Thank you for purchasing our furniture, it's an honor to be
in your home!
Every effort has been made to ensure your Wood Furniture is
of the finest quality. If you have any questions or need
any replacement parts, please do not hesitate to contact
us at
www.grainwoodfurniture.com
REV - 09/2020
Assembly Instructions
Greenport Collection
5 Drawer Chest
PH#2
MADE IN BRAZIL
www.grainwoodfurniture.com
Model #
GP0703
Brushed White
GP0740
Brushed Grey
Finish
page 1/12
Advertisement
Related Manuals for GrainWood Greenport GP0703
Summary of Contents for GrainWood Greenport GP0703
- Page 1 Assembly Instructions Greenport Collection 5 Drawer Chest Thank you for purchasing our furniture, it’s an honor to be in your home! Every effort has been made to ensure your Wood Furniture is of the finest quality. If you have any questions or need any replacement parts, please do not hesitate to contact us at www.grainwoodfurniture.com...
- Page 2 PLEASE READ BELOW BEFORE BEGINNING YOUR ASSEMBLY Here are some tips on assembling yourflat-pack furniture in order to minimize your assembly time and frustrations: -Do Not throw away packaging material until assembly is complete. -Assemble the item on a soft surface, such as cardboard or old blanket, to protect finish from possible dents of scratches.
-
Page 3: Hardware List
HARDWARE LIST 61 + 2 FURNITURE ANTI-TIPPING RESTRAINT KIT 4,0x30 02 + 1 16 + 1 3,0x20 3,5x14 10 + 1 M4x25 40 + 2 6,0x10 62 + 2 8,0x25 Chest RIGHT 330mm - 13" Drawer RIGHT 330mm - 13" Chest LEFT 330mm - 13"... -
Page 4: Parts List
Parts list Box 1 Part # Description Right side Left side Upper crosspiece Lower crosspiece Back panel Drawer front Drawer right side Drawer Left side Drawer bottom Drawer back Drawer bottom support Profile “H” Rear panel Stabilizing panel Hardware page 4/12... - Page 5 Pro Tip : Use a hammer in case dowels are hard to install by hand. 8,0x25 C2 C2 C2 C2 Chest RIGHT 330mm - 13" Chest LEFT 6,0x10 330mm - 13" page 5/12...
- Page 6 4,0x30 4,0x30 page 6/12...
- Page 7 10x10 page 7/12...
- Page 8 3,5x14 3,5x14 page 8/12...
- Page 9 1" 4,0x30 page 9/12...
- Page 10 FLIP THE ASSEMBLED DRAWER UPSIDE DOWN TO INSTALL GLIDES 6,0x10 Drawer RIGHT 330mm - 13" Drawer LEFT 330mm - 13" M4 x 25 page 10/12...
- Page 11 Place the labeled drawer on the top position page 11/12...
- Page 12 FURNITURE ANTI-TIPPING RESTRAINT KIT Install against the furniture install on the wall Anchors and screws are not included, choose best type based on your wall Install both parts F8 3,0x20 Tighten them together using the safety strap page 12/12...
