Seav L 2150 NEW Series Manual

LX 2150 NEW ELECTRONIC PANEL
Single-phase electronic control unit for swinging gates, with
built-in radio receiver. It is equipped with initial motor boost,
motor power adjustment and deceleration power adjustment,
pedestrian passage, dead man and several other functions, all
easily selectable by the installer manually or via Smartphone
using the BW 2356 Interface with which it will be possible to
configure the control unit,
(Bluetooth), it also gives the user the possibility to send
commands not only from the radio control and push button
panel but also from a Smartphone using the BeLite APP
(Bluetooth) or the BeAll APP (Wi-Fi).
- Mod. LG 2150 New
- Mod. LS 2150 New SET
- Mod. LH 2150 New
I
MPORTANT FOR THE USER
- The device can be used by children over 8 years of age
and persons with reduced physical or psychological
abilities or with little knowledge and experience only if
supervised or educated in its operation and safe use, in
order to also understand the dangers involved in its use.
- these instructions are also available at the website
www.seav.com
- Do not allow children to play with the device and keep
the radio controls away from their reach.
- Frequently examine the system to detect any signs of
damage. Do not use the device if it is in need of repair
work.
-Always remember to disconnect the power supply before
carrying out any cleaning or maintenance.
- Cleaning and maintenance must not be carried out by
unsupervised children
- ATTENTION: keep this instruction manual safe and
observe the important safety requirements contained
herein. Failure to comply with the requirements may
cause damage and serious accidents.
I the
MPORTANT FOR INSTALLER
− Before automating the gate, check that it is in good
conditions, in compliance with the Machinery
Directive and with EN 12604.
− Check that the location where the installation is
located enables compliance with operating
temperature limits specified for the device.
− The safety of the final installation and compliance
with all prescribed Standards (EN 12453 - EN
12445) is the responsibility of the person who
assembles the various parts to construct a total
closing.
− Once installation is finished, it is recommended that
all necessary checks be performed (appropriate
programming of the control panel and correct
installation of safety devices) to ensure that
compliant installation has been performed.
− The control unit does not have any type of isolating
device for the 230 Vac line. It is therefore the
responsibility of the installer to set up an isolating
device inside the system. It is necessary to install an
omnipolar switch, surge category III. It must be
positioned to provide protection from accidental
closing, pursuant to point 5.2.9 of EN 12453.
GB
through the BeTech APP
: Without radio reciver
: 433,92 Mhz "narrow band"
: 868,3 Mhz "narrow band"
− For the power supply cables, use flexible cables in an
insulating sheath in harmonised polychloroprene
(H05RN-F) with a minimum conductor section of
1mm2
− The various electrical components external to the
control unit must be cabled in accordance with
standard EN 60204-1 as amended, and as set forth
in point 5.2.7 of EN 12453. Power cables may have
a maximum diameter of 14 mm. The fixing of power
and connection cables must be secured through the
use of "optional" cable glands supplied. Pay careful
attention when fastening the cables so that they are
anchored in a stable manner.
Furthermore, care is required when drilling holes in the
outside casing where connecting and power supply
cables will pass, and when assembling the cable glands,
so that everything is installed so as to maintain the
panel's IP protection characteristics.
− The assembly of a push button panel for manual
control must be completed positioning the push
button panel in such a way that the user is not
placed in a dangerous position.
− The rear part of the casing is equipped with
fittings for wall mounting (it is possible to drill holes for
installation with plugs, or there are already holes
available for installation with screws). Plan and
implement all necessary measures to achieve an
installation that does not alter the IP protection.
− The gear motor used to move the gate must comply
with the requirements of point 5.2.7 of EN 12453.
− The D.S. Power Supply output must be dedicated to
the power supply of the photocells only. It cannot be
used for other applications.
− With every operation cycle, the control unit performs
the photocell operating test, ensuring protection
against the rupture of Category 2 crush-proof
devices, in accordance with point 5.1.1.6. of EN
12453. Accordingly, if the safety devices are not
connected and/or are not working, the control unit is
not enabled for operation.
− The safety function ensured by the control unit is
active only during closing, therefore, protection on
opening must be ensured in the installation phase
with measures (guards or safety distances)
independent of the control circuit.
− For proper functioning of the radio receiver, if using
one or more control units, the installation at a
minimum distance of at least 3 metres one from the
other is recommended.
