- Page 1 Home Appliances K-60D19BM1-EN Cooking User Manual...
- Page 2 Thank you for choosing this product. This User Manual contains important safety information and instructions on the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference. Icon Type Meaning...
-
Page 3: Table Of Contents
CONTENTS 1.SAFETY INSTRUCTIONS ....................4 1.1 General Safety Warnings ....................4 1.2 Installation Warnings ......................6 1.3 During Use ........................7 1.4 During Cleaning and Maintenance .................8 2.INSTALLATION AND PREPARATION FOR USE ..............9 2.1 Instructions for the Installer ....................9 2.2 Installation of the Oven ....................9 2.3 Electrical Connection and Safety..................10 3.PRODUCT FEATURES ....................12 4.USE OF PRODUCT ......................13... -
Page 4: Safety Instructions
1. SAFETY INSTRUCTIONS • Carefully read all instructions before using your appliance and keep them in a convenient place for reference when necessary. • This manual has been prepared for more than one model therefore your appliance may not have some of the features described within. - Page 5 the oven. • Handles may get hot after a short period during use. • Do not use harsh abrasive cleaners or scourers to clean the oven door glass and other surface. They can scratch the surfaces which may result in shattering of the door glass or damage to surfaces.
-
Page 6: Installation Warnings
heating a room. • Do not use the oven door handles to lift or move the appliance. • All possible measures have been taken to ensure your safety. Since the glass may break, care should be taken while cleaning to avoid scratching. Avoid hitting or knocking the glass with accessories. -
Page 7: During Use
• Any materials (i.e. cabinets) around the appliance must be able to withstand a minimum temperature of 100°C. • The appliance must not be installed behind a decorative door, in order to avoid overheating. 1.3 DurinG uSe • When you first use your oven you may notice a slight smell. -
Page 8: During Cleaning And Maintenance
• Make sure the appliance control knobs are always in the “0” (stop) position when it is not in use. • The trays incline when pulled out. Take care not to spill or drop hot food while removing it from the ovens. -
Page 9: Installation And Preparation For Use
2. INSTALLATION AND do not use it and contact an authorised service person or qualified technician PREPARATION FOR USE immediately. WARNING : This appliance must be • Make sure that there are no flammable installed by an authorised service or combustible materials in the close person or qualified technician, according to vicinity, such as curtains, oil, cloth etc. -
Page 10: Electrical Connection And Safety
Installation in a wall unit After making the electrical connections, appliance’s power rating (also indicated insert the oven into the cabinet by pushing on the identification plate). it forward. Open the oven door and insert • During installation, please ensure 2 screws in the holes located on the oven that isolated cables are used. - Page 11 • Fix the supply cable in the cable clamp and then close the cover. • The terminal box connection is placed on the terminal box. Blue Brown Yellow+Green EN - 11...
-
Page 12: Product Features
3. PRODUCT FEATURES Important: Specifications for the product vary and the appearance of your appliance may differ from that shown in the figures below. List of Components 1. Control Panel 2. Oven Door Handle 3. Oven Door Control Panel Please use product control panel 4. -
Page 13: Use Of Product
4. USE OF PRODUCT heating elements will start operating. The static cooking function emits heat, ensuring even cooking of food. This is ideal for 4.1 oven ControlS making pastries, cakes, baked pasta, Oven function control knob lasagne and pizza. Preheating the oven for 10 minutes is recommended and it is best Turn the knob to the corresponding symbol to use only one shelf at a time in this... -
Page 14: Cooking Table
elements will start operating. This function Puff Pastry 2-3-4 170-190 25-35 is used for faster grilling and for grilling food with a larger surface area, such as meat. Cake 2-3-4 150-170 25-35 Use the upper shelves of the oven. Lightly Cookie 2-3-4 150-170... - Page 15 Time adjustment 2. Select the desired time period using the The time must be set before you start using “+” and “-” keys while the oven. Following the power connection, “ ” is flashing. the symbol “A” and “00:00” or “12:00” will flash on the display.
- Page 16 sound. The symbols “A” will flash. Turn both 1. Select the desired cooking function and control knobs to the “0” position and press the temperature using the control knobs. any key on the timer to stop the warning 2. Press “MODE” until sound.
-
Page 17: Accessories
Sound Adjustment ****Accessories may vary depending on the model purchased. To adjust the volume of the audible warning The Deep Tray sound, while the current time of day is displayed, press “+” and “-” keys and the The deep tray is best used for cooking dot in the middle of the screen will start stews. -
Page 18: Cleaning And Maintenance
The Wire Rack with Easyfix Half Telescopic Rail The half telescopic rail extends half-way out, to allow easy access to your food. WARNING Place the grid to any corresponding rack in the oven cavity correctly and push it to the end. Telescopic rails Clean the accessories thoroughly with warm water, detergent and a soft clean... - Page 19 • Check whether the cleaning materials cloth soaked in only water. Then, dry are appropriate and recommended by them thoroughly with a dry cloth. the manufacturer before use on your Do not clean the stainless steel parts appliance. while they are still hot from cooking. •...
-
Page 20: Maintenance
3. Place the glass under the location Removal of the Wire Shelf bracket (x) in the direction of C. To remove the wire rack, pull the wire rack as shown in the figure. After releasing it from the clips (a), lift it up. If the oven door is a triple glass oven door, the third glass layer can be removed the same way as the second... -
Page 21: Troubleshooting&Transport
illumination. 6. TROUBLESHOOTING&TRANSPORT 6.1 troubleShootinG If you still have a problem with your appliance after checking these basic troubleshooting steps, please contact an authorised service person or qualified technician. Problem Possible Cause Solution Check whether there is power supplied. Oven does not switch Power is switched off. -
Page 22: Technical Specifications
7. TECHNICAL SPECIFICATIONS 7.1 enerGy fiChe Brand Model K-60D19BM1-EN Type of Oven ELECTRIC Mass 32,0 Energy Efficiency Index - conventional 103,6 Energy Efficiency Index - fan forced 94,1 Energy Class Energy consumption (electricity) - conventional kWh/cycle 0,87 Energy consumption (electricity) - fan forced... - Page 23 Service & Support Visit Our Website sharphomeappliances.com...
