73 ¾"
Thank you for choosing Grain Wood Furniture, it is an honor to be in your home!
If you have any questions, feedback, or need replacement parts please contact us at:
grainwoodfurniture.com/help or
Greenport Collection
3-Door Wardrobe
REV - 07/2021
Assembly Instructions
59 ½"
support@grainwoodfurniture.com
21 ½"
Made in Brazil
2-person assembly
Model #
Finish
GP0903
Brushed White
Brushed Driftwood
GP0916
Brushed Grey
GP0940
PH #2
page 1/19
