Section 2. General Information

This manual provides installation and operation instructions
for the AstralPool CTX, XP, XF and E Series pumps.
Read these installation and operation instructions
completely before proceeding with the installation.
2.1

Pump Features

• Reinforced precision-moulded impeller, provides extra
high-head performance
• Single piece moulded body for added strength and
longer life
• Rapid-priming diffuser quickly corrects loss of water flow
• Continuous-duty rated motor at 2850 rpm
• Large capacity basket with easily removed lid
• Quick and easy disassembly for servicing
• Operating temperatures: 2 to 50°C air, 2 to 35°C water
• Protection index: IPX4
The CTX-Series pumps provide high head pressure to move
water through the pool filter, salt chlorinator, in-floor cleaning
systems, or multi-jet spas. Energy efficient. Infrequent
cleaning needed thanks to a large hair and lint pot.
The XP-Series pump offers high head pressure, energy-
efficient operation. Runs cool and quiet. The large hair and
lint pot needs infrequent cleaning.
The XF-Series pump is designed for flooded suction
without the need for a hair and lint pot. Smaller-horsepower
XF models are perfect for low-flow applications such as
booster pump, solar pump, above-ground pool pump, or
heating system circulating pump. The larger-horsepower XF
models are suitable for the high-flow needs of swim jets or
multi-jet spas.
The E-Series pump provides low cost performance and
reliability for all pools and spas up to 100,000 litres.
2.2

Specifications

Model Phase Voltage
CTX 280 1 240V
CTX 360 1 240V
CTX 400 1 240V
CTX 500 1 240V
XP 1.5 1 240V
1 240V
XP 2.0
3 415V
1 240V
XP 3.0
3 415V
XF 140 1 240V
XF 250 1 240V
XF 520 1 240V
E 140 1 240V
E 170 1 240V
E 230 1 240V
Table 1. Electrical and Flow Specifications
6
Max Flow
Watts Amps Suction
(8 ft/sec)
1260 5.3 280 LPM
1360 7.1 360 LPM
1500 7.9 400 LPM
1900 8.3 500 LPM
1640 6.6 440 LPM
2020 8.5 540 LPM
2440 3.4 540 LPM
2300 12.5 635 LPM
2944 4.1 640 LPM
500 2.9 140 LPM
1050 4.3 250 LPM
1980 8.3 520 LPM
500 2.9 140 LPM
710 3.1 170 LPM
1010 3.5 230 LPM
