MULTISPAN PTC-4202 Manual

PROCESS TEMPERATURE CONTROLLER
PV = Process value
SV = Set Value
TECHNICAL SPECIFICATION
INPUT SPECIFICATION:
Input Types
PT-100
0-10V DC
0-20mA DC
4-20mA DC
J,K,PT-100 = 1°C
Resolution
PT.1 = 0.1°C
0-10V DC,0-20mA DC,4-20mA DC
= 0.1,0.01,0.001,0001
±1% of FSD ± 1°C
Indication
Accuracy
(FSD:- full scale deflection)
DISPLAY AND KEYS:
Display Upper: 4 digit, 7 segment, 0.56"
Lower: 4 digit, 7 segment, 0.33"
Keys SET, INC, DEC, ENT
DIMENSION:
Size
52 (H) x 52 (W) x 111 (D) mm
Panel Cutout 45 (H) x 45 (W) mm
CONTROL METHOD:
Heating 1) PID control with Auto-Tuning
2) ON-OFF control
Cooling
1) BL.TP (Blower Time Proportion)
2) ON-OFF control
Alarm High/ Absolute Low/
Inband/ Absolute Outband
Display Color:
Upper : White Or Red
Lower : Green
Input Range
J 0 to 600°C,
K 0 to 1200°C,
-99 to 400°C,
PT.1 -99.0 to 400.0°C,
-999 to 9999
-999 to 9999
-999 to 9999
OUTPUT SPECIFICATION
PTC-4202
Relay
Relay Type
Rating
Transmitter supply
AUXILIARY SUPPLY
Supply voltage
Power consumption
(VA RATING)
ENVIRONMENT CONDITION
Operating Temp.
Relative Humidity
Protection Level
Outline Dimension (mm)
448.5
450.0
O/P1
O/P2 AT
TUNE
SET
52
1
2
3
4
5
Relay Output
2 nos.
1 C/O (NO-C)
5A, 230V AC/30 V DC
24V DC
100 to 270V AC, 50-60Hz
Approx 7 VA @ 230V AC MAX
0°C to 55°C
UP to 95% RH
(non-condensing)
IP-65 (Front side) As per IS/IEC
60529 : 2001
MECHANICAL INSTALLATION
PTC 4202
PV
SV
ENT
111
3
TERMINAL CONNECTION
L ~
100
!
270V AC
50/60 Hz
7VA
N
Made in India
11
+
O/P
24V
DC
-
C
12
R1
NO
www.multispanindia.com
PTC 4202-RG
Panel Cutout
Dimension (mm)
45
0-10V DC
6
T/C
7
-
0/4-20
mA DC
8
RTD
9
C
R2
NO
10
