x1
Type-C Female x1 (PD & Data)
2 Years
0°C to 45°C (32°F to 113°F)
10% to 90% RH (no condensation)
-10°C to 70°C (14°F to 158°F)
10% to 90 % RH (no condensation)
MAX 50V
2W
100W(20V/5A)
FCC, CE
