HPRT Ares Pro Quick Start Manual

Quick Start Guide
Ares Pro
Cau�on:
This is a Class A product. In a domes�c environment this
product may cause radio interference in which the user
may be required to take adequate measures.
Xiamen Hanin Electronic Technology Co., Ltd.
ADD: No.96, Rongyuan Road, Tong'an District, Xiamen, China 361100
WEB： www.hprt.com
-1-
Packing List
Printer AC Adapter
Label Roll CD
！
Note: The packing items are actually based on the order.
Appearance and Components
②
④
①
⑥
③ ⑤
⑦
⑰
⑪
⑬
⑭
⑫
！
Note: The interface shown in the figure above is for reference only.
-2-
Power Cord USB Cable
Quick Start Guide
①Display
②Power Bu�on
③Printer Cover
④Feed Bu�on
⑧
⑤Cover Open Levers
⑨
⑥USB Port(Type A)
⑩
⑦USB Port(Type B)
⑧Serial Port
⑨Power Receptacle
⑩Ethernet Port
⑪Moveable Roll Holders
⑱
⑫Locking Tab
⑬Kick-stand Cover Lock
⑭Moveable Label Guides
⑮Label Sensor
⑯Platen
⑮
⑰Ribbon Supply Wheel
⑱Ribbon Supply Pin
⑯
