TABLE OF CONTENTS TABLE OF CONTENTS
A- Safety instructions ....................................................................................................................................................................... 22
B- Description ..................................................................................................................................................................................... 22
C- Wiring / Installation ..................................................................................................................................................................... 23
D- Use .............................................................................................................................................................................................. 25
E- Configuration .................................................................................................................................................................................. 33
F-Setting .............................................................................................................................................................................................. 35
G-Technical features ......................................................................................................................................................................... 39
H- Technical assistance ................................................................................................................................................................... 40
I-Warranty ............................................................................................................................................................................................ 40
J- Warnings ......................................................................................................................................................................................... 40
K- Declaration of conformity ........................................................................................................................................................... 40

A- SAFETY INSTRUCTIONS

A- SAFETY INSTRUCTIONS
This manual is an integral part of your product. These instructions are provided for your safety. Read this manual
carefully before installing and keep it in a safe place for future reference. Select a suitable location. Make sure you
can easily insert screws and wallplugs into the wall. Do not connect your electrical appliance until your equipment is
totally installed and controlled. The installation, electric connections and settings must be made using best practices
by a specialized and qualified person. The power supply must be installed in a dry place. Check the product is only used
for its intended purpose.
The function of this videophone is to identify a visitor, it must not be used for street surveillance. The use of this
installation must be in compliance with the French law n° 78-17 of January 6, 1978 relating to data processing, files and
freedoms. It is up to the buyer to ask the CNIL about the conditions and administrative authorisations required for use
outside a strictly personal context. SCS Sentinel cannot be held responsible in case of use of this product outside the
laws and regulations in force.
This product works with the iSCS Sentinel app only. The application is available for free on the PlayStore and the
AppStore. Application updates may be necessary, for example to fix bugs, improve features, and benefit from a better
user experience. You can enable or disable automatic updates for the iSCS Sentinel application in the PlayStore or
AppStore settings. The information concerning the reason for the update, its impact on the performance and the
evolution of the functionalities of the product or application as well as the storage space used, are indicated, for each
update, on the PlayStore or the Apple Store.
In accordance with the regulations and the legal guarantee, the application availability and updates are guaranteed for
a period of 2 years. This manual may be amended as the application is updated. To ensure you have the latest version,
we recommend you download it from our website www.scs-sentinel.com

B- DESCRIPTION

B- DESCRIPTION
B1- Content / Dimensions
174 mm
112 mm
Indoor monitor
Screws
22 EN
55 mm
155 mm
1 2
4 5
7 8
* 0
Outdoor
station
Connector
dry contact input
3
6
9
#
Supports
(flat and corner)
DC adapter
Manual
