73 ¾"
Thank you for choosing Grain Wood Furniture, it is an honor to be in your home!
If you have any questions, feedback, or need replacement parts please contact us at:
grainwoodfurniture.com/help or
Greenport Collection
3-Door Wardrobe
REV - 11/2023
Assembly Instructions
59 ½"
support@grainwoodfurniture.com
21 ½"
Made in Brazil
2-person assembly
Model #
Finish
GPS0903
Brushed White
GPS0905
Brushed Walnut
GPS0916 Brushed Driftwood
Brushed Grey
GPS0940
PH #2
page 1/26
Advertisement
Related Manuals for GrainWood Greenport GPS0903
Summary of Contents for GrainWood Greenport GPS0903
- Page 1 Assembly Instructions 21 ½” 59 ½" 2-person assembly PH #2 73 ¾” Model # Finish GPS0903 Brushed White GPS0905 Brushed Walnut GPS0916 Brushed Driftwood Brushed Grey GPS0940 Thank you for choosing Grain Wood Furniture, it is an honor to be in your home! If you have any questions, feedback, or need replacement parts please contact us at: grainwoodfurniture.com/help or support@grainwoodfurniture.com...
- Page 2 PLEASE READ BELOW BEFORE BEGINNING ASSEMBLY Enlist help from a friend or family member as most items require two Ÿ people for proper assembly. Choose a spacious, open area near where the piece will be located once Ÿ assembled. It is easier to move parts than to relocate the furniture after it is fully assembled.
-
Page 3: Hardware List
HARDWARE LIST 50 + 3 ANTI-TIPPING RESTRAINT KIT 4,0x30 8 + 1 2 + 1 3,5x14 3,0x20 3,0x20 41 + 3 3,5x16 9 + 1 4,0x40 250 - 9 ³⁄ " 4 + 1 4,0x25 7 + 1 M4x25 20 + 1 6,0x10 59 + 3 8,0x25... - Page 4 BOX A - 1 of 2 BOX B - 2 of 2 Part # Description Qty. Part # Description Qty. Rear panel Right side Drawer front Left side Drawer right side Upper crosspiece Drawer left side Lower crosspiece Drawer bottom Back panel Drawer back Drawer bottom support...
- Page 5 Tip: Use a hammer in case dowels are hard to install by hand. 59 D21 8,0x25 page 5/26...
- Page 6 Attach hinge ( F10 ) to hinge plate if it comes separated. Push hinge against plate until it clicks. click! A9 A9 A9 A9 A9 A9 3,5x16 page 6/26...
- Page 7 Glide wheels should be positioned towards the front and bottom of the side panel. 6,0x10 LEFT Side page 7/26...
- Page 8 Attach hinge ( F10 ) to hinge plate if it comes separated. Push hinge against plate until it clicks. click! A9 A9 A9 A9 A9 A9 3,5x16 page 8/26...
- Page 9 Glide wheels should be positioned towards the front and bottom of the division panel. 6,0x10 RIGHT Side page 9/26...
- Page 10 Attach hinge ( F10 ) to hinge plate if it comes separated. Push hinge against plate until it clicks. click! A9 A9 3,5x16 page 10/26...
- Page 11 Attention: There are no predrilled holes for the A4 screws on parts 03 and 22. 3,5x14 page 11/26...
- Page 12 Attention: There are no predrilled holes for the A1 and A18 screws on part 03. ü û 4,0x30 4,0x25 Attention: There are no predrilled holes for the A1 screws on part 03. 4,0x30 page 12/26...
- Page 13 Attention: There are no predrilled holes for the A1 screws on part 22. 4,0x30 Attention: There are no predrilled holes for the A1 screws on part 22. 4,0x30 page 13/26...
- Page 14 Attention: There are no predrilled holes for the A1 and A18 screws on part 02. 4,0x30 4,0x25 Attention: There are no predrilled holes for the A16 screws on parts 02, 03 and 22. Attention: There are no predrilled holes for the A18 screws on parts 04 and 05.
- Page 15 Make sure back panels are perfectly aligned with side panels and top and there are no gaps. Gap present û No gap ü ü 10x10 Gap present û No gap ü 10x10 page 15/26...
- Page 16 10x10 10x10 page 16/26...
- Page 17 G1 G1 10x10 3,5x14 page 17/26...
- Page 18 Choose the desired shelf height and insert metal supports. Attention: There are no predrilled holes for the A9 screws on part 21. 3,5x16 page 18/26...
- Page 19 Attention: There are no predrilled holes for the A9 screws on part 19. 3,5x16 3,5x16 page 19/26...
- Page 20 Attention: There are no predrilled holes for the A9 screws on part 18. If the doors are not properly aligned, we will adjust them after the product is fully assembled and placed in its final location, (pages 25 and 26). 3,5x16 page 20/26...
- Page 21 Attention: There are no predrilled holes for the A1 screws on part 08. 4,0x30 page 21/26...
- Page 22 Flip the assembled drawer upside down to install glides. Drawer RIGHT Drawer LEFT 8 E21 6,0x10 page 22/26...
- Page 23 M4x25 Place the labeled drawer in the top position page 23/26...
- Page 24 ANTI-TIPPING RESTRAINT KIT Install against the furniture on the wall Anchors and screws are not included, choose best type based on your wall Install both parts F8 3,0x20 Tighten them together using the safety strap page 24/26...
- Page 25 Removing the Gap Between the Door and the Frame Loosen rear screw. û Adjust door forwards or backwards. ü Re-tighten the rear screw. Adjusting the Space Betweeen the Door and the Drawer Left Right Loosen top and bottom Door Door screw on all hinges.
- Page 26 Aligning Crooked Doors Pivot outwards. Tighten rear screw if needed. Pivot inwards. Aligning Crooked Doors Pivot inwards. Pivot outwards. Tighten rear screw if needed. page 26/26...
