AstralPool
CTX, XP, XF and E Series Pumps | Installation and Operation Manual
®
2.5
Dimensions
5x Pipe Diameter
216mm
Figure 1. CTX-Series Pump
5x Pipe Diameter
216mm
Figure 2. XP-Series Pump
341mm
247mm
609mm
273mm
295mm
359mm
249mm
704mm
336mm
160
295
135
Figure 3. XF-Series Pump
5x Pipe Diameter
291mm
Figure 4. E-Series Pump
423
77
346
323mm
245mm
273mm
219mm
250
268
295mm
7
