Packaging and Hardware
Box 1
Box 2
(H1) x 14 (H1) x 14
wedgefix wedgefix
housing housing
+4 spare +4 spare
(H8) x 1 (H8) x 1
left/right left/right
Wall connecting bracket Wall connecting bracket
Box 3
C
x3
E
x1
(H2) x 16 (H2) x 16 (H3) x 30 (H3) x 30
wedgefix wedgefix
Knock-in housing Knock-in housing
dowel dowel
+4 spare +4 spare
(H9) x 1 (H9) x 1
left/right left/right
Side connecting bracket Side connecting bracket
A
x2
(H4) x 2 (H4) x 2 (H5) x 12
3/8" flat-head
leveling wedge leveling wedge
screw
(H10) x 1 (H10) x 1
Bracket Cover Bracket Cover
B
x1
D
F
(H14) x 2
Closet rod
(H7) x 4
spacer
x 4
(H12)
wall anchor
(H13) x 4
2"3/8 screw TC
(H11) x 4
Rod bracket
