- Page 1 PERFORMANCE MADE SMARTER Product manual 5715 Programmable LED indicator T E M P E R AT U R E I . S . I N T E R FA C E S CO M M U N I C AT I O N I N T E R FA C E S...
- Page 2 6 Product Pillars to meet your every need Individually outstanding, unrivalled in combination With our innovative, patented technologies, we make signal conditioning smarter and simpler. Our portfolio is composed of six product areas, where we offer a wide range of analog and digital devices covering over a thousand applications in industrial and factory automation.
-
Page 3: Table Of Contents
Programmable LED indicator 5715 Table of contents Warning .................... -
Page 4: Warning
The following operations should only be carried out on a disconnected device and under ESD-safe conditions: Troubleshooting the device. Repair of the device must be done by PR electronics A/S only. Symbol identification Triangle with an exclamation mark: Warning /demand. Potentially lethal situations. Read the manual before installation and commissioning of the device in order to avoid incidents that could lead to personal injury or mechanical damage. -
Page 5: Safety Instructions
Should there be any doubt as to the correct handling of the device, please contact your local distributor or, alternatively, PR electronics A/S www.prelectronics.com Mounting and connection of the device should comply with national legislation for mounting of electric materials, i.e. wire cross section, protective fuse, and location. -
Page 6: Front And Back Layout
Front and back layout Picture 1: Front of 5715. Picture 2: Back of 5715. 5715V104-UK... -
Page 7: Application
To be mounted in panel front. The included rubber packing must be mounted between the panel cutout hole and the display front to obtain a protection degree of IP65 (type 4X). For extra protection in extreme environments, PR 5715 can be delivered with a specially designed splash-proof cover as accessory. -
Page 8: Applications
Applications Input signals: Current Potentio- RTD & Lin R - Voltage connection, wires meter Output signals: 4 change over relays Analog, 0/4...20 mA Supply: 21.6...253 VAC 19.2...300 VDC 5715V104-UK... -
Page 9: Order
Order Type Version 5715 4 relays Analog output and 4 relays NB! Please order the splash-proof cover seperately. Order No. 8335. Electrical specifications Environmental conditions: Ambient operating temperature range ..... . . -20°C to +60°C Calibration temperature. - Page 10 Basic values Input type Basic accuracy Temperature coefficient ≤ ±4 μA ≤ ±0.4 μA / °C Volt ≤ ±20 μV ≤ ±2 μV / °C Pt100 ≤ ±0.2°C ≤ ±0.01°C / °C Linear resistance ≤ ±0.1°Ω ≤ ±0.01 Ω / °C Potentiometer ≤...
- Page 11 RTD, linear resistance and potentiometer input Input type Min. value Max. value Standard Pt10...Pt1000 -200°C +850°C IEC 60751 Ni50...Ni1000 -60°C +250°C DIN 43760 Cu10...Cu100 -200°C +260°C α = 0.00427 Lin. R 0 Ω 10000 Ω Potentiometer 10 Ω 100 kΩ Input for RTD types: Pt10, Pt20, Pt50, Pt100, Pt200, PT250, Pt300, Pt400, Pt500, Pt1000 Ni50, Ni100, Ni120, Ni1000, Cu10, Cu20, Cu50, Cu100...
-
Page 12: Sensor Error Detection / Sensor Error Detection Outside Range
UL us, UL 508........E248256 Sensor error detection / sensor error detection outside range Sensor error check in 5715 variants Variant... - Page 13 Outside range readout (IN.LO, IN.HI): If the valid range of the A/D converter or the polynomial is exceeded Input Range Readout Limit IN.LO < -25 mV 0...1 V / 0.2...1 V IN.HI > 1.2 V VOLT IN.LO < -25 mV 0...10 V / 2...10 V IN.HI >...
-
Page 14: Connections
Connections Supply: 31 32 Inputs: RTD & Lin R, 2-wire RTD & Lin R, 3-wire RTD & Lin R, 4-wire 41 42 43 44 45 46 41 42 43 44 45 46 41 42 43 44 45 46 2-wire transmitter Current 41 42 43 44 45 46 41 42 43 44 45 46... -
Page 15: Block Diagram
Block diagram 5715V104-UK... - Page 16 Power up Fast setpoint adjustment and relay test F. S ET SETP 1 Increase setpoint 2 Decrease setpoint REL1 -1999 3 Save and exit the menu 9999 REL2 1 and 2 simultaneously = change relay state 50. 0 REL3 /OFF REL4 PASS DEC.
-
Page 17: Routing Diagram
Routing diagram If no keys are activated for 2 minutes the display returns to default state 1.0 without saving configuration changes. 1 Increase value / choose next parameter. 2 Decrease value / choose previous parameter. 3 Accept the chosen parameter and go to the next menu. Hold 3 Back to previous menu / return to menu 1.0 without saving. -
Page 18: Scrolling Help Text
Scrolling help text Display in default state xxxx, hardware error: DI.LO SE.BR xxxx --> DISPLAY READOUT LOW --> SENSOR WIRE BREAKAGE SE.SH --> SENSOR SHORT CIRCUIT DI.HI IN.HI --> INPUT OVERRANGE xxxx --> DISPLAY READOUT HIGH IN.LO --> INPUT UNDERRANGE 9.9.9.9 -->... - Page 19 UNIT O.LO °C --> DISPLAY AND RELAY SETUP IN CELSIUS xxxx --> DISPLAY VALUE FOR OUTPUT LOW °F --> DISPLAY AND RELAY SETUP IN FAHRENHEIT O.HI REL1 xxxx --> DISPLAY VALUE FOR OUTPUT HIGH --> ENTER RELAY 1 SETUP SKIP -->...
-
Page 20: Configuration / Operating The Function Keys
Configuration / operating the function keys Documentation for routing diagram. In general When configuring the display you are guided through all parameters, you can choose the settings which fit the application. For each menu there is a scrolling help text which is automatically shown in the display, this starts after 5 seconds if no key has been activated. -
Page 21: Programming Via Pc
The customer-defined input type is saved in the 5715 in the input menu C. L IN. If the display is later configured by way of the front keys for e.g. temperature input, the input type C. L IN containing all the original parameters can be subsequently selected. -
Page 22: Installation Instructions
Installation instructions UL installation requirements For use on a flat surface of a type 1 enclosure Use 60/75°C copper conducters only Enclosure rating (face only) acc. to UL50E..... Type 4X Max. -
Page 23: Document History
Document history The following list provides notes concerning revisions of this document. Rev. ID Date Notes 2208 Relay data updated, graph with resistive loads inserted. UKCA approval added. 2230 DNV marine approval replaced by EU-RO marine approval. 5715V104-UK... - Page 24 We are near you, all over the world Our trusted red boxes are supported wherever you are All our devices are backed by expert service and a 5-year business with a global reach. This means that we are warranty. With each product you purchase, you receive always nearby and know your local markets well.
- Page 25 Benefit today from PERFORMANCE MADE SMARTER PR electronics is the leading technology company specialized in making industrial process control safer, more reliable and more efficient. Since 1974, we have been dedicated to perfecting our core competence of innovating high precision technology with low power consumption.
