SELF-PRIMING COMMERCIAL
CENTRIFUGAL PUMPS WITH TRAP
FOR SWIMMING POOL USE
Astral Products Inc.
8525 Mallory Rd., Jacksonville, FL 32220
Printed in U.S.A.
O
W
N
E
R '
INSTALLATION, OPERATION & PARTS
H.P.
Phase
7.5
1
7.5
3
10
1
10
3
15
3
20
3
S
M
A
N
U
230/460V/60 Hz.
A142C
A142C3
A143C
A143C3
A144C
A145C3
A
L
This manual should be furnished to
the end user of this pump; its use will
reduce service calls and chance of
injury and will lengthen pump life.
S420 (Rev. 6/7/02)
Advertisement
Table of Contents
Related Manuals for Astralpool A142C
Summary of Contents for Astralpool A142C
- Page 1 SELF-PRIMING COMMERCIAL CENTRIFUGAL PUMPS WITH TRAP FOR SWIMMING POOL USE R ’ INSTALLATION, OPERATION & PARTS H.P. Phase 230/460V/60 Hz. A142C A142C3 A143C A143C3 A144C A145C3 This manual should be furnished to the end user of this pump; its use will reduce service calls and chance of injury and will lengthen pump life.
-
Page 2: Table Of Contents
SELF-PRIMING COMMERCIAL CENTRIFUGAL PUMP and TRAP To avoid unneeded service calls, prevent possible injuries, and get the most out of your pump, READ THIS MANUAL CAREFULLY! The Astral Self-priming Commercial Centrifugal pump: • Is designed for use with commercial swimming pools or as a centrifugal pump. -
Page 3: Safety Instructions
READ AND FOLLOW SAFETY IMPORTANT INSTRUCTIONS! SAFETY INSTRUCTIONS This is the safety alert symbol. When you see this symbol on your system or in this manual, look for one of the following signal words and be alert to the potential for personal injury. Always follow basic safety pre- cautions with this equipment, in- cluding the following. - Page 4 Table I – OUTLINE DIMENSIONS – In Inches (Includes Package A184S) Model No. Volt/Hz/Ph A142C 230/60/1 10.62 7.00 39.44 5.25 4.25 5.50 1.00 30.00 8.50 A142C3 230-460/60/3 9.00 6.75 40.31 4.50 3.75 5.50 1.75 29.13 7.50 A143C 230/60/1 10.35 8.26 42.69...
- Page 5 Installation Diagram Flooded Suction Installation Support pipe Filter From pool suction Isolation valves full plumbing. open when pumping. Discharge pipe diameter Minimum suction Straight run, as short as possible 4" or larger. The distance pipe diameter 6". but at least 6 times pipe diameter to the first elbow must be (to stabilize flow) from nearest at least 5 times the pipe...
-
Page 6: Uncrating And Inspection
UNCRATING AND INSPECTION Handle with care. Check items received against packing list to be sure that all equipment has been received. Inspect for shipping damage. If found, file claim with carrier immediately. Cleanup Clean up all trash and other materials which will interfere with installation from foundation and surrounding area. - Page 7 Use larger pipe as required to keep water velocity below 7 feet per second or local construction code limits, whichever is lower. Suction pipe must rise continuously from source to pump. To avoid airlock- ing, do not allow high spots in pipe. When using reducer to connect to pump flange, use an eccentric reducer with the straight side on top.
- Page 8 Suction Outlet Covers All suction outlet covers must be maintained. They must be replaced if cracked, broken, or missing. See Page 6 for outlet cover certification requirements. All suction outlets must have correctly installed, screw-fastened covers in place. Outlets Per Pump Provide at least two hydraulically balanced main drains, with covers (see Page 6), for each swimming pool pump suction line.
-
Page 9: Electrical
ELECTRICAL Ground motor before connecting to electrical power supply. Failure to ground motor can cause severe or fatal electrical shock hazard. Do not ground to a gas supply line. To avoid dangerous or fatal electrical shock, turn OFF power to motor before working on electrical connections. -
Page 10: Operation
Start pump; it should prime now. Priming time will depend on vertical length of suction lift (10'/3m maximum) and horizontal length of suction pipe. Priming for the A142C through A145C3 series pumps has been tested to 10 ft. elevation above water level. Priming time using 6” diameter suction pipe is approximately 9 minutes, at less than 1,000 ft. -
Page 11: Service
If pump does not prime, make sure that all valves are open, suction pipe end is under water and that there are no leaks in suction pipe. Fill strainer to bot- tom of inlet port. Make sure that there are no vacuum leaks around drain plugs, gaskets, and O-Rings. - Page 12 20. Install new volute gasket and slide motor/impeller/bracket assembly into place; bolt up to volute. Tighten cap screws and nuts to 450 inch-lbs. (5.2 kg-m) torque. 21. Pumps below water level: Close drains; open system valves to fill pump. Pumps above water level: Fill strainer and prime pump. Open system valve if they were closed at disassembly.
-
Page 13: Troubleshooting Guide
TROUBLE SHOOTING PROBABLE CAUSE GROUP 1 GROUP 2 GROUP 3 SYMPTOM ELECTRICAL MECHANICAL SYSTEM PUMP RUNS, BUT NO • • • • • WATER DELIVERED • • • • • • • • NOT ENOUGH WATER DELIVERED • • • • • •... -
Page 14: Repair Parts List
Repair Parts List Discharge pipe Models is user supplied A142C, A142C3 A143C, A143C3 3A, 3B A144C3, A145C3 22A 22 21 20 Model Number 7.5HP 10HP 15HP 20HP Part A142C A143C Description A142C3 A143C3 A144C3 A145C3 Motor, 230 Volt 1 Phase... - Page 15 PKG A184S Strainer Repair Parts List Part Standard Flange Description Pkg A184S Strainer Body 16401-0010 O-Ring 35505-0421 Strainer Cover 16401-0211 Pipe Plug, 1/4” Square Head U78-57D Strainer Basket 16401-0102 Pipe Plug, 1/2” Square Head Brass U78-59D Wing Nut 35404-0319 Toggle Bolt 30767-0011 Spring Pin 35857-0031...
-
Page 16: Warranty
184, 184C, 184E, 184CE Pressure Drop Curve Max. Flow Rate 850 GPM for PKG A184S Strainer Max. Flow Rate 850 GPM (13.8) (10.3) (6.9) (3.5) (378.5) (757) (1138.5) (1514) (1892.5) (2271) (2649.5) (3028) (3406.5) Flow in GPM (LPM) ASTRAL LIMITED WARRANTY Pumps manufactured for Astral are warranted to be free of defects in material and workmanship for one (1) year from date of installation.
