- Page 1 Powerball Color ENGLISH Operation Manual Other languages can be downloaded from: WWW.JB-SYSTEMS.EU Version: 1.0...
-
Page 3: Before Use
USER MANUAL OPERATION MANUAL ® Thank you for buying this JB Systems product. To take full advantage of all possibilities and for your own safety, please read these operating instructions very carefully before you start using this unit. This device was designed to produce decorative effect lighting and is used in light show systems. -
Page 4: Safety Instructions
• The housing and the lenses must be replaced if they are visibly damaged. • Please use the original packing when the device is to be transported. • Due to safety reasons it is prohibited to make unauthorized modifications to the unit. JB SYSTEMS® POWERBALL COLOR... -
Page 5: Overhead Rigging
This secondary safety attachment should be installed in a way that no part of the installation can drop more than 20cm if the main attachment fails. • The device should be well fixed; a free-swinging mounting is dangerous and may not be considered! JB SYSTEMS® POWERBALL COLOR... -
Page 6: How To Set Up And Control The Unit
• Press the [ENTER] button again if you want to set the sound sensitivity of the internal microphone: • Use the [UP] and [DOWN] buttons to set the sound sensitivity of the internal microphone [u.7] to [u.100] • Press the [ENTER] button to confirm. JB SYSTEMS® POWERBALL COLOR... - Page 7 Sound controlled programs and use the – and + buttons to modify the setting Select the rotation direction and use the – and + buttons to modify the setting Select the rotation speed and use the – and + buttons to modify the setting JB SYSTEMS® POWERBALL COLOR...
- Page 8 DMX- Channel value function remarks 000-005 Blackout No Rotation 006-036 037-068 Green 069-100 Blue Slow rotation 101-132 White 118-164 Auto Program 165-196 Sound Program No rotation 197-228 Sound Program Slow rotation 229-255 Sound Program Medium rotation JB SYSTEMS® POWERBALL COLOR...
- Page 9 Sound control for the selected program via channel 1 No rotation 001-127 Clockwise rotation Motor Control No rotation 129-255 Anticlockwise rotation 000-005 No strobe 006-127 Random strobe 128-250 Normal Strobe Speed Standard strobe (slow to fast) 251-255 Sound Strobe JB SYSTEMS® POWERBALL COLOR...
- Page 10 • Press the [ENTER] button if you want to enter this part of the menu with extra options. • Use the [UP/DOWN] buttons to browse the extra functions in this System menu [ir] = Infra Red Remote controller: with this function you can deactivate the infra-red remote controller receiver. JB SYSTEMS® POWERBALL COLOR...
-
Page 11: Maintenance
Working temperature: 10°C to 40°C Dimensions: 242 x 242 x 275mm Weight: 4.65kg All the information is subject to change without prior notice You can download the latest version of this user manual on our website: www.jb-systems.eu JB SYSTEMS® POWERBALL COLOR... -
