EX-1580SHMVS
3. Layout, Connections & Jumpers

3.1 Layout

7-24V T-Block for optional
external Power Supply
Power LED
1x USB 3.2 Gen 1
Upstream B-Port

3.2 Connections

+7V - 24V T-Block:
GND (Ground)
+7V - 24V
USB 3.2 Gen 1 A-Port:
GND_DRAIN
StdB_SSTX +
StdB_SSTX -
VCC D- D+ GND
© Copyright 2024 by EXSYS Vertriebs GmbH. All Rights Reserved
ATTENTION!
Never connect power to GND, it will destroy
your Hardware!
StdB_SSTX
ATTENTION!
StdB_SSTX -
Never plug in with force or in wrong direction.
10x USB 3.2 Gen 1
Downstream A-Port
Reset Button
11
English
Status LED for
each Port
