P0 7 – AFS Air / Floor Sensor
01 Internal air sensor
This function allows the user to select between 3 di erent
temperature sensor options.
01 Internal air sensor – This option allows the user to record the
room temperature using the internal sensor. This is the default
option.
02 External air sensor – This option allows the user to record the
temperature of an adjacent room (NTC10K temperature sensor
required)
03 Internal a sensor with an External high limit sensor.
This option allows the user to record the room temperature with
the internal sensor while having the external sensor record the oor
temperature to prevent overheating. (NTC10K temperature sensor
required)
Temperature Sensor
Note: The temperture sensor should
be ran through the breakout on the
rear housing.
