EPH Controls RFRB V2 Installation And Operation Manual page 8

Mounting & Installation
1) The mounting height should be 1.5 metres above the oor
level.
2) The thermostat should be located in the room where the
heating is to be controlled.
The place of installation should be chosen so that the sensor
can measure the room temperature as accurately as possible.
Choose the mounting location to prevent direct exposure
to sunlight or other heating / cooling sources.
3) Press and hold the release button on the bottom of the
thermostat to detach the front housing from the base plate.
4) Insert the 2 x AAA batteries provided and the thermostat
will turn on.
5) For wall mounted installation, x the base plate directly to the
wall with the screws provided. Attach the front housing to the
base plate.
6) For table mounted installation, attach the front housing to
the base plate. Place the thermostat onto the stand provided.
6
Continued
RFRB
V2
