- Page 1 CONFIDENCE IS EVERYTHING.™ World Leader of In-Rack, Audio, Video, Data Monitoring, and Closed Captioning Solutions RMT-150 Series • RMT-150-A • RMT-150-SD 15” Audio/Video LCD Monitor User Guide Part Number 821701, Revision B the video division of...
- Page 2 In no event will Wohler Technologies, Inc. be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect in the hardware, software, or its documentation, even if advised of the possibility of such damages.
-
Page 3: Table Of Contents
RMT-150 Series User Guide Introduction Overview By employing a 1024 x 768 TFT/LCD screen, a perfect medium is reached in the scaling and interpolation process, providing superb imaging regardless of video format. This monitor comes with a plethora of in-monitor display features including level metering and built-in speaker monitoring of its dual stereo analog inputs. -
Page 4: Safety Instructions
R M T -1 5 0 S e r i e s U s e r G u i d e S a f e t y I n s tr u c ti o n s Safety Instructions Read, keep, and follow all of these instructions; heed all warnings. Do not use this equipment near water. -
Page 5: Unpacking And Installation
RMT-150 Series User Guide U n p a c k i n g a n d I n s t a l l a t i o n Unpacking and Installation Carton Contents Unpack the RMT-150 Series monitor and inspect for any apparent physical damage that may have occurred in transit. -
Page 6: Product Distinctions
R M T -1 5 0 S e r i e s U s e r G u i d e P ro d u ct D i s t i n c ti o n s Product Distinctions The RMT-150-SD has all of the inputs the RMT-150-A has plus two SD-SDI inputs. - Page 7 RMT-150 Series User Guide S p e ci f i c a t i o n s Table 1–1 Specifications for the RMT-150 Series Specification RMT-150-A RMT-150-SD • 1 CVBS • 2 SD-SDI • 1 CVBS Y/C-YpbPr • 1 CVBS Inputs •...
- Page 8 R M T -1 5 0 S e r i e s U s e r G u i d e S p e c if i c a ti o n s Table 1–3 Signal Formats for the RMT-150-A and RMT-150-SD Input Signal Type...
-
Page 9: Dimensions
RMT-150 Series User Guide D i m e n s io n s Table 1–5 Controls to Signal Relationships Input Terminal Select SDI-1 or Line-1 Line-2 DVI-I Area ---Button Items SDI-2 Ypbpr Control Video Video SDI SD DVI-D Color ... - Page 10 R M T -1 5 0 S e r i e s U s e r G u i d e D i m e n s i o n s Figure 1–2 Rear View Figure 1–3 Side View (with Table Top Stand) 8 2 1 7 0 1 : R M T- 1 5 0 S er ie s U s e r G u i d e ©...
-
Page 11: In Monitor Features
RMT-150 Series User Guide I n M o n i t o r F e a t u re s Figure 1–4 Top View In Monitor Features Figure 1–5 Monitor Display and Audio Features Tally Light Signal Format Safe Area Audio Meters Speakers 8 2 1 7 0 1 :... -
Page 12: Front Control Panel
R M T -1 5 0 S e r i e s U s e r G u i d e F r o n t C o n t r o l P a n e l Note: While the image in Figure 1–5 shows a waveform, this monitor does not currently come with this feature. - Page 13 RMT-150 Series User Guide F r o n t C o n t r o l P a n e l • Green: The monitor is on. • Red: The monitor is idle (standby). • LINE 1 — VIDEO Input Select Button/Lamp: The signal of the LINE 1 input displays on the screen.
- Page 14 R M T -1 5 0 S e r i e s U s e r G u i d e F r o n t C o n t r o l P a n e l Option Buttons Pressing any of the buttons in this section and selecting a non-default value lights the button.
- Page 15 RMT-150 Series User Guide F r o n t C o n t r o l P a n e l automatically disappears in about 15 seconds after the last status operation. • When set to , the state bar displays all the time. •...
- Page 16 R M T -1 5 0 S e r i e s U s e r G u i d e F r o n t C o n t r o l P a n e l • METER2L •...
- Page 17 RMT-150 Series User Guide F r o n t C o n t r o l P a n e l Table 1–6 OSD (On Screen Display Menu) Menu Available Options Input audio mode. When the input signal is DVI-D , no audio mode can be selected.
- Page 18 R M T -1 5 0 S e r i e s U s e r G u i d e F r o n t C o n t r o l P a n e l Rotary Knobs Pressing any of the knobs repeatedly steps through the configurable options and then finally disappears from the display.
-
Page 19: Rear Panel Connectors And Controls
RMT-150 Series User Guide R e a r Pa n e l C o n n e c t o r s a n d C o n tr o l s Rear Panel Connectors and Controls Figure 1–7 Rear Panel (Left Side) SDI In 1 SDI In 2 SDI Out... - Page 20 R M T -1 5 0 S e r i e s U s e r G u i d e R e a r P a n e l C o n n e ct o r s a n d C o n t r o l s •...
- Page 21 RMT-150 Series User Guide R e a r Pa n e l C o n n e c t o r s a n d C o n tr o l s Figure 1–9 Tally GPI RJ-45 Pin Numbering Schema Table 1–7 Tally Color Definitions Status...
-
Page 22: Technical Functional Overview
R M T -1 5 0 S e r i e s U s e r G u i d e T e c h n i c a l F u n c t i o n a l O v e r v i e w Table 1–9 RS485 Pin Out RS485 In terminal... - Page 23 RMT-150 Series User Guide T e c h n i c al F u n c ti o n al O v e r v ie w Figure 1–11 RMT-150-A Block Diagram Audio Audio Out Source Select Audio In 1 Audio In 2 RS-485 (future)
- Page 24 RMT-150 Series User Guide T e c h n i c a l F u n c t i o n a l O v e r v i e w Figure 1–12 RMT-150-SD Block Diagram RS-485 (future) RS-485 LED Tally Interface Audio Source...
